Quick Start Guide
for the NeptuNe™ Sound processor
For additional information about the operation of your processor, refer to the
Neptune Sound processor user Guide.
Neptune System Parts
1.
Sound processor
2.
processor Led
3.
On/Off Button
4.
auxiliary connector
5.
Battery cover
6.
color cover
7.
Neptune connect
8.
Neptune connect Sync Light
9.
program Switch
4
7
1
16
5
12
9
10.
Volume control
11.
Sensitivity control
12.
euro port connector
13.
Headpiece
14.
Microphone
15.
Headpiece cable
16.
aaa Battery
17.
Headpiece cable connector
18.
Neptune connect release Latch
11
8
10
13
18
17
4
3
2
SIDE VIEW
14
6
15
18
17
Advertisement
Related Manuals for Advanced Bionics Sound Processor
Summary of Contents for Advanced Bionics Sound Processor
-
Page 1: Quick Start Guide
Quick Start Guide for the NeptuNe™ Sound processor For additional information about the operation of your processor, refer to the Neptune Sound processor user Guide. Neptune System Parts Sound processor Volume control processor Led Sensitivity control On/Off Button euro port connector... - Page 2 Powering Your Processor to turn your processor ON, press and hold the Neptune ‘on/off’ button for 1–2 seconds. You should notice the orange Led within the button flashing to indicate battery charge. to turn your processor OFF, press and hold the Neptune ‘on/off’...
- Page 3 Understanding Sync Light Indicators Color Behavior Indication Green Blinks once Neptune connect and processor settings are synced. Blinks once per second Neptune processor and Neptune connect settings are NOt synced. Solid error condition. if this occurs, remove and re-attach the Neptune connect.
- Page 4 You may need to sync Neptune connect and processor prior to program, volume, or sensitivity control changes taking effect. 9050050265 reV A...
