- Page 1 Hikvision Technical Manual DS-8000HTI-S Series Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Hikvision Technical Manual Contents 1. Overview 2. Model Description 3. Features 4. Specifications ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 4 Hikvision Technical Manual 1. Overview DS-8000HTI-S series Network Digital video Recorder is an excellent digital surveillance product adopts embedded MCU (Microprocessor Control Unit) and an embedded Real-Time Operating System (RTOS), along with the most advanced technology in the Information technology Industry such as video and audio encoding/decoding, hard disk recording and TCP/IP transmission.
-
Page 5: Model Description
DS-8016HTI-S: 16-ch video input and 16-ch audio input. Each channel can max support DCIF encoding resolution real time. It has 8 SATA interfaces Note: The default DVRs are without HDD or CD-R/W. ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 6: Preview And Playback
Support video signal loss alert. Support 2-ch synchronous playback. Support play forward, backward, pause, frame-by-frame, etc Support play back by files or by time/date Displays local record status ©2006 – 2010 by HIKVISION. All rights reserved. - Page 7 Support bi-directional audio or one-way audio broadcast Support IE preview and configuration Support SADP protocol Support remote log query 3.5 Development support: Provide network SDK (Software Development Kit) Provide client demo source code ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 8: Specifications
Voice talk 1 channel, BNC (2.0Vp-p, 1KΩ) Communication 1 RJ45 10M/100M Adaptive Ethernet Interface interface 1 RJ45 RS232 Port RS-485 Port 1 Port (T+, T-, R+, R-) Keyboard 1 Port (D+, D-) interface ©2006 – 2010 by HIKVISION. All rights reserved. - Page 9 ≤70W (without HDD or DVD-R/W) consumption Working -10℃ ~ +55℃ temperature Working 10% ~ 90% humidity Size 470mm(D)*441mm(W)*90mm(H) Weight ≤8Kg (without HDD or DVD-R/W) PAL: 176×144(QCIF), 352×288(CIF), 704×288(2CIF), 528×384(DCIF), 704×576(4CIF); NTSC: 176×120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704×480(4CIF). ©2006 – 2010 by HIKVISION. All rights reserved.
