1.2 Getting to Know Your Camera

Infrared LEDs (x7)
allow your camera to
capture clear image in
a dark environment.
Power LED
indicates the camera
is powered on with
the steady amber
light.
Link LED
indicates the camera's
network connectivity
with the flashing green
light.
* The camera's USB port supports WCN (Windows Connect Now)
technology, which allows you to use the notebook computer to set
up and store your wireless networking configuration on the USB
storage device, and then retrieve the wireless settings when you
connect the USB storage device to the camera.
NOTE After long pressing the Unmount button for four seconds, the
Power LED starts flashing. When the Power LED resumes the
steady amber light, you can remove the USB device safely.
Light Sensor
is used to trigger on and off the
Infrared LEDs according the
environmental light level.
Internal Microphone
allows the camera to
receive sound and voice.
Front View
- 4 -
Antenna
Lens Assembly
USB Port*
allows you to connect an
external USB device. It
provides the power
distribution up to 500mA.
