To compensate for image degradation, which is caused by
using a long cable.
RED/GREEN/BLUE DELAY
To adjust the each phase of RED, GREEN and BLUE
signal.
LEVEL: 0 - 6
RED/GREEN/BLUE SHARPNESS
To adjust the each performance degradation of RED,
GREEN and BLUE signal.
0 LEVEL: 0 - 45
2
0
0
0
SOG PEAK
0
0
0
To adjust the shape of Sync on Green signal.
HI / LO
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
Level: 0 - 1
VIDEO EQ (Input RGB 3 only)
To optimize the shape (Tailing) of RED, GREEN and
BLUE signal.
Level: 0 - 7
SYNC TERMINATE (Input RGB 3 only)
To select the terminate resistance for matching the cable
impedance.
HI: 2.2K ohm/LO:75 ohm
The OSM control menu will stay on as long as it is use.
In the OSM Turn Off submenu, you can select how long
the monitor waits after the last touch of a button to shut
10 SEC.
off the OSM control menu. The preset choices are
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
10 -240 seconds.
Selects the information OSM display or not. The
information OSM will display when input signal or
ON 10 SEC.
source change or warning message like as no-signal or
OFF
out-of range.
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
A time between 3 to 10 seconds is available.
To select OFF TIMER mode ON/OFF.
In the OFF TIMER menu, you can preset the monitor to
automatically power down.
ON 1 HOUR
OFF
A time between 1 to 24 hours is available.
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
When the OFF TIMER is set, the SCHEDULE
(see page 26) settings will be disabled.
Selects the kind of DVI-D equipment which is connected
RGB1.
Select "DVI-PC" when PC or other computer equipment
DVI-PC / DVI-HD
is connected.
+ -:SEL :RETURN :EXIT MENU
EXIT MENU
Select "DVI-HD" when DVD player, which has DVI-D
output, is connected.
Adjusts the position of the OSM menu.
UP
Press + button to move right side of the screen.
Press - button to move left side of the screen.
LEFT RIGHT
Press button to move right side of the screen.
DOWN
+ - :ADJ
EXIT :RETURN MENU :EXIT MENU
Press button to move left side of the screen.
