CPU Core Speed Derivation Procedure

If CPU Clock
Core/Bus ratio
then CPU core speed

CPU Clock Frequency Selection through BIOS

The hardware configuration for CPU clock frequency of the motherboard
is set to 100MHz by default. Therefore, to make a 133MHz CPU run at
133MHz when it is installed on the board, you have to adjust the CPU clock
frequency in the BIOS setup utility.
To set the clock frequency for the installed CPU, refer to Frequency/
Voltage Control in Chapter 3. BIOS Setup.
MSI Reminds You...
Replacing CPU
While replacing the CPU, always turn off the ATX power sup-
ply or unplug the power supply's power cord from grounded
outlet first to ensure the safety of CPU.
Overclocking
This motherboard is designed to support overclocking.
However, please make sure your components are able to toler-
ate such abnormal setting, while doing overclocking. Any at-
tempt to operate beyond product specifications is not
recommended. We do not guarantee the damages or risks
caused by inadequate operation or beyond product
specifications.
= 100MHz
= 14
= Host Clock x Core/Bus ratio
= 100MHz x 14
= 1.4 GHz
