SERVICE MANUAL
XV-M565BK/M567GD
Contents
the traverse unit
DVD PLAYER
1-2
1-3
1-4
1-5
1-6
This service manual is printed on 100% recycled paper.
COPYRIGHT
2000 VICTOR COMPANY OF JAPAN, LTD.
Areas suffix
J ----------------------------- U.S.A.
C -------------------------- Canada
XV-M565BK/M567GD
1-21
1-24
1-25
1-31
1-34
No.20845
Jun. 2000
