3. Troubleshooting
3.3 Troubleshooting (Concerning engine and fuel injection
equipment)
Malfunctions
The engine does not operate
1. Fuel oil is not injected from the
injection pump
2. Injection timing is incorrect
3. The nozzle does not operate
4. The engine operates but only
for short time
5. The engine "knocks"
Causes
1. There is no fuel oil in the fuel
tank
2. The fuel line from the fuel tank
is blocked
3. The fuel is clogged
4. There is air in the fuel filter or
the pump chamber
5. The accelerator linkage is not
properly connected
6. The magnet valve wiring is
broken or its armature is
sticking
7. The feed pump blades are
sticking, and therefore not
operating
8. The drive gear or woodruff key
is broken
1. The drive gear or belt
connections are incorrect
2. The injection pump is
incorrectly installed on the
engine
3. The roller holder assembly's
roller or pin is worn excessively
4. The plunger is worn excessively
1. The nozzle or nozzle holder is
functioning incorrectly
1. The pipe(s) to the injection
pump is blocked or the fuel filter
is clogged
2. The fuel oil contains air or water
3. The feed pump's delivery
quantity (or pressure) is
insufficient
1. The injection timing is too
advanced
2. The nozzle or nozzle holder is
functioning incorrectly
59
Remedies
Supply fuel and bleed the system
Clean or replace
Clean or replace
Bleed the system
Repair
Repair or replace
Repair or replace
Replace
Repair
Repair and adjust injection timing
Replace the assembly
Replace the distributor assembly
Inspect, then repair or replace
Clean or replace the pipe(s) or fuel
filter
Bleed of air or replace the fuel oil
Repair or replace
Readjust the timing
Inspect, then repair or replace
