Icom IC-M402 Service Manual page 23

6-2 MH-127
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1140009280 S.IC
IC2 1110001810 S.IC
IC3 1110004490 S.IC
IC4 1120002830 S.IC
IC5 1180000420 S.IC
IC6 1180001250 S.IC
IC7 1110004710 S.IC
IC8 1130007420 S.IC
IC9 1130006220 S.IC
Q1 1560000810 S.FET
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q4 1590001390 S.FET
Q5 1590000430 S.TRANSISTOR DTC144EUA T106
Q6 1590000980 S.TRANSISTOR DTB123EK T147
Q9 1560000810 S.FET
Q10 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q11 1510000510 S.TRANSISTOR 2SA1576A T106R
Q12 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D1 1750000130 S.DIODE
D2 1160000060 S.DIODE
D3 1750000550 S.DIODE
X1 6060000750 S.CERAMIC
R1 7030000270 S.RESISTOR
R2 7030000270 S.RESISTOR
R3 7030000280 S.RESISTOR
R6 7030003560 S.RESISTOR
R7 7030003560 S.RESISTOR
R8 7030003560 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003680 S.RESISTOR
R11 7030003680 S.RESISTOR
R12 7030003680 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003680 S.RESISTOR
R15 7030003680 S.RESISTOR
R16 7030003680 S.RESISTOR
R17 7030003680 S.RESISTOR
R18 7030003680 S.RESISTOR
R19 7030003800 S.RESISTOR
R20 7030003540 S.RESISTOR
R21 7030003630 S.RESISTOR
R22 7030004120 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003450 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7510001150 S.THERMISTOR NTCCM1608 4BH 103KC
R27 7030003560 S.RESISTOR
R28 7030004120 S.RESISTOR
R29 7030003560 S.RESISTOR
R30 7030003590 S.RESISTOR
R31 7030003560 S.RESISTOR
R32 7030004120 S.RESISTOR
R33 7030003560 S.RESISTOR
R34 7030003440 S.RESISTOR
R35 7030003440 S.RESISTOR
R36 7030003560 S.RESISTOR
R37 7030003600 S.RESISTOR
R38 7030003580 S.RESISTOR
R39 7030003680 S.RESISTOR
R40 7030003760 S.RESISTOR
R41 7030003680 S.RESISTOR
R42 7030003570 S.RESISTOR
R43 7030003490 S.RESISTOR
R44 7030003680 S.RESISTOR
R45 7030003680 S.RESISTOR
R46 7030003620 S.RESISTOR
R47 7030003760 S.RESISTOR
R50 7030003680 S.RESISTOR
R51 7030003610 S.RESISTOR
R52 7030003630 S.RESISTOR
R53 7030003680 S.RESISTOR
DESCRIPTION
µPD78F9418AGK-9EU (FX-2345D)
TA7368F (TP1)
M62429FP 700C
NJM2125F-TE1
TA78L05F (TE12R)
TA7808F (TE16L)
S-80928ANMP-DDR-T2
TC7W14FU (TE12L)
TC4W53FU (TE12L)
2SK1069-4-TL
2SJ144-Y (TE85R)
2SK1069-4-TL
DA204U T107
DAN202U T107
1SS355 TE-17
CSTCC4.91MG
MCR10EZHJ 120 Ω (121)
MCR10EZHJ 120 Ω (121)
MCR10EZHJ 150 Ω (151)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R54 7030003440 S.RESISTOR
R55 7030003640 S.RESISTOR
R56 7030003440 S.RESISTOR
R57 7030003520 S.RESISTOR
R58 7030003280 S.RESISTOR
R59 7030003580 S.RESISTOR
R60 7030003560 S.RESISTOR
R61 7030003630 S.RESISTOR
R62 7030003640 S.RESISTOR
R63 7030003560 S.RESISTOR
R64 7030003510 S.RESISTOR
R65 7030003800 S.RESISTOR
R66 7030003800 S.RESISTOR
R67 7030003800 S.RESISTOR
R68 7030003320 S.RESISTOR
R69 7030003320 S.RESISTOR
R70 7030003260 S.RESISTOR
R75 7030000180 S.RESISTOR
R76 7030000180 S.RESISTOR
R77 7030000180 S.RESISTOR
C1 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C3 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C4 4030006900 S.CERAMIC
C5 4030006900 S.CERAMIC
C6 4030006900 S.CERAMIC
C7 4030011600 S.CERAMIC
C9 4030006900 S.CERAMIC
C10 4030011600 S.CERAMIC
C11 4030011600 S.CERAMIC
C12 4030012600 S.CERAMIC
C13 4030008920 S.CERAMIC
C14 4030011600 S.CERAMIC
C15 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C16 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C17 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C18 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C22 4030006900 S.CERAMIC
C23 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C24 4030012600 S.CERAMIC
C25 4030006900 S.CERAMIC
C26 4030012600 S.CERAMIC
C27 4030006850 S.CERAMIC
C28 4030011600 S.CERAMIC
C29 4030006860 S.CERAMIC
C30 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C31 4030011810 S.CERAMIC
C32 4030007090 S.CERAMIC
C33 4030012600 S.CERAMIC
C34 4030011600 S.CERAMIC
C35 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C36 4030011600 S.CERAMIC
C37 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C38 4030011600 S.CERAMIC
C39 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C40 4030011600 S.CERAMIC
C41 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C42 4030008890 S.CERAMIC
C44 4030011600 S.CERAMIC
C45 4030006900 S.CERAMIC
C46 4030011600 S.CERAMIC
C47 4030006850 S.CERAMIC
C50 4030006860 S.CERAMIC
C51 4030007090 S.CERAMIC
C52 4030007090 S.CERAMIC
C53 4030006900 S.CERAMIC
C54 4030012600 S.CERAMIC
J1 6510019420 S.CONNECTOR B8B-ZR-SM3-TF
J2 6510021440 S.CONNECTOR B6B-ZR-SM3-TF
DS1 5030001900 LCD
DS2 5040002660 S.LED
DS3 5040002660 S.LED
DS4 5040002310 S.LED
DS5 5040002660 S.LED
DS6 5040002660 S.LED
6 - 6
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 330 V (33 Ω)
MCR10EZHJ 22 Ω (220)
MCR10EZHJ 22 Ω (220)
MCR10EZHJ 22 Ω (220)
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C2012 JB 1A 105M-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1E 103K-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1A 224K-T-N
C1608 CH 1H 470J-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 273K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1E 103K-T-A
C2012 JB 1A 105M-T-A
A0119 LCD36*28.5
FY1101F-TR (LED)
FY1101F-TR (LED)
SML-311YTT86
FY1101F-TR (LED)
FY1101F-TR (LED)
S.=Surface mount
