IPUX ICS1330 Installation Manual page 17

 Auto Patrol button controls the camera to automatically
scan the preset positions once. Click Stop to stop patrolling.
 Click the Number button (1~8) to move the camera lens to
the preset position immediately.
To set up the preset positions, move the camera lens by
clicking the Left/Right/Up/Down buttons to the desired
position first, then select the number (1~8) from the pull-
down list and click the Apply button. You can enter a
descriptive name for the assigned position in the text box to
identify it easily.
 Function Buttons
video, and trigger functions.
 Manual Record allows you to record and save a video clip.
 Snapshot allows you to capture and save a still image.
 Browse allows you to assign the destination folder to store
the video clips and still images.
 Talk allows you to speak out through the camera. Please
note only one user is allowed to use this function at a time.
 Listen allows you to receive the on-site sound and voice
from the camera.
 Trigger Out allows you to trigger on/off the GPIO output
manually.
NOTE If your PC use Microsoft Vista platform. Maybe you can't find
these recorded files what stored by Snapshot or Manual
Record. That you need to disable the protected mode of
Security in the IE Browser. Please follow as below Steps:
1. Open IE Browser
2. Select ToolsInternet Options
3. Select Security
4. Disable the "Enable Protected Mode" then press OK
–
Use these buttons to control the audio,
- 16 -
