Islandaire EZ Series Engineering Manual
Perfect fit for replacing existing ge 8500 & 7500 series friedrich vertical, first company vertical and for new construction projects
Hide thumbs
Also See for EZ Series:
- Engineering manual (38 pages) ,
- Engineering manual (52 pages) ,
- Installation instructions & owner's manual (18 pages)
Advertisement
Quick Links
EZ Series
& EZ Series R (DR. TAC option)
Perfect fit for Replacing Existing
Friedrich Vertical, First Company Vertical and for New
Construction Projects
Engineering Manual
M A N U FA C T U R E R O F Q U A L I T Y A I R C O N D I T I O N I N G A N D H E AT I N G P R O D U C T S
Rev.
Advertisement
Related Manuals for Islandaire EZ Series
Summary of Contents for Islandaire EZ Series
- Page 1 EZ Series & EZ Series R (DR. TAC option) Perfect fit for Replacing Existing Friedrich Vertical, First Company Vertical and for New Construction Projects Engineering Manual M A N U FA C T U R E R O F Q U A L I T Y A I R C O N D I T I O N I N G A N D H E AT I N G P R O D U C T S...
- Page 2 APPLICATIONS ELECTRICAL INSTALLATION PRODUCT OVERVIEW SYSTEM CONTROLS AND MANAGEMENT PRODUCT FEATURES AND BENEFITS ..5 DATA & SPECIFICATIONS OPTIONS AND ACCESSORIES ......1 INSTALLATION INSTRUCTIONS Islandaire reserves the right to make changes in design and construction at any time without notice.
- Page 3 Our Company The Perfect Fit The Islandaire Team...
- Page 4 Applications ADVANTAGES FOR NEW CONSTRUCTION Design Flexibility For The Architect Engineer Lower Operating Costs & Reliable Comfort for the Occupant Retrofit/ Replacement New Construction...
- Page 5 Applications Application Guaranteed Quality Considerations Indoor Air Quality - DR. TAC UNDERSIZING OVERSIZING AIR INFILTRATION...
-
Page 6: Product Overview
Product Overview All Units Have Seacoast Quiet Operation Construction Durable Construction Standard on All Models: Corrosion protection treatment shields the unit from corrosive environments and extends the life of the unit especially in coastal locations. - Page 7 Features and Benefits nefits Slide Out Chassis – and quiet operation See page page for chassis installation instructions for chassis installation instruction Wall – for maximum scratch, dent and corrosion resistance. See pages 1 for wall sleeve installation instructions Exterior Louver/Grilles – See pages for exterior grille installation instructions Removable Front Panel...
-
Page 8: Ordering Data
Ordering Data Model Nomenclature COMPONENT FUNCTIONAL OPTIONS B- M EZ - C MODEL TYPE COOLING CAPACITY 09 - 9,000 BTU 12 - 12,000 BTU POWER MANAGEMENT OPTIONS 15 - 15,000 BTU A- N 1 - 1 ,000 BTU C- E M . - Page 9 Performance Data Performance Data for EZ Series Heating options HEATING OPTION WATTAGE Electrical LINE VOLTAGE MAXIMUM AMPERAGE WALL SOCKET CONFIGURATION RECEPTACLE NUMBER ELECTRICAL HEAT OPTIONS...
- Page 10 Model Nomenclature COMPONENT MODEL TYPE FUNCTIONAL OPTIONS COOLING CAPACITY POWER MGT. OPTIONS SYSTEM TYPE IDENTITY CODE VOLTAGE/LINE CORD HEATING OPTIONS RETURN/DISCHARGE OPTIONS HYDRONIC OPTIONS ROOM CONTROLS...
- Page 11 Performance Data Performance Data for EZ R Series Heating options HEATING OPTION WATTAGE Electrical LINE VOLTAGE MAXIMUM AMPERAGE WALL SOCKET CONFIGURATION RECEPTACLE NUMBER ELECTRICAL HEAT OPTIONS...
- Page 12 Product information...
- Page 13 Dimensional drawings...
- Page 14 Options and Accessories Hard Wire kit –...
- Page 19 Side View Inside Wall Female Drain Fitting 3/4" (External drain) 90° Elbow Internal Drain Attach PVC to the unit's female 3/4" NPT drain connector. Local codes may apply. Side View Inside Wall Female drain fitting 3/4" (Internal drain)
- Page 20 UNIT INSTALLED` THROUGH FRONT OF CASE UNIT INSTALLED THROUGH SIDE OF CASE...
- Page 22 Condensate Drain Installation Internal Drain Installation An internal drain can be field installed (by others) on the bottom of the to allow condensate to drain into an internal drain system inside of the building. Locate the drain so that it will be on the room side of the wall when the cabinet wall sleeve is installed.
-
Page 23: Stamped Rear Grille
Rear Grille Installation Instructions Stamped Rear Grille STANDARD GRILLE INSIDE WALL PULL FORWARD TO INSERT SCREW HEADS INTO ANGLE THE GRILLE KEYHOLE SLOTS THROUGH THE OPENING AT BACK OF WALL SLEEVE SECURE THE GRILLE TO THE WALL SLEEVE BY TIGHTENING SCREW HEADS IN HOLES. -
Page 24: Architectural Rear Grille
Rear Grille Installation Instruct Architectural Rear Grille STUD HEX NUT WASHER ARCHITECTURAL GRILLE INSTALL THE FOUR THREADED STUDS INTO THE THREADED OPEN- INGS ON THE INSIDE FACE OF THE GRILLE. INSTALL WASHERS AND HEX NUTS TO THE END OF EACH STUD. ARCHITECTURAL GRILLE INSIDE... -
Page 25: Chassis Installation
Chassis Installation Top View Top View 3 4" -1/2" -1/2" Side View External... - Page 26 Information for Heat Pump units Heat Pump Features...
-
Page 27: Electrical Installation
Electrical Installation HARDWIRE KIT LCDI CORDS TAC WIRE HARNESS KIT VOLTAGE MEASUREMENTS OPERATING VOLTAGE VOLTAGE UTILIZATION RANGE UNIT VOLTAGE RATING MINIMUM MAXIMUM... - Page 28 Wiring Diagram...
- Page 29 Wiring Diagram...
- Page 30 System Controls and Management USER INTERFACES Wall Thermostats See pages 3 & 3 for full details Front Desk Control...
- Page 31 System Controls and Management (cont.) SYSTEM MANAGEMENT SOFTWARE Room Freeze Prevention Diagnostic Software Custom Operation High Temperature and Continual Room Compressor Protection Temperature Monitoring Low Temperature Compressor Protection...
- Page 32 Auto Restart Feature Freeze Protection Feature To prevent multiple units from powering up simultaneously after a power outage, there will Memory Recall Feature memory; computer memory that can retain Heater Safety Feature recalled after a power failure or if power is disconnected while servicing the unit.
- Page 33 Remote Thermostats Remote Wall Mounted Thermostats Remote Thermostat Control Wireless Wall Thermostat...
- Page 34 Remote Thermostat Interface...
-
Page 35: Control Board
Control Board Fuse A TRANS G IR PLUG S L2(N2) B 24 VAC – ACCESSORY H DISPLAY L2(N1) ODA- OUTDOOR AIR SENSOR C REMOTE THERMOSTAT U L2(N3) IDC – INDOOR COIL SENSOR D EGND – ACCESSORY V CNT K RA – RETURN AIR SENSOR DIP SWITCH 1 W FUSE ODC –... - Page 36 Performance Specifications PACKAGED TERMINAL COOLING 1.01 SYSTEM DESCRIPTION 1.02 QUALITY ASSURANCE 1.03 DELIVERY, STORAGE, AND HANDLING...
- Page 37 Performance Specifications (cont.) 2.01 EQUIPMENT...
- Page 38 Performance Specifications (cont.) 3.01 CONTROLS...
- Page 39 Performance Specifications (cont.) 4.0.1 HEAT PUMP OPERATION Heat pump units shall have the selected room temperature maintained by cycling either in the heat pump mode or electric strip heat. A heat pump unit with electric heat is switched from the heat pump mode to electric strip heat when the unit is on and the outdoor A temperature-sensing device shall be used to...
- Page 40 OF THIS SALE AND IS IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED. THIS WARRANTY DOES NOT APPLY TO ANY ACCESSORY THAT IS NOT A PART OF THE UNIT AS SHIPPED BY ISLANDAIRE THIS WARRANTY APPLIES ONLY TO THE ORIGINAL EQUIPMENT AT THE ORIGINAL INSTALLATION LOCATION. PROOF OF PROPER, ROUTINE MAINTENANCE WILL BE REQUIRED IN ORDER TO MAINTAIN EXTENDED WARRANTY.
- Page 41 EZ R EPLACEMENT UIDE Original Model Sleeve Sleeve Original Model Sleeve Sleeve Height Width Model Height Width Model Amana® Keeprite® PT 42 x 16 Series Climette 18 5/16 PB 26 x 16 Series Seasonall 18 5/16 American Air Filter® Lennox® Enersaver Type 16 37 1/2 PTEIA Series...
