VSM Pro Documentation Overview

Video System Manager Pro is an integrated hardware and software solution. This Quick Start guide describes the
steps required to set up VSE Pro hardware and install VMT mapping software. The following documents are also avail-
able to help you make the most of your complete solid-state lighting system:
Document Name
VSM Pro Release Notes
VSM Pro Installation Instructions www.philipscolorkinetics.com/ls/controllers/vsmpro Printed booklet
VSM Pro Product Guide
VSM Pro User Guide
VMT User Guide
Lighting Fixture Wiring Diagrams www.philipscolorkinetics.com/support/wiring/

Hardware Installation

Mount the VSE Pro Hardware
Mount the Video System Engine Pro in a rack location that meets environment specifications (see the
VSM Pro Product Guide for details) and is accessible to the lighting installation network and media source.
Make sure power is Off
Before connecting network or video input cables, use the Power switch on the front of the device to shut
down, then use the master power switch on the back of the device to disconnect power.
Connect network, video, and power cables
Determine which of the two versions of VSM Pro you're installing: DVI / VGA video or Composite video:
DVI / VGA Cable Installation
a) Connect the Ethernet cable from your lighting installation's Ethernet switch.
b) If connecting from VGA, connect your VGA cable to the appropriate DVI adapter.
c) Connect the DVI cable or DVI adapter directly to the DVI connector at the back of the VSM Pro.
d) Attach the power cable.
Composite Video Cable Installation
a) Connect the Ethernet cable from your installation's Ethernet switch.
b) Connect the red S1 Breakout cable.
c) Connect the Breakout connector to the Composite port at the back of the VSM Pro.
d) Attach the power cable.

System Requirements

A personal computer enables you to access the VSE Pro user interface and use VMT. Verify that your
computer meets the following minimum specifications:
Windows XP / Vista / 7
Windows 256 MB RAM
40 MB free disk space
Online Location
www.philipscolorkinetics.com/ls/controllers/vsmpro PDF, downloadable from VSM Pro interface
www.philipscolorkinetics.com/ls/controllers/vsmpro PDF, downloadable from VSM Pro interface
www.philipscolorkinetics.com/ls/controllers/vsmpro PDF, downloadable from VSM Pro interface
www.philipscolorkinetics.com/ls/controllers/vsmpro PDF, downloadable from VSM Pro interface
Included with VSM Pro
PDF, downloadable from VSM Pro interface
Mac OS X 10.5.8 or greater
Mac OS X 256 MB RAM
40 MB free disk space
