Safety Section; Quick Facts; Specification - handi quilter HQ 24 Fusion User Manual

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Please note: Do not operate your HQ Fusion™ quilting machine until you have completely read the information
contained in this manual. Please keep all packaging and order information for warranty purposes.
TM
1. The HQ Fusion is very heavy. Never attempt to lift it alone – always use two people when lifting.
2. Always unplug the HQ Fusion™ from the electrical outlet when performing any maintenance, changing the
needle, removing thread locks, or when left unattended.
3. Keep fingers away from all moving parts. Use caution around the needle or sharp external components.
4. Change the needle often. Do not use bent or dull needles.
5. Switch the power off when making any adjustments in the needle or bobbin area, such as threading the
needle, installing the bobbin case, or when oiling or cleaning.
6. Never drop or insert foreign objects into any opening.
7. The HQ Fusion™ should only be used indoors away from moisture.
8. The HQ Fusion™ should not be stored or used in extreme temperatures.
9. Use the HQ Fusion™ only for its intended use as described in this manual.
10. Use only attachments recommended by the manufacturer.
11. To disconnect from the wall outlet, push the switch to the off position, then remove the plug from outlet pulling
from the plug, not the cord. Never operate the HQ Fusion™ if the cord is damaged or not working correctly. If
a mechanical or electrical problem is encountered, return the HQ Fusion™ to the nearest authorized service
center or the manufacturer for examination, repair, electrical or mechanical adjustment.
12. It is not recommended that the HQ Fusion™ Quilting Machine be used with any machine quilting frame other
than those recommended or manufactured by Handi Quilter.
Sewing Speed – Manual Mode
Sewing Speed – Regulated Mode
Needle Bar Stroke
Sewing Foot Stroke/Lift
Needle System
Needle Sizes
Lubricating Oil & Greases
Dimensions of Sewing Machine Throat
Rate Voltage/Power Consumption
Power Consumption of LED Lights
Hook System
Bobbin Type
Motor Type
Automatic Needle Positioning
Disclaimer
Handi Quilter and its Representatives are in no way legally responsible or liable for
damage to the HQ Fusion
guidelines stated in this manual or when used on Machine Quilting Frames not
recommended by Handi Quilter.
HQ Fusion™ User Manual 1.0

Safety Section

Quick Facts

Description
™
when used improperly or not in accordance with the

Specification

110 – 2200 SPM
0 – Full Speed
35.3 mm
5 mm
135x7 Standard 134 R Long Scarf
14/90 – 19/120
Kluber Lubrication
9.625‖ x 24.00‖
90 – 264 V , 47 – 63 Hz, 400 Watts
AC
24 Watts
Custom Manufactured, Rotary, Large Bobbin
Class M
Brushless DC
Up and down, full stitch and half stitch
Page 1
