Icom IC-M402 Service Manual page 19

[LOGIC BOARD]
REF ORDER
NO. NO.
EP1 0910053453 PCB
EP2 8930054970 LCD CONTACT SRCN-2438-SP-N-W
[VR-A BOARD]
REF ORDER
NO. NO.
R1 7210002350 VARIABLE
W1 8900010510 CABLE
EP1 0910053462 PCB
[VR-B BOARD]
REF ORDER
NO. NO.
R1 7210002360 VARIABLE
EP1 0910053472 PCB
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110003200 S.IC
IC2 1130007610 S.IC
IC3 1150001540 IC
IC4 1130008090 S.IC
IC5 1130008090 S.IC
IC6 1110003650 S.IC
IC7 1110002680 S.IC
IC8 1180001070 S.IC
IC9 1110003090 IC
Q1 1580000660 S.FET
Q2 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q4 1590000430 S.TRANSISTOR DTC144EUA T106
Q5 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q6 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q8 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q9 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q10 1530002240 S.TRANSISTOR 2SC3775-3-TB
Q11 1530003710 S.TRANSISTOR 2SC3268 (TE12L)
Q12 1520000380 TRANSISTOR
Q14 1590000430 S.TRANSISTOR DTC144EUA T106
Q15 1590000670 S.TRANSISTOR FMW1 T148
Q16 1590000430 S.TRANSISTOR DTC144EUA T106
Q17 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q18 1590000430 S.TRANSISTOR DTC144EUA T106
Q19 1590000720 S.TRANSISTOR DTA144EUA T106
Q20 1560000810 S.FET
Q21 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q22 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q23 1590000430 S.TRANSISTOR DTC144EUA T106
Q24 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q25 1590000430 S.TRANSISTOR DTC144EUA T106
Q26 1590000430 S.TRANSISTOR DTC144EUA T106
Q27 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q28 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
DESCRIPTION
B 5584C
DESCRIPTION
TP96N97N15F-10KA-1301
OPC-1044
B 5585B
DESCRIPTION
TP96N97-15F-10KB-1301
B 5586B
DESCRIPTION
TA31136FN (EL)
µPD3140GS-E1 (DS8)
M57710-A/SC-1302
BU4066BCFV-E1
BU4066BCFV-E1
NJM2211M-TE1
NJM2902M-T1
TA7805F (TE16L)
LA4425A
3SK272-(TX)
2SB1143 S
2SK1069-4-TL
[MAIN UNIT]
REF ORDER
NO. NO.
D1 1790000620 S.DIODE
D2 1790000620 S.DIODE
D3 1720000370 S.VARICAP
D4 1720000370 S.VARICAP
D5 1790000620 S.DIODE
D6 1790000620 S.DIODE
D7 1750000550 S.DIODE
D8 1790000690 S.DIODE
D9 1790000690 S.DIODE
D10 1710001080 DIODE
D11 1790000700 DIODE
D12 1750000550 S.DIODE
D14 1750000130 S.DIODE
D15 1710001080 DIODE
D16 1790001210 S.DIODE
D19 1790000620 S.DIODE
D20 1790000620 S.DIODE
D21 1790000660 S.DIODE
FI1 2010002420 MONOLITH
FI2 2010002420 MONOLITH
FI3 2020001680 CERAMIC
X1 6070000210 S.DISCRIMINATOR CDBCA450CX24
X2 6050010800 S.XTAL
L1 6200003050 S.COIL
L2 6200002410 S.COIL
L3 6200002430 S.COIL
L4 6200003090 S.COIL
L5 6200008190 S.COIL
L6 6200009180 S.COIL
L7 6200009180 S.COIL
L8 6200009180 S.COIL
L9 6200002430 S.COIL
L10 6200002430 S.COIL
L11 6170000230 COIL
L12 6110001600 COIL
L13 6110001600 COIL
L14 6110001670 COIL
L15 6110001600 COIL
L16 6200007760 S.COIL
L17 6200007760 S.COIL
L19 6200007760 S.COIL
L20 6200007760 S.COIL
L21 6200007760 S.COIL
L22 6200007760 S.COIL
L24 6200007760 S.COIL
L25 6200007760 S.COIL
L26 6200004720 S.COIL
L27 6200003550 S.COIL
L28 6200009150 S.COIL
L29 6200009170 S.COIL
L30 6200002600 S.COIL
L31 6200002600 S.COIL
R3 7030003560 S.RESISTOR
R5 7030003560 S.RESISTOR
R6 7030003200 S.RESISTOR
R7 7030003500 S.RESISTOR
R8 7030003480 S.RESISTOR
R9 7030003460 S.RESISTOR
R10 7030003460 S.RESISTOR
R11 7030003680 S.RESISTOR
R12 7030003460 S.RESISTOR
R13 7030003400 S.RESISTOR
R14 7030003450 S.RESISTOR
R15 7030003400 S.RESISTOR
R16 7310002760 S.TRIMMER
R17 7510001050 S.THERMISTOR NTCCM1608 4LH 333KC-T
R18 7030003620 S.RESISTOR
R19 7030003430 S.RESISTOR
R20 7030003740 S.RESISTOR
R21 7030003390 S.RESISTOR
R22 7030003460 S.RESISTOR
R25 7030003320 S.RESISTOR
R26 7030003380 S.RESISTOR
R27 7030003460 S.RESISTOR
6 - 2
DESCRIPTION
MA77 (TX)
MA77 (TX)
HVU350TRF
HVU350TRF
MA77 (TX)
MA77 (TX)
1SS355 TE-17
HSM88ASR-TR
HSM88ASR-TR
XB15A308
DSA3A1
1SS355 TE-17
DA204U T107
XB15A308
1SS375-TL
MA77 (TX)
MA77 (TX)
MA728 (TX)
21R15AB (FL-310)
21R15AB (FL-310)
ALFY450E
CR-659 (21.25 MHz)
NL 322522T-R82J-3
NL 252018T-056J
NL 252018T-082J
NL 322522T-2R7J-3
0.25-1.9-8TL 80N
ELJRE R10J-F3
ELJRE R10J-F3
ELJRE R10J-F3
NL 252018T-082J
NL 252018T-082J
LW-25
LA-243
LA-243
LA-253
LA-243
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
LQN21A 82NJ04
MLF1608D R10K-T
MLF1608A 4R7K-T
ELJRE 82NJ-F3
ELJRE 47NJ-F2
NL 252018T-047J
NL 252018T-047J
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
RV-152 (RH03A3AJ4X0HA) 223
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
S.=Surface mount
