Whip Mix Pro 200 Series Quick Start Manual

Pro 200 Series
QuickStart Guide
The furnace weighs approximately 50 pounds (25 kg). A four wheeled platform cart is recommended
if the final destination is more than a few feet away. Position the furnace with the Main Power Switch
closest to the front edge of its current surface. Slide one arm just underneath the table lift arm as close
to the chassis as possible. Use your other hand to grasp the back of the chassis just above the
vacuum inlet fitting. Raise the furnace two inches, keeping it over the work surface until your back and
arms confirm you are able to control the furnace without injuring yourself. Move slowly to the final
location and reverse the sequence to place the furnace.

Before Unpacking

Unpacking
Connecting Power and
Vacuum Pump
Placement of the Furnace
Control and Display
Familiarization
Front Panel Controls on Right Side of Panel
• Do not turn on AC Power until instructed to do so.
• Save all packing materials
• Ensure appropriate Power and Ventilation
• Open Box
• Remove Accessory Box
• Tilt box up and slide Furnace and fitted foam onto counter
• Remove Foam and Save Foam and Box
• Remove Orange Shipping Bar and Green Sheet
• Open Accessory Box
• Take Inventory
• Open Pump Box
• Connect Tubing to Pump – Observe Air Flow Arrows on Pump
• Connect output hose to Quick Cool Jet
• Connect input hose to Vacuum Barb
• Plug the Pump Power Cord into Furnace Outlet
Ensure Air Flow room and hoses not kinked
Place cooling tray nearby
Rotary Detent Knob
• Rotating knob scrolls menu selections and changes parameter
values
• Pressing center of knob selects menu items
• Up Arrow button raises lift table/firing tray
• Down Arrow button lowers lift table/firing tray
• Menu button brings up lists of main functions. Select a main function to enter
list of secondary functions
• Abort button aborts a running program and lowers the lift table.
