Machine Models Compatible for Con-
nection with this Product
DLA-HD2KU
This product (LD-HD2KU) is exclusively for the
above-mentioned model. The performance cannot
be guaranteed when using with other models.
This processor is used as a dedicated machine and
this manual (instruction manual) may contain de-
scription of features as well as specifications not
used by the processor.
DLA-HD2KE
This product (LD-HD2KE) is exclusively for the
above-mentioned model. The performance cannot
be guaranteed when using with other models.
This processor is used as a dedicated machine and
this manual (instruction manual) may contain de-
scription of features as well as specifications not
used by the processor.
DIGITAL VIDEO PROCESSOR
LD-HD2KU/LD-HD2KE
OFF
VIDEO
S-VIDEO
RGB
YCrCb
PASS-T
PASS-TX
MENU
PROFILE
STORE
1
2
3
4
5
6
7
8
9
0
BRIGHTNESS
CONTRAST
COLOR
TINT
DETAIL
ANAMORPHIC
4:3
LETTERBOX
®
®
INSTRUCTIONS
For customer Use:
Enter below the Serial No. which is located
on the side panel of the cabinet. Retain
this information for future reference.
Model No.
LD-HD2KU
Serial No.
LCT1679-001A

Advertisement

Table of Contents

   Related Manuals for JVC D-ILA LD-HD2KE

   Summary of Contents for JVC D-ILA LD-HD2KE

  • Page 1 DLA-HD2KE This product (LD-HD2KE) is exclusively for the above-mentioned model. The performance cannot be guaranteed when using with other models. This processor is used as a dedicated machine and...
  • Page 2: Safety Precautions

    FCC INFORMATION (U.S.A. ONLY) CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules.
  • Page 3 – Do not overload wall outlets, extension cords, or conve- nience receptacles on other equipment as this can result in a risk of fire or electric shock. – Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS ... 2 QUICK START ... 5 INSTALLATION ... 6 SETUP ... 8 IR REMOTE/OSD ... 10 RS232 ... 13 HELP MENUS ... 16 SPECIFICATIONS ... 17...
  • Page 5: Quick Start

    QUICK START Connection with Other Devices Before connecting to other devices, ensure to turn off the power supply of the device to be connected with the digital video processor. Connecting to a Projector ● Read through the projector’s instruction manual thoroughly. ●...
  • Page 6: Installation

    Note on DVDs: For proper aspect ratio and to insure the highest quality image from the DVD player, be sure to set the DVD screen shape to 16:9 in the DVD player’s Setup menu. See the DVD player’s owner’s manual for details.
  • Page 7: Connecting Hdtv Satellite Receivers

    Installation (continued) DVI Output: Digital output interface for compatible dis- plays. All processed analog and digital in- puts are output to this connector as well as computer scan rates when the pass-through input is selected. Maximum cable length is 50ft with a high quality DVI cable. For longer lengths a distribution system or fiber optic system must be used.
  • Page 8: Setup

    SETUP 1 2 3 FRONT PANEL CONTROL 1 Firmware Reset: Push a small paper clip into this opening to reset the unit’s CPU. ● Use this reset only if the unit will not respond to commands. It will not erase custom settings. Use the Factory Restore command in the Setup Menu to completely reset firmware.
  • Page 9 Setup (continued) SET : BLACK LEVEL (For setting the black level) 7.5 IRE / 0 IRE (Default) For setting the black signal level of the video signal. When the video signal is “7.5 IRE Setup”, set to “7.5 IRE”. SET : DVI Input Level (For setting the gray scale) 16-235 / 0-255 (Default) OUTPUT FORMAT (ANALOG) RGB (Default) / YPrPb...
  • Page 10: Ir Remote/osd

    IR REMOTE/OSD IR REMOTE AND OSD OPERATION This unit is now shipped with a simplified remote control that allows for direct access to most commands used to control the processor. Adjustments can be made three different ways: 1. Press the Menu button to activate the OSD and use the Function and Value keys to make changes.
  • Page 11 Input Menu INPUT PICTURE DISPLAY FORMATS INPUTS ASPECT ANAMORPHIC PROFILE RECALL F 1 2 3 4 STORE Formats 1. Input Select: OSD Video-S-Video- RGB-YCrCb-DVI ● The Pass-Thru input cannot be selected from the OSD since an OSD is not available on that input. Use the Input button on the remote to select it.
  • Page 12 Osd (continued) Color Factory 50 Adjust the color density of the picture image. Tint Factory 50 Tint is not available with YPrPb or PAL sources Detail Factory 4 ● The Detail circuit is a powerful tool for image quality. The settings have been optimized for the output scan rate and resolution.
  • Page 13: Rs232

    RS232 Patterns Menu The best approach to system setup is to use a DVD that offers the proper test patterns. This way, the system is aligned for the entire signal path. If a test DVD is not avail- able, then use the internal test patterns provided in this unit.
  • Page 14 RS232 (continued) Following the header, a comma is used to delimit the header from the command. All the commands with their descriptions are listed below. All the text strings are terminated with a carriage return (0x0d or 13). Maximum command string length is 250 characters.
  • Page 15 SETUP COMMANDS (Normally not controlled by RS232) OPTIONS OR RANGE COMMAND (0-192) (0-252) (0-255) BLT# 1=On 0=OFF 1=On 0=OFF EXTD EXTE (0-50) 25 default (0-200) (0-1) [0=RGB, 1=YPrPb] OSDOFF OSDON 0=Analog, 1=Digital OUTMOD 000-192 SETFT STPP# STNP# SRHELP 000-192 (0=Neg 1=Pos) VPOL# 0=4:3, 1=Widescreen, 2=Wide 4:3 NTSC SCAN RATE LIST (USE ONLY BY QUALIFIED TECHNICIAN!)
  • Page 16: Help Menus

    HELP MENUS TEST PATTERN OFF REVERSE COLOR BARS LUMA RAMP CR RAMP GREEN SCREEN TP10 BLUE SCREEN TP12 ACTIVE BORDER TP14 WHITE WINDOW Output Scan Rate 1920 x 540P 720 x 576P 800 x 600P 1280 x 720P 1280 x 720P 1024 x 768P 1024 x 768P 1366 x 768P...
  • Page 17: Specifications

    SPECIFICATIONS Model Name/ Article Name LD-HD2KU/LD-HD2KE Digital Video Processor Colour System NTSC, PAL (Auto switching) Video Input Input Terminals VIDEO 1-line, BNC x 1 1-line, mini-DIN 4 pin x 1 R,G,B,C-SYNC 1-line, BNC x 4 Y, Pr, Pb 1-line, BNC x 3...
  • Page 18 MEMO...
  • Page 20 ® VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan 0504-SW-VP © 2004 VICTOR COMPANY OF JAPAN, LIMITED...
