- Page 1 TRITON routing switcher Multimedia Router 8x8 Product model no. TTN-BAV-0808 INSTALLATION MANUAL MANUAL PART NO. 071-8242-00 Rev. 0 MARCH 18, 2003 the most watched worldwide...
- Page 2 FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General Specifications 1.1.1 Video Specifications 1.1.2 (Optional) Audio Specifications 1.1.3 Panel Specifications 1.1.4 General Specifications Connection drawing Power connection Connecting the BAV-0808 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection... - Page 4 Control panel operation Front panel drawing PANEL ENABLE button V/A TOGGLE button Operating crosspoints TAKE function Programming of SALVOS (Pre-sets) Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 9.1.1 Binary Code 9.1.2 Echo 9.1.3 RS-422 Matrixes 9.1.4...
-
Page 5: Electromagnetic Radiation Notice
Electromagnetic Radiation Notice The following information is given to note compliance with the United States Government Federal Communications Commission (FCC) Rules (47 CFR Part 15) designed to limit interference to radio and TV reception. The ruling establishes measurement procedures and frequency criteria for Class A computing devices (commercial and industrial applications) with the following conduction and radiation limits: CLASS A COMPUTING DEVICE: CONDUCTION LIMIT (Part 15.812) Frequency (MHz) -
Page 6: Hardware Warranty And Software License
Hardware Warranty and Software License Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 18/03/03 Initial Revision... -
Page 9: General
BAV-0808 Rev. 0 1 General The Media-8 is an RGBHV Analogue Video + Stereo Analogue Audio (optional) 8x8 Router for Multimedia applications. The Video Router has seamless tri-step switching, or vertical interval switching, and a large signal bandwidth, which provides high performance up to 1600x1200 resolution. The Audio Router has balanced inputs and outputs, and audio breakaway allows selecting audio independent from video. -
Page 10: Optional) Audio Specifications
BAV-0808 Rev. 0 1.1.2 (Optional) Audio Specifications Frequency response: 20Hz-100kHz ± 0.1dB Crosstalk: > -100dB Click noise: < 80dBqp THD+N: < 0.003% SNR: > 100dB ref. to 0db 20Hz-20kHz Number of inputs: 8 (Stereo) true balanced Input impedance: > 10k ohms CMRR: >... -
Page 11: Power Connection
BAV-0808 can also be delivered with DC ±15V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information. -
Page 12: Ncb Connection
Network devices, with 5-PIN DIN connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router. -
Page 13: Pin-Out And Cable Type
BAV-0808 Rev. 0 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, including the BAV-0808, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data... -
Page 14: Rj45 To 5-Pin Din Converter
BAV-0808 Rev. 0 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45. - Page 15 BAV-0808 Rev. 0 o RS-422 Data + CP for data on Level 3 o Universal Control Panel to control all devices above, with user configurable default level. • Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. Triton - RCS •...
-
Page 16: Router Configuration
BAV-0808 Rev. 0 5 Router configuration There are 8 DIP switches on the rear side of the BAV-0808. They have the following meaning: Router level Switches 1 - 3 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. -
Page 17: Disconnect Allowed
BAV-0808 Rev. 0 Default timing mode is No VIT. When RGB switching is applied, the Video routers 1, 2, and 3 will be switched in a special manner. When a new status is received, via buttons in front, or serial connections, the video switchers 4, and 5, as well as the audio, will be connected to the new input immediately. -
Page 18: Programming Of Restrictions
BAV-0808 Rev. 0 Programming of restrictions If the user enables the Restrictions option, the previously programmed restrictions will be fetched from the on-board memory during power-up. Putting the panel in “Restrictions Programming mode” may program new restrictions. This is done, starting from Panel Disable state, by pushing and holding “V/A toggle”, “Take On/Off”... -
Page 19: Connecting Signal Cables To The Bav-0808
BAV-0808 Rev. 0 6 Connecting signal cables to the BAV-0808 Connecting Video Signals The BAV-0808 router offers standard 75 ohms BNC connectors for video in- and outputs. All video inputs are terminated with 75 ohms. Connecting Audio Signals Below you will find our standard pin-out for DB25 audio contacts. This pin-out is used for both analogue and digital audio routers. -
Page 20: Control Panel Operation
BAV-0808 Rev. 0 7 Control panel operation The built-in panel in the BAV-0808 offers 8 input select buttons on the top row. The input buttons are equipped with two LED indicators for displaying both video and audio status during breakaway operations. -
Page 21: Take Function
BAV-0808 Rev. 0 TAKE function The BAV-0808 provides a TAKE function, which can be activated by pressing the TAKE ON/OFF button. The TAKE ON/OFF button will show green light if the TAKE function is activated. After selecting output and input like described under 7.4 the INPUT button and the TAKE button will start to blink. - Page 22 BAV-0808 Rev. 0 When programming the salvos, use the A/V Toggle button to program separate operations for video and audio (breakaway). When using breakaway, remember that only the chosen layer (video and/or audio) will be subject to switching when the setting is stored. Example: If only the red light is lit in the A/V Toggle button when the next output is selected, the video will be left unchanged for the previous output.
- Page 23 BAV-0808 Rev. 0 - Push “A/V Toggle”, and select A+V (Red + Green light), - Disconnect all inputs, i.e. No inputs are lit, - Repeat the last three lines for all outputs 3 – 8 too. Step 4. - Push “F3”, - Push “OUT1”, - Push “A/V Toggle”, and select A+V (Red + Green light), - Push “IN3”...
-
Page 24: Control And Connection Of Triton Systems, Interface Protocol
BAV-0808 Rev. 0 9 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 9.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. -
Page 25: Example: Several Units Connected By Ncb
BAV-0808 Rev. 0 9.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB. -
Page 26: Commands
BAV-0808 Rev. 0 Commands 9.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 27: Video Crosspoint Set Acknowledge
BAV-0808 Rev. 0 9.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
