Maintenance Air Intake Filters; Routine Maintenance - Islandaire EZ Series 42 Engineer's Manual

Maintenance
Air Intake Filters
(2 per) Part Number 6080067
When air conditioner is operating, indoor air
is filtered and refiltered continuously trapping
airborne dirt and dust in the washable filter. The
air intake filters are removable for easy cleaning.
A clean filter helps remove dust, lint, and other
particles from the air and is important for best
cooling and operating efficiency.
Check the filter every two weeks to see whether
it needs cleaning.
1. Turn unit off.
2. Remove each air filter by grasping the top
edge of the filter frame and pulling each one
up and out of the unit.
3. Wash in hot soapy water, rinse and shake dry.
4. Replace the filter, with the front of the filter
toward you.
5. To dry the filter thoroughly, run your unit for
a few minutes in fan mode.

Routine Maintenance

• Keep air intake filter clean.
• Coils should be inspected periodically for
build-up of lint, dirt, leaves, other debris, and
bent fins.
Clean coils with a soft brush and compressed
air or vacuum. Do NOT use sharp objects to
clean coils.
• The fan motors are permanently lubricated
and do not require servicing.
• In areas of heavy snow and ice accumulation,
snow and ice should not be permitted to
accumulate against the unit.
practical after such inclement weather, clean
snow and ice from around the unit as much as
possible.
Manufacturer of Quality Air Conditioning and Heating Products • www.islandaire.com • sales@islandaire.com • (800)-886-2759
As soon as
30
Figure 34 Filter Removal
AIR INTAKE
FILTERS
