Videocon DIGI NEMO Owner's Manual page 8

VARIOUS FUNCTIONS
HOT-COLD WATER INLET
Selection into the hot water. cold water and warm water.
Method of setting
Press POWER ON/OFF button to switch on the power, and press TEMP button to choose.
If the light is flash. It is into the hot water.
If the light is light. It is into the warm water.
If the light is not flash. It is into the cold water.
WATER LEVEL SETTING
Washing with low level water and rinsing with high level water will help more clean
washing and completely rinsing.
Method of setting
Press WASH button to set wash time, press WATER LEVEL button to set water level
for wash, press RINSE button to set rinse type and rinse times. Then press
WATER LEVEL to set water level for rinse, press SPIN button to set spin time, press
START/PAUSE button to start. By this, wash and rinse will work according to the water
levels set separately.
REMEMBER FUNCTION
When select NORMAL, CUSTOM or HEAVY DUTY, 15 seconds after starting,
the machine will remember this program and starts same next time working.
?This function is not available for DELICATE/BLANKET course.
?PRESET and WATER LEVEL will not be remembered.
?The Soak, Wash, Rinse and Spin for CUSTOM program could be remembered.
CHILD LOCK FUNCTION
Method of setting
Press POWER ON/OFF button to switch on the power, and press COURSE button
for 4 seconds till a sound from buzzer. To restore it, repeat above .
¡¤ W hen setting child lock, all the button on control are locked and can't be operated until
relive child lock.
TWO CLEAN STEPS FUNCTION
The washer will start washing when water to the level below 2 levels as set. By this,
the washer starts working with more density of detergent.
¡¤ T his function won't be effected when select level 1 or level 2 water, and DELICATE
or BLANKET course.
¡¤ W hen SOAK is selected, this function will not be effected after soaking.
13
Press the TEMP button.
Trouble Indication
When the following problems occur,the microcomputer will detect the abnormal condition
and an electronic buzzer sounds for approximately 10 seconds and the indicators flash as
shown below. At the same time,the washer stops operation.
Kind of Trouble
Trouble Indication
The washer
does not work
at all.
Water does not
flow into the
Wash/Spin Tub.
Water does not
drain out.
The washer
does not spin.
The buzzer
keeps beeping.
Other troubles.
NOTE: The trouble indicators can be released by pressing the START/PAUSE button
once if you want to release the emergency stop.
Then press the START/PAUSE button again to restart the operation.
NO TROUBLE CONDITIONS
1.During Washing or Rinsing, still there is Water inletting. This is possibly automatic water
adding due to water level decrease.
2.Spin tub turns or stops timely at the beginning of spinning. This is intermittent spinning
for better spin effect.
3.Water inletting and rinsing sometimes during spinning. This is automatic lean-correction
due to clothe is not equally inside.
4.There is sound like water flow after spinning. This is the sound of balance liquid in
Balance ring. It is for reducing vibration of spinning.
5.Control panel keeps warm after power off, this is caused by Remembering circuitry
working.
6.Power off during working and the washer could not continue working. Should set the
program again.
Where to Check
Press the POWER ON/OFF button.
Press the START/PAUSE button.
Press the PRESET button.
Check whether power failure occurs.
Check whether the fuse or circuit breaker has
been activated.
Turn the water supply faucet on.
Check whether the water supply has been cut off.
Check whether the metal filter of the Water Inlet
is clogged.
Check the washer has been freezing.
Check whether water pressure is too low.
Put down the Drain Hose from the hookhole.
Check the Drain Hose for any obstructions.
Check whether the Drain Hose is clogged.
Check whether the Drain Hose rises too high off
the ground.
Check whether the laundry is clumped on one
side of the Wash/Spin Tub.
Check whether the washer is on the level surface.
Close the Washer Lid.
Check whether the CHILD LOCK is set.
Close the Washer Lid.
Press the POWER ON/OFF button to turn off the
power, call your service-person or dealer.
14
