- Page 1 ICS7222 Box Type CMOS H.264/MPEG4 Mega Pixel PoE IP Camera with Removable IR Cut Filter(Support DC-iris) Advanced Installation Guide Version 1.0...
-
Page 2: Preface
REFACE Thank you for purchasing ICS7222, a standalone system that can be connected directly to an Ethernet or Fast Ethernet network. Equipped with a megapixel CMOS sensor, the camera allows you to capture a wider field of view with a resolution of up to 1280 x 1024. - Page 3 This Advanced Installation Guide provides you with the instructions and illustrations on how to use your camera, which includes: Chapter 1 Introduction to Your Camera describes the features of the camera. You will also know the components and functions of the camera. Chapter 2 Hardware Installation helps you install the camera according to your application environment.
-
Page 4: Table Of Contents
Contents Preface ....................1 Chapter 1 Introduction To Your Camera ..........4 Checking the Package Contents ..........4 Getting to Know Your Camera........... 5 Features and Benefits..............7 System Requirement ............... 10 Chapter 2 Hardware Installation............. 11 Attaching the Wall Mount Kit............ 11 Connecting the Cables ............ -
Page 5: Chapter 1 Introduction To Your Camera
HAPTER NTRODUCTION AMERA 1.1 Checking the Package Contents Check the items contained in the package carefully. You should have the following: One ICS7222. One AC Power Adapter One Wall Mount Kit One GPIO Connector One Ethernet Cable (RJ-45 type) ... -
Page 6: Getting To Know Your Camera
1.2 Getting to Know Your Camera Front and Top and Side View DC-Iris Connector allows you to attach the DC-iris lens (optional). Screw Hole* is used to attach the camera stand onto the camera by screwing the screw head of the camera stand into the screw hole of the camera. -
Page 7: Rear View
Rear View Video out connects the composite video output Ethernet Cable Connector (BNC type) of the external connects the network cable, video device. which supports the NWay protocol so that the camera can detect the network speed LED* automatically. SD Card Slot GPIO and RS485 is used to DC Power Connector... -
Page 8: Features And Benefits
1.3 Features and Benefits H.264/MPEG4/MJPEG Multi-codec Supported The camera provides you with excellent images by the H.264/MPEG4/ MJPEG multi-codec selectable technology, allowing you to adjust image size and quality, and bit rate according to the networking environment. High Resolution Surveillance Equipped with a megapixel CMOS sensor, the high performance camera is designed for your professional surveillance and security applications. - Page 9 Remote Control Supported By using a standard Web browser or the bundled UltraView Pro software application, the administrator can easily change the configuration of the camera via Intranet or Internet. In addition, the camera can be upgraded remotely when a new firmware is available.
- Page 10 PoE Supported PoE (Power over Ethernet) standard enables the camera to be powered by the Ethernet, which simplifies your surveillance system by eliminating the need of power outlet. The PoE camera features both stability and security, providing a cost-saving solution to your application of Internet camera.
-
Page 11: System Requirement
1.4 System Requirement Networking LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet; Auto-MDIX. Accessing the Camera using Web Browser Platform: Microsoft® Windows® 2000/XP/Vista/ Win7 CPU: Intel Pentium III 800MHz or above RAM: 512MB Resolution: 800x600 or above ... -
Page 12: Chapter 2 Hardware Installation
HAPTER ARDWARE NSTALLATION 2.1 Attaching the Wall Mount Kit The Wall Mount Kit that is provided in the package has a swivel ball screw head, so that can you can attach it to the screw hole on the camera’s top (or bottom) panel. After attaching the camera to the Wall Mount Kit, the camera can be mounted on the wall or ceiling securely through the three screw holes on the base of the Wall Mount Kit. -
Page 13: Connecting The Cables
2.2 Connecting the Cables 1. Connecting the camera to power source Use the provided AC power adapter to connect the camera to the power supply, such as the electrical outlet on the wall, and the camera will be powered on automatically. You can verify the power status from the Power LED on the rear panel of the camera. -
Page 14: Installation Of The Lens Assembly
2.3 Installation of the Lens Assembly The camera is designed with a CS- mount, allowing you to install any standard C or CS lens that are commonly used in the surveillance application. To install new lens assembly, follow the instructions below: 1. -
Page 15: Applications Of The Camera
2.4 Applications of the Camera The camera can be applied in multiple applications, including: Monitor local and remote places and objects via Internet or Intranet. Capture still images and video clips remotely. Upload images or send email messages with the still images attached. -
Page 16: Chapter 3 Accessing The Camera
HAPTER CCESSING AMERA 3.1 Using IPFinder The camera comes with a conveniently utility, IPFinder, which is included in the Installation CD-ROM, allowing you to search the camera on your network easily. 1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program. -
Page 17: Accessing To The Camera
3.2 Accessing to the Camera Whenever you want to access the camera: 1. Since the default configuration of the camera is DHCP mode enabled, you are recommended to launch IPFinder to search the IP address that is assigned to the camera by the DHCP server, and then click Link to access the camera via the Web browser. - Page 18 After you login into the Web Configuration of the camera, the Main screen will appear as below: The Main screen of the Web Configuration provides you with many useful information and functions, including: ...
- Page 19 Function Buttons: Use these buttons to control the audio, video, and trigger functions. Manual Record allows you to record and save a video clip. Snapshot allows you to capture and save a still image. Browse allows you to assign the destination folder to store the video clips and still images.
-
Page 20: Configuring The Ip Address Of The Pc
3.3 Configuring the IP Address of the PC If you are failed to access to the camera, please check the IP address of your computer. When you connect the camera to your computer directly to proceed with configuration of the camera, you need to set up the IP addresses to be in the same segment for the two devices to communicate. -
Page 21: Chapter 4 Configuring The Camera
HAPTER ONFIGURING AMERA 4.1 Using the Web Configuration You can access and manage the camera through the Web browser and the provided software application UltraView Pro. This chapter describes the Web Configuration, and guides you through the configuration of the camera by using the Web browser. To configure the camera, click on the Main screen of Web Configuration. -
Page 22: Using Smart Wizard
4.2 Using Smart Wizard The camera’s Smart Wizard lets you configure your camera easily and quickly. The wizard will guide you through the necessary settings with detailed instructions on each step. To start the wizard, click Smart Wizard in the left menu bar. Step 1. - Page 23 Step 3. Email Settings Enter the required information to be able to send email with image. Step 4. Confirm Settings Click Apply to finish the wizard and reboot the camera. Click Prev to go back to the previous step(s) and change the settings;...
-
Page 24: Basic Setup
4.3 Basic Setup The Basic menu contains three sub-menus that provide the system settings for the camera, such as the Camera Name, Location, Date & Time, and User management. 4.3.1 Basic >> System Basic: This item allows you to assign the camera name and location information. - Page 25 Indication LED: This item allows you to set the LED illumination as desired. There available options include: Normal, OFF, and Dummy. IR cut filter control: With a removable IR-cut filter, this Network Camera can automatically remove the filter to let IR light into the sensor during low light conditions.
-
Page 26: General User
4.3.3 Basic >> User Administrator: To prevent unauthorized access to the camera’s Web Configuration, you are strongly recommend to change the default administrator password. Type the administrator password twice to set and confirm the password. General User - User Name: Enter the user’s name you want to add to use the camera. -
Page 27: Network Settings
4.4 Network Settings The Network menu contains two sub-menus that provide the network settings for the camera, such as the IP Setting, DDNS Setting, and IP Filter. 4.4.1 Network >> Network IP Setting: This item allows you to select the IP address mode and set up the related configuration. - Page 28 - DHCP: Select this option when your network uses the DHCP server. When the camera starts up, it will be assigned an IP address from the DHCP server automatically. - Static IP: Select this option to assign the IP address for the camera directly.
- Page 29 3. Enter the required information in the Host Name, User Name, and Password boxes. NOTE You have to sign up for DDNS service with the service provider before configuring this feature. UPnP: The camera supports UPnP (Universal Plug and Play), which is a set of computer network protocols that enable the device-to-device interoperability.
- Page 30 RTSP - RTSP Streaming: Selection the Authentication as Disable or Enable to configure the transmission of streaming data within the network. The default RTSP Port (Real Time Streaming Protocol) is 554. - Multicast settings: Configure the following settings so that you can deliver information from your camera to a set of receivers.
- Page 31 allowed to access the camera, or select the Deny option to assign the range of IP addresses that are blocked to access the camera. Disable: Select this option to disable the IP Filter function of the camera. Accept - IPv4: Assign a range of IP addresses that are allowed to access the camera by entering the Start IP address and End IP address options.
-
Page 32: Image Setting
4.5 Setting up Video & Audio The Video & Audio menu contains four sub-menus that provide the video and audio settings for the camera. 4.5.1 Video & Audio >> Camera Image Setting - Black Level: Adjust the black level from 0 ~ 5. - Brightness: Adjust the brightness level from 0 ~ 100. - Page 33 - Light Frequency: Select the proper frequency according to the camera’s location to reduce the noise: 50Hz or 60Hz. - Auto Iris: When you attach a DC-Iris lens with the auto Iris function, select the DC Iris Lens option to enable the feature.
- Page 34 - Video Quality: Select the desired image quality from five levels: Lowest, Low, Medium, High, and Highest. - Frame Rate: Select Auto or a proper setting depending on your network status. NOTE The camera supports H.264, MPEG4 and MJPEG compression. Please note that that MJPEG mode captures the images in JPEG format, which requires higher bandwidth to view smooth video.
- Page 35 You can set the speaker’s volume by entering the proper value in the Volume option. The default setting is 90. 4.5.4 Video & Audio >> Overlay / Mask This sub-menu is used to set the image overlay and mask feature of the camera.
- Page 36 4.5.6 Video & Audio >> Overlay / Mask >> Text Overlay This page is used to set the text overlay feature of the camera, including the following three options: date & time, heading text, and background transparency setting. Include Date & Time: Select this option to display the date &...
-
Page 37: Event Server Configuration
4.6 Event Server Configuration The Event Server menu contains four sub-menus that allow you to upload images to FTP, send emails that include still images, and store the images to a NAS system. When you complete the required settings for FTP, Email, or Network Storage, click Test to test the related configuration is correct or not. - Page 38 - User Name: Enter the user name to login into the FTP server. - Password: Enter the password to login into the FTP server. - Directory Path: Enter the destination folder for uploading the images. For example, /Test/. - Passive Mode: Select the Enable option to enable passive mode.
-
Page 39: Network Storage
- Sender User Name: Enter the user name to login the mail server. - Sender Password: Enter the password to login the mail server. - Receiver #1 Email Address: Enter the first email address of the user who will receive the email. - Receiver #2 Email Address: Enter the second email address of the user who will receive the email. - Page 40 - Encode Format: Select MPEG4 or H.264 as the encode format while recording. - File Format: Select MP4 or AVI as the file format while recording. NOTE The recorded video files in Network Storage are enclosed by AVI format without audio. 4.6.4 Event Server Setting >>...
-
Page 41: Motion Detect
4.7 Motion Detect The Motion Detect menu contains the command and option that allow you to enable and set up the motion detection feature of the camera. The camera provides three detecting areas. To enable the detecting area, select Window 1/2/3 from the pull- down list, and then select Enable. -
Page 42: Event Configuration
4.8 Event Configuration The Event Config menu contains five sub-menus that provide the commands to configure event profiles. 4.8.1 Event Configuration >> General Setting General - Snapshot/Recording Subfolder: You can assign a descriptive name for the subfolder to save the captured image/video files. - Page 43 4.8.2 Event Configuration >> Arrange Schedule Profile Schedule Profile: This sub-menu displays the scheduled profile(s). To customize the profile, click Add and then enter a descriptive name for the profile in the prompt dialog window. After entering the profile name, click OK and the profile is added to the Schedule Profiles list.
- Page 44 4.8.3 Event Configuration >> Motion Detect Trigger Motion Detect Trigger: Select the Enable option to enable the trigger function of the camera, so that you can send captured images within the detecting area to the FTP server, email receiver, or the Network Storage server. You have to configure corresponding settings, such as FTP server and email server, to enable this feature.
- Page 45 4.8.5 Event Configuration >> GPIO Trigger GPIO Trigger: Select the Enable Trigger In 1/2 option to enable the GPIO trigger function of the camera, so that you can set Trigger Out function or send captured images within the detecting area to the SD card, FTP server, email receiver, Network Storage server, or send an instant message.
-
Page 46: Tools
4.9 Tools The Tools menu provides the commands that allow you to restart or reset the camera. You can also backup and restore your configuration, and upgrade the firmware for the camera. Factory Reset: Click Reset to restore all factory default settings for the camera. - Page 47 Update Firmware: You can upgrade the firmware for your camera once you obtained a latest version of firmware. - Current Firmware Version: This item displays the current firmware version. - Select the firmware: Click Browse to locate the backup file and then click Update.
-
Page 48: Rs-485
4.10 RS-485 The RS-485 menu provides the control settings for external device through the I/O port. Select the Enable option and complete the required configuration to use the RS-485 function of the camera. RS-485 >> RS-485 Setting Popular Protocol Setting: Select this option and then select a protocol. -
Page 49: Setting Up Sd Card
Command string boxes should be from the connected external device (please refer to the manual of the connected device). About the control buttons on the Main window, see the following instructions 4.11 Setting up SD Card The SD Card menu allows you to set up the SD card. 4.11.1 SD Card >>... - Page 50 - Encode Format: Select MPEG4 or H.264 as the encode format while recording. - File Format: Select MP4 or AVI as the file format while recording. 4.11.2 SD Card >> File Manager Use the File Manager to store the files from the SD card (inserted in the camera) to your computer.
-
Page 51: Information
4.12 Information The Information menu displays the current configuration and events log of the camera. 4.12.1 System Information >> Device Information Display the Basic, Video & Audio, and Network settings of the camera. 4.12.2 System Information >> Logs The Logs table displays the events log recorded by the system. - 50 -... -
Page 52: Appendix
Appendix A.1 Specification Image Sensor Sensor 1/3.2” Color Mega CMOS Sensor Resolution 1600 x 1200 Min. Illumination 1 Lux System Hardware Processor ARM9 base 64MB SDRAM 8MB NOR Flash Power DC 12V Video Compression H.264/MPEG4/MJPEG Video resolution SXGA (1280 x 1024): 15fps;... - Page 53 LEDs Power LED (amber); Link LED (green) Communication 10/100Mbps Fast Ethernet, auto-sensed, Auto-MDIX IEEE802.3af Protocol support TCP/IP, IPV6, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP Software OS Support Windows XP/Vista/Win7 Browser Internet Explorer 6.0 or above;...
-
Page 54: Gpio Terminal Application
A.2 GPIO Terminal Application Typically used in association with programming scripts for developing applications for motion detection, event triggering, alarm notification via e-mail, and a variety of external control functions. The 8-pin I/O Terminal Block is located on the rear panel and provides the interface to: a photo-coupled switch output, a photo-coupled input, and RS-485 interface. -
Page 55: Bandwidth Reference Guide
A.3 Bandwidth Reference Guide H.264 Bit rate (Kbit/s) Frame Resolution rate (fps) Lowest Normal High Highest QQVGA QVGA 1024 1024 2048 SXGA 1536 3072 MPEG4 Bit rate (Kbit/s) Frame Resolution rate (fps) Lowest Normal High Highest QQVGA QVGA 1024 1024 2048 MJPEG Image size (KB) -
Page 56: Glossary Of Terms
A.4 Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media. 100BASE-TX The two-pair twisted-media implementation of 100BASE-T is called 100BASE-TX. ADPCM Adaptive Differential Pulse Code Modulation, a new technology improved from PCM, which encodes analog sounds to digital form. - Page 57 Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media. They represent the sender and receivers. The data they send is the message. The cabling or transmission method they use is the medium.
- Page 58 Enterprise An enterprise network consists of collections of network networks connected to each other over a geographically dispersed area. The enterprise network serves the needs of a widely distributed company and operates the company’s mission-critical applications. Ethernet The most popular LAN communication technology. There are a variety of types of Ethernet, including 10Mbps (traditional Ethernet), 100Mbps (Fast Ethernet), and 1,000Mbps (Gigabit Ethernet).
- Page 59 Short for hexadecimal refers to the base-16 number system, which consists of 16 unique symbols: the numbers 0 to 9 and the letters A to F. For example, the decimal number 15 is represented as F in the hexadecimal numbering system. The hexadecimal system is useful because it can represent every byte (8 bits) as two consecutive hexadecimal digits.
- Page 60 connection methods, you get connected to the computer that “owns” that IP address. ISP (Internet Service Provider) is a company that maintains a network that is linked to the Internet by way of a dedicated communication line. An ISP offers the use of its dedicated communication lines to companies or individuals who can’t afford the high monthly cost for a direct connection.
- Page 61 internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network. NAT solves the problem. When devices within your network request information from the Internet, the requests are forwarded to the Internet under the router's IP address.
- Page 62 Protocol Communication on the network is governed by sets of rules called protocols. Protocols provide the guidelines devices use to communicate with each other, and thus they have different functions. Some protocols are responsible for formatting and presenting and presenting data that will be transferred from file server memory to the file server’s net work adapter Others are responsible for filtering information between networks and forwarding data to its destination.
- Page 63 Server It is a simple computer that provides resources, such as files or other information. SIP (Session Initiated Protocol) is a standard protocol that delivers the real-time communication for Voice over IP (VoIP), which establishes sessions for features such as audio and video conferencing. SMTP The Simple Mail Transfer Protocol is used for Internet mail.
- Page 64 The User Datagram Protocol is a connectionless protocol that resides above IP in the TCP/IP suite User Name The USERNAME is the unique name assigned to each person who has access to the LAN. Utility It is a program that performs a specific task. Unshielded twisted-pair.
