This gas patio flame must be used only outdoors in a well-ventilated space and must not be used
inside a building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER!
This appliance can produce carbon monoxide, which has no odor. Using it in an
enclosed space can kill you. Never use this appliance in an enclosed space such as a
camper, tent, car or home.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
WARNING!
For Outdoor Use Only.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com
427-O-02-5
CARBON MONOZIDE HAZARD
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
LINEAR PATIOFLAME
OUTDOOR GAS FIREPLACE
GPFL48 (WITHOUT ENCLOSURE)
GPFL48MHP (WITH ENCLOSURE)
Do not try to light this appliance without reading
the "LIGHTING" instructions section of this manual.
Do not store or use gasoline or other flammable
liquids or vapors in the vicinity of this or any other
appliance. An L.P. cylinder not connected for
use must not be stored in the vicinity of this or
any other appliance. If the information in these
instructions is not followed exactly, a fire or explosion
may result, causing property damage, personal injury
or death.
Napoleon Appliance Corp.,
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
WARNING
N415-0239 MAR 17/11
Advertisement
Table of Contents
Related Manuals for Napoleon GPFL48MHP
Summary of Contents for Napoleon GPFL48MHP
- Page 1 MODEL NO. LINEAR PATIOFLAME OUTDOOR GAS FIREPLACE GPFL48 (WITHOUT ENCLOSURE) GPFL48MHP (WITH ENCLOSURE) DANGER! CARBON MONOZIDE HAZARD This appliance can produce carbon monoxide, which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home.
-
Page 2: Conditions And Limitations
After the first year, NAPOLEON® will not be responsible for installation, labour or any other costs or expenses related to the reinstallation of a warranted part, and such expenses are not covered by this warranty. -
Page 3: Safe Operating Practices
WARNING! For Outdoor Use Only. WARNING! Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this gas patio flame. Safe Operating Practices • THIS APPLIANCE IS HOT WHEN OPERATING AND CAN CAUSE SEVERE BURNS IF CONTACTED. •... -
Page 4: General Information
General Information This gas appliance is certified under Canadian and American National Standards, ANSI Z21.97-2010 “Standard for Outdoor Decorative Gas Appliance” and CAN/CGA 2.17-M91 (R2009) “Gas-Fired Appliance for use at High Altitude” and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CSA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States. -
Page 5: Specifications
Specifications DIMENSIONS BURNER BASE ENCLOSURE 13 1/2” 17 7/8” (343mm) (455mm) 47 1/2” (1206mm) 51 7/8” (1318mm) BURNER BASE ENCLOSURE 5 1/2” (138mm) 11 7/8” (302mm) INPUT GAS INLET PRESSURES MODEL FUEL MAX. INPUT Btu/Hr NATURAL PROPANE GPFL48N Natural Gas 60, 000 Inlet Pressure 7.0"... -
Page 6: Installation Options
Installation Options This unit is designed with some unique features that allow for maximum installation flexibility. 1. The gas supply to the enclosure can come either from underneath or through the side of the enclosure. The gas supply is shown entering the side of the enclosure. -
Page 7: Removing Control Panel
3. The supply can feed either into the side of the burner base, or is fed from below the base. The gas line needs to be disconnected from the gas valve and reconnected in order to do this. This must be done by a licensed gas fitter and the connections need to be leak tested according to the leak testing instructions before using the unit. - Page 8 WARNING! Cabinet frame, cabinet and counter top must be made from non-combustible material. WARNING! You must have clear and easy access to the on/off valve AFTER the appliance is installed and connected to the gas supply in order to safely turn off the burner. WARNING! Materials placed around the burner unit will get extremely hot.
- Page 9 Gas Hook-Up Instructions WARNING! If these instructions are not followed exactly, a fire causing death or serious injury may occur. Propane Cylinder Specifications A dented or rusty cylinder may be hazardous and should be checked by your propane supplier. Never use a cylinder with a damaged valve.
- Page 10 CAUTION! • Make sure cylinder valve is in its full off position. (Turn clockwise to stop). • Check cylinder valve features to ensure it has proper external mating threads. (Cylinder Valve Marked: USE WITH TYPE 1) • Inspect hose shipped with the unit for damage. Never attempt to use damaged or plugged equipment. See your local LP Gas Dealer for repairs.
- Page 11 The enclosure for the LP-gas cylinder shall isolate the cylinder from the burner compartment to provide: a. Shielding from radiation; b. A flame barrier; and c. Protection from foreign material. Be certain to mount or set the LP gas cylinder on a flat surface and restrain it using the cylinder retaining bracket to prevent it from tipping.
- Page 12 Conversion to Natural Gas WARNING! To avoid the possibility of burns conversions should only be done when the patio flame is cool. Ensure burner is turned off. Turn gas off at source and disconnect the patio flame before beginning conversion. WARNING! Glass embers may have sharp edges wear safety glasses and gloves when handling.
-
Page 13: Natural Gas Hook-Up
7. Reconnect the stainless steel flex connector to the orifice and tighten using (2) wrenches. 8. Place the glass tray over the burner and fasten to the patio flame with the screws removed in step 2. 9. A leak test must be performed according to the leak testing instructions found in the manual. Natural Gas Hook-Up The gas appliance is designed to operate at an inlet pressure of 7 inches water column. -
Page 14: Glass Ember Installation
Finishing Glass Ember Installation WARNING! Glass embers may have sharp edges, wear safety glasses and gloves when handling. Do not change or substitute the glass ember material provided with this appliance. If replacing, use only replacement glass embers available from your local authorized dealer / distributor. WARNING! Glass embers may have a fine oil residue that needs to be cleaned prior to installation. - Page 15 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
-
Page 16: Lighting Instructions
Lighting Instructions Igniter Open Cover WARNING! Never use the appliance when it is raining. A cover has been provided to protect the burner and glass embers when not in use. Remove the cover before starting the appliance. WARNING! Keep face and body away from burner area when lighting. WARNING! Ensure burner controls are in the off position. - Page 17 Inspect the hose assembly before each use. If there is evidence of excessive abrasion or wear, or if the hose is damaged it must be replaced prior to using the patio flame with a replacement hose assembly specified by your Napoleon dealer. NOTE! The patio flame has been designed with several safety features, which include a safety valve.
-
Page 18: Maintenance / Cleaning Instructions
Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the patio flame. Have the part replaced by your Napoleon dealer or qualified gas installer. Cleaning Inside The Patio Flame: While washing your patio flame, be sure to keep the area around the burner and pilot assembly dry at all times. - Page 19 Cleaning The Outer Patio Flame Surface: Do not use abrasive cleaners or steel wool on any painted, or stainless steel parts of your Napoleon Patio Flame. Doing so will scratch the finish. Exterior heater surfaces should be cleaned with warm soapy water. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.
-
Page 20: Troubleshooting
Troubleshooting Problem Possible Causes Solution Low heat / Low flame when For propane - improper lighting Ensure lighting procedure is followed carefully. valve turned to high. procedure. The valve must be in the off position when the tank valve is turned on. Turn tank on slowly to allow pressure to equalize. -
Page 21: Ordering Replacement Parts
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts Warranty Information MODEL: DATE OF PURCHASE: SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Care Department, check the NAC Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com. -
Page 22: Parts List
Parts List Item Part # Description n010-0699 base w272-0001 foot, rubber n570-0013 #8 x 5/8" screw n100-0043 main burner n565-0008 replacement screen n450-0025 1/4" - 20 nut n475-0289 control panel n725-0049 safety valve n051-0007 control knob bezel n380-0016r burner control knob n720-0044 flex connector 12"... - Page 23 Parts List Item Part # Description mkga glass embers - amber 6lb mkgc glass embers - clear 6lb mkgk glass embers - black 6lb mkgb glass embers - blue 6lb mkgr glass embers - red 6lb x - standard p - propane units only n - natural gas units only ac - accessory www.napoleongrills.com...
-
Page 24: Parts Diagram
Parts Diagram www.napoleongrills.com... - Page 25 FAX TO: 705 727 4282 ACCESSORIES & PARTS ORDER FORM PLEASE PRINT CLEARLY CONTACT NAME:______________________________________________________________________ SHIP TO :_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TEL :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ VISA OR MASTERCARD # :_______________________________________ EXPIRY DATE: _____________ SIGNATURE:_____________________________________________________________________________ QUANTITY PART NUMBER DESCRIPTION TAXES MAY APPLY SHIPPING EXTRA IF CONFIRMATION IS REQUIRED PLEASE INCLUDE A FAX NUMBER OR EMAIL ADDRESS...
- Page 26 TÉLÉCOPIEZ AU: 705 727 4282 BON DE COMMANDE POUR PIÈCES/ACCESSOIRES NOM DU CLIENT______________________________________________________________________ ADRESSE:_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TÉLÉPHONE :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ # VISA OU MASTERCARD :_______________________________________ DATE D’EXPIRATION : _____________ SIGNATURE:_____________________________________________________________________________ QUANTITÉ NUMÉRO DE PRODUIT DESCRIPTION LES TAXES PEUVENT S'APPLIQUER LES FRAIS D'EXPEDITION SUPPLÉMENTAIRE SI VOUS DÉSIREZ RECEVOIR UNE CONFIRMATION, VEUILLEZ INCLURE UN NUMÉRO DE TÉLÉCOPIEUR OU UNE ADRESSE COURRIEL...
