Philips Lytemode 2-Button Remote Station User Manual

Philips Lytemode 2-Button Remote Station User Manual

Architectural lighting control system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lytemode 2-Button Remote Station and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips Lytemode 2-Button Remote Station

Summary of Contents for Philips Lytemode 2-Button Remote Station

  • Page 2 Controls supplier which agrees in advance to handle the return and replacement by factory authorization). If the product or part is found by Philips Controls to have been This manual is for informational use only and is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Customer Service ..............2 Lytemode System Overview ..........3 2-Button Remote Station Overview ........4 Installation ................5 Basic Settings ................6 LED Intensity ..............6 Lockout ................6 Programming ................7 Remote ON/OFF ..............7 Remote RAISE/LOWER ..........8 Remote ROOM COMBINE ..........9 Remote LOCK/UNLOCK ..........10 Resetting Unit to Factory Defaults ........11 Installing Custom Buttons .............12 Specifications ................13...

  • Page 4: Customer Service

    Customer Service Technical and Sales assistance for Lytemode products are available worldwide. Phone: +1-800-526-2731 (In the United States and Canada) +1-214-647-7880 (Worldwide) Customer Service...

  • Page 5: Lytemode System Overview

    Lytemode System Overview The Lytemode System is designed to control architectural lighting by distributing both power and intelligence. The system provides processing power and control at each respective Master or Remote Station, eliminating the need for a central processor. Lytemode Master Stations provide individual control for up to 16 channels, 13 scenes plus “Off”, and adjustable fade times.

  • Page 6: 2-Button Remote Station Overview

    2-Button Remote Station Overview The Lytemode 2-Button Remote Station (ILS-CL-2RES) can be configured to operate in one of four modes: • Remote On/Off - allows unit to set a single scene or turn lights off. • Remote Raise/Lower - allows unit to adjust lighting levels.

  • Page 7: Installation

    Installation The Lytemode ILS Network consists of a single CAT5e cable connecting all ILS devices in a daisy chain manner. All units connect to the network using a 9-pin connector (included). To install: Step 1. Unpack unit and inspect for any signs of shipping damage. Ensure that two mounting screws are included.

  • Page 8: Basic Settings

    Basic Settings LED Intensity The LED intensity (brightness) may be set to four different levels. To program: Step 1. Press and hold TOP button for 3 seconds. Step 2. While holding TOP button, tap BOTTOM button. LED intensity will change. Step 3.

  • Page 9: Programming

    Programming The 2-Button Station can be set in one of four modes as follows: Remote ON/OFF Provides control for up to 16 Lytemode Masters (or separate IDs). In this configuration, the top (ON) button can be programmed to correspond with any Master scene (ON, A-L), while the bottom (OFF) button will always send an off command.

  • Page 10: Remote Raise/Lower

    Remote RAISE/LOWER Provides control for up to 16 Lytemode Masters (or separate IDs). In this configuration, the station can be used as either a Master Raise/Lower or a Channel Raise/Lower device. In the Raise/Lower mode, the top button sends the Raise RAISE command, while the bottom button will send the Lower command.

  • Page 11: Remote Room Combine

    Remote ROOM COMBINE When used with an ILS-CL-RCGP or ILS- CL8-RSPS Room Combine Panel, the unit can be programmed to control the combining of two rooms. The top (OPEN) button will send OPEN the room combine command, while the bottom (CLOSE) button will send the room un- combine command.

  • Page 12: Remote Lock/Unlock

    Remote LOCK/UNLOCK Provides control for up to 16 Lytemode Masters (or separate IDs). In this configuration, the 2-Button Remote Station provides lock- out control for any Master or Remote Station. This will allow the Master or Remote to be locked or unlocked without entering the password at each Master Station.

  • Page 13: Resetting Unit To Factory Defaults

    Resetting Unit to Factory Defaults To set the unit back to its Factory Defaults, do the following: Step 1. Press and hold TOP and BOTTOM buttons for 10 seconds. (Both LEDs will start to blink.) Step 2. Press TOP button. (Unit will clear and remove itself from the ILS network.) The LED intensity setting will not change.

  • Page 14: Installing Custom Buttons

    Installing Custom Buttons Custom engraved buttons* are available for Lytemode products. If you received custom buttons with your unit or obtain them in the future, use the following procedure for installation. To install custom buttons: Step 1. At 2-button unit, remove faceplate. Step 2.

  • Page 15: Specifications

    Specifications Electrical: • Input Power: +18-26 VDC (powered from Lytemode ILS network) • Current: 20mA • Temperature - Storage: -25° to 85° C - Operating: 0° to 40° C - Relative Humidity: 30-90% (non-condensing) Accessories Part Number Description ILSCK2B__* Color Kit for 2-Button Remote Station CE2BES*** Custom Engraved 2-Button Keypad Membrane COMFP1__**...
  • Page 16 Notes Notes...
  • Page 17 Notes 2-Button Remote Station User’s Guide...
  • Page 18 Notes Notes...
