DIGITAL VIDEO CAMERA
CAMERA VIDEO NUMERIQUE
GR-DVM1D
INSTRUCTIONS
MODE D'EMPLOI
For Customer Use:
Enter below the Serial Nos. of the
GR-DVM1U camcorder and the
AA-V80U AC Power Adapter/Charger.
The serial numbers are located on the
bottom of the GR-DVM1U and the
AA-V80U.
Model No.
GR-DVM1U/AA-V80U
Serial No.
LYT0002-0E9B
Advertisement
Table of Contents
Related Manuals for JVC GR-DVM1DU
Summary of Contents for JVC GR-DVM1DU
-
Page 1: Digital Video Camera
DIGITAL VIDEO CAMERA CAMERA VIDEO NUMERIQUE GR-DVM1D INSTRUCTIONS MODE D’EMPLOI For Customer Use: Enter below the Serial Nos. of the GR-DVM1U camcorder and the AA-V80U AC Power Adapter/Charger. The serial numbers are located on the bottom of the GR-DVM1U and the AA-V80U. - Page 2 Dear Customer, Thank you for purchasing this Digital Video Camera. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of this product. Using This Instruction Manual • All major sections and subsections are listed in the Table Of Contents ( pg.
-
Page 3: Important Product Safety Instructions
IMPORTANT PRODUCT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing. - Page 4 1. Accessories To avoid personal injury: • Do not place this product on an unstable cart, stand, tripod, bracket or table. It may fall, causing serious injury to a child or adult, and serious damage to the product. • Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.
-
Page 5: Safety Precautions
SAFETY PRECAUTIONS Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock. CAUTION! The following notes concern possible physical damage to the camcorder and to the user. -
Page 6: Provided Accessories
AC Power Adapter/Charger AA-V80U Remote control unit RM-V708U Battery pack BN-V812U Hand strap AUDIO/VIDEO cable (Docking Station to TV or VCR, RCA plug 4 RCA plug) S-VIDEO cable 3.5mm diameter 4-pole cable (x 2) Soft camera case CAM Stand Grip MiniDV Cassette Sun hood Tape 30 min... -
Page 7: Table Of Contents
CONTENTS PROVIDED ACCESSORIES GETTING STARTED Charging The Battery Pack ... 8 Installing The Battery Pack ... 9 Indoor Use ... 10 Using The CAM Stand ... 10 Clock (Lithium) Battery Insertion/Removal ... 11 Date/Time Settings ... 12 Loading/Unloading A Cassette ... 13 Recording Mode Setting ... -
Page 8: Getting Started
Charging The Battery Pack You can charge one battery pack at a time, or two consecutively. ATTACH Battery pack BN-V812U Charger indicator 2 Power lamp Charger indicator 1 SUPPLY POWER TO CHARGER Plug the AC Adapter/Charger's power cord in to an AC outlet. The power indicator comes ATTACH BATTERY/BATTERIES Make sure the + –... -
Page 9: Installing The Battery Pack
NOTES: If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the camcorder and charging stops. When using the AC Power Adapter/Charger, be sure to use the supplied power cord only. The AC Power Adapter/Charger is for use with the BN-V812U Battery Pack only. -
Page 10: Indoor Use
Power cord AC Power Adapter/Charger DC cord Core Filter Indoor Use When using the camcorder indoors, you can use the AC Adapter instead of a battery. SUPPLY POWER TO ADAPTER Plug the AC Adapter/Charger's power cord in to an AC outlet. SUPPLY POWER TO CAMCORDER Connect the AC Adapter to the camcorder. -
Page 11: Clock (Lithium) Battery Insertion/Removal
Clock (Lithium) Battery CR2025 Insertion/Removal This battery is necessary to operate the clock and to perform date/time settings. Open switch Battery cover OPEN BATTERY COVER 1 Slide the open switch on the battery cover. 2 Pull open the battery cover in the direction of the arrow. -
Page 12: Date/Time Settings
Date/Time Settings Date and time will automatically be recorded on tape at all times. It is your choice to display it or not during playback ( pg. 54) To set date and time follow the instructions from 1 to 5. LCD monitor WIDE MODE O FF... -
Page 13: Loading/Unloading A Cassette
Loading/Unloading A Cassette The camcorder needs to be powered up to load or eject a cassette. OPEN/EJECT switch Make sure the window side is facing out. OPEN CASSETTE DOOR Turn on the power, then slide the OPEN/EJECT switch in the direction of the arrow. The cassette cover releases. -
Page 14: Recording Mode Setting
monitor Recording mode indicator Hand Strap Attachment The provided Hand Strap helps you to keep a firm hold on the camcorder. Make sure you never hold the camcorder without using the Hand Strap. Eyelet Hand strap ATTACH HAND STRAP Slide the strap through the eyelet, pulling firmly to ensure secure attachment. -
Page 15: Sun Hood Attachment
Sun Hood Attachment The sun hood shields the LCD monitor from reflection so that the user can watch it with ease even under direct sunlight. It also helps protect the monitor from damage. LCD monitor Sun hood Lens Sun hood LCD monitor ATTACH SUN HOOD Mount the sun hood on the LCD monitor so... -
Page 16: Grip Attachment
Grip Attachment Use of the grip enables stable shooting. Bottom of the camcorder Tripod mounting socket Screw ALIGN Align the grip's screw with the camcorder's socket for tripod mounting, with Grip band When loading/unloading a cassette ..tilt the grip toward you. You can load/unload a cassette with the grip attached. -
Page 17: Remote Control Unit
Remote Control Unit You can use the RM-V708U to control the camcorder when it’s attached to the Docking Station. PAUSE IN connector ( ZOOM Buttons ( pg. 56) DISPLAY Button ( pg. 65) SHIFT Button ( pg. 56) SLOW Rewind/Forward Buttons ( pg. -
Page 18: Recording
Full Auto/Manual Operation The following chart shows you which functions are available in the Full Auto and Manual operation modes. According to the shooting mode selector position you have selected, "F.AUTO" or "MANUAL" appears in the upper left corner of the LCD monitor screen. -
Page 19: Basic Recording
Basic Recording You should already have performed the necessary preparations ( selector to "AUTO" and try recording that way before attempting to use more advanced features. NOTE: Before starting recording, make sure you set the date and time ( recording, you can display them during playback ( LCD monitor PUSH-OPEN OPEN LCD MONITOR... - Page 20 Recording From The Middle Of A Tape When removing a tape on which you were recording, or when you resume recording on a tape after playing back the recording previously made (without taking the tape out between recordings), perform this procedure.
- Page 21 Time Code During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from "00:00:00" (minute:second:frame).
- Page 22 Tape Remaining Indicator The time remaining on the tape is automatically monitored and displayed in the LCD monitor pg. 74). When the tape ends, “TAPE END” appears in the LCD monitor. If the LCD monitor indications are turned off ( remaining indicator appears when remaining time reaches 2 minutes.
- Page 23 LCD monitor IND/DISPLAY BRIGHT Brightness Control You can adjust the brightness of the LCD monitor by pressing the –/+ button. ADJUST BRIGHTNESS If you want to brighten the image... Press the "+" button. If you want to darken the image... Press the "–"...
- Page 24 Lens RECORDING Interface Shooting You can shoot yourself while viewing your own image in the LCD monitor. TILT LCD MONITOR UPWARD Open the LCD monitor and tilt it upward to 180 degrees so that it faces forward. START RECORDING Point the lens toward yourself and start recording.
- Page 25 Zoom Select any one of the three powers of magnification and get “closer” to the subject ( Simply set the zoom switch to either zoom in (toward “T”) or zoom out (toward “W”). The zoom speed is variable — the quicker you set the zoom switch, the quicker the zoom action. NOTE: Digital zoom (20x and 100x) cannot be used while the Video Echo effect ( Dissolve function (...
-
Page 26: Advanced Features
Snapshot Use your camcorder like a regular camera and take a snapshot, or several of them in succession. LCD monitor PUSH-OPEN Press SNAPSHOT during recording SNAPSHOT Press SNAPSHOT during Record/Standby mode OPEN LCD MONITOR Press the PUSH-OPEN switch and open the LCD monitor fully. - Page 27 Snapshot Search The Snapshot Search function enables you to quickly and easily access scenes recorded in the Snapshot mode, or scenes where Strobe was used. ENABLE SNAPSHOT SEARCH Set the Power Dial to “PLAY”. REWIND TAPE Press REW. Let the tape rewind to the begin- ning, where it stops automatically.
- Page 28 Scene Record a vacation or an important event in 5-second clips to keep the action moving. The 5-Second function may also be activated during Full Auto operation. While the 5-Second mode is activated, Fade/ Wipe ( pg. 34), P.AE/Effects ( LCD monitor PUSH-OPEN Dissolves during 5 second mode recording...
- Page 29 Self-Timer Once the camcorder is set, the camcorder operator can become part of the scene in a more natural way adding the final touch to a memorable picture. LCD monitor PUSH-OPEN OPEN LCD MONITOR Press the PUSH-OPEN switch and open the LCD monitor fully.
-
Page 30: Select Function
Menus The Recording Menu allows you to set these functions: Wide Mode, Zoom Magnification, Digital Image Stabilizer, Gain Up, Fade/Wipe ( White Balance ( pg. 44) . The following selection procedure applies to Wide Mode, Zoom Magnification, Stabilization and Gain Up . LCD monitor WIDE MODE O FF... - Page 31 SQUEEZE 100X CINEMA O FF WIDE MODE 20 X ZOOM D I S GA I N UP TO FADER / W IPE MENU TO P.AE / EFFECT MENU TO DATE / TIME MENU TO SYSTEM MENU W.BALANCE AUTO I T EM –/+ BUTTON SET MENU BUTTON WIDE MODE This recording mode is compatible with wide-screen...
- Page 32 System Menu The System Menu allows you to set the following functions: Scene, Beep/Tally, Wind Cut, Sound Mode, ID numbers, and Photo Frame. LCD monitor O FF WIDE MODE 20 X ZOOM D I S GA I N UP TO FADER / W IPE MENU TO P.
-
Page 33: Wind Cut
SCENE BEEP/TALLY W IND CUT SOUND MODE I D No . PHOTO FRAME I TEM –/+ BUTTON SET MENU BUTTON SCENE (5-Second Mode) To enable this mode, open the LCD monitor fully and turn the Power Dial to "5S" while pressing the lock button. -
Page 34: Start Recording
FADE/WIPE Effects Use these to spice up the transition from one scene to the next. You can also vary transitions from scene to scene. Select any one effect from the Fader/Wipe Menu. To use effects that don’t appear in the menu, exchange them ( pg. - Page 35 Fades and Wipes A scene gradually appears on a black or white screen (Fade In/Wipe In), or disappears, leaving a black or white screen (Fade Out/Wipe Out). Select Fade or Wipe at the Fader/Wipe Menu ( Select any one effect from the Fader/Wipe Menu. To use effects that don’t appear in the menu, exchange them ( pg.
- Page 36 Picture Wipe/Dissolve Combine the Picture Wipe and Dissolve functions for a professional transition effect. There are 6 Picture Wipe effects and 1 Dissolve effect. Select the Picture Wipe effect at the Fader/Wipe Menu ( Select any one effect from the Fader/Wipe Menu. To use effects that don’t appear in the menu, exchange them ( pg.
- Page 37 Random Variations RANDOM FADER: When this function is activated, the camcorder randomly selects the effect used in scene transition (from the Fade and Wipe effects). The camcorder chooses one of the fades/wipes at random. To customize the selection of Fade and Wipe Effects used with Random Variations, refer to the procedures on pg.
- Page 38 Exchanging FADE/WIPE Effects You can replace the 5 effects currently appearing in the menu with 5 others. After exchanging, the new effects appear in the Fader/Wipe Menu. LCD monitor WIDE MODE O FF 20 X ZOOM D I S GA I N UP TO FADER / W IPE MENU TO P .
- Page 39 Refer to page 34 on using the exchanged effects. pg. 35 WHITE FADER MOSAIC FADER SLIDE WIPE SHUTTER WIPE pg. 36 DISSOLVE SLIDE WIPE SHUTTER WIPE pg. 37 RANDOM FADER F ADER / W I P E CUSTOM I ZE WH I T E F ADER B L ACK F ADER D I SSOL VE...
- Page 40 P.AE/Effects You can choose any one of the effects from the P.AE/Effects Menu. In addition, you can exchange 5 of the 12 options that appear for other available effects ( LCD monitor P . AE / E FF EC T SEL ECT 1/250 SHUT T ER 1/250...
- Page 41 MONOTONE Like classic black and white films, your footage is shot in B/W. Used together with the Wide Cinema function, it enhances the “classic film” effect. SEPIA Recorded scenes have a brownish tint like old photos. Combine this with the Cinema mode for a classic look.
- Page 42 Exchanging P.AE/Effects You can replace 5 of the effects that appear in the menu with 5 others. Refer to page 40 on using the exchanged effects. LCD monitor WIDE MODE O FF 2 0 X ZOOM D I S GA I N UP TO FADER / W IPE MENU TO P .
- Page 43 Displaying The Date And Time During Recording You must first set the date and time (see “Date/Time Settings” Date/Time Menu. The Date/Time appears in the LCD monitor if the Shooting mode selector is set to “MANUAL”. The Date/Time is always displayed in the LCD monitor when the Shooting mode selector is set to “AUTO”.
- Page 44 White Balance Adjustment A term that refers to the correctness of color reproduction under various lighting. If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, the more advanced camcorder operator would prefer to control this function manually and achieve a more professional color/tint reproduction.
- Page 45 Manual White Balance Operation If the camera is operating in manual mode, perform a Manual White Balance when shooting under various types of lighting LCD monitor WIDE MODE O FF ZOOM 20 X D I S GA I N UP TO FADER / W IPE MENU TO P.AE / EFFECT MENU TO DATE / TIME MENU...
- Page 46 Manual Focus Adjustment The recorder, in most cases, adjusts the focus from 10 cm to infinity automatically. However, when focusing is difficult or when the subject is not in the middle of the LCD monitor, adjust the focus manually. Focus zone (Focus is adjusted at the center of the screen) FOCUS Manual focus indicator...
- Page 47 Exposure Control Usually this is adjusted automatically. However, when the background is too bright or too dark in compari- son with the subject, the exposure could be corrected manually. EXP. Exposure control indicator FOCUS PRO. EXP. IND/DISPLAY SELECT MODE First make sure the LCD monitor is open fully. Turn the Power Dial to "REC"...
- Page 48 Iris Lock Use this function when shooting a moving subject, when zooming, when the subject changes its distance (thus its size in the LCD monitor), or when you want to lock the brightness level. When the subject is close, keep the iris locked. Even when the subject moves away from you, the image will not darken.
-
Page 49: Playback
PLAYBACK Basic Playback You can watch what you’ve recorded in the LCD monitor. LCD monitor PUSH-OPEN OPEN LCD MONITOR Press PUSH-OPEN to open the LCD monitor. SELECT OPERATION MODE Turn the Power Dial to “PLAY” while pressing down the lock button located on the dial. REWIND TAPE Press 2. -
Page 50: Basic Connections
VCR/TV Connection Lens CAM stand CONNECT CAMCORDER TO TV OR Connect as shown in the illustration. • It is recommended to place the camcorder on the CAM stand for playback. ( TURN ON POWER Turn the Power Dial to "PLAY" and turn on the TV/VCR. - Page 51 Docking Station Attachment When you attach your camcorder to the Docking Station, you can add many interesting effects during playback. To DC input jack Core filter To AC outlet To DC jack CONFIRM POWER-OFF STATUS Make sure the camcorder’s power is off. ATTACH AND LOCKS Press down on the camcorder and slide the Lock Lever in the direction of the arrow.
- Page 52 TV Playback * Please refer to your VCR and/or TV instruction manual(s) when connecting. AC Power Adapter/Charger To DC input jack Core filter PLAYBACK To DC output jack DC cord To AUDIO output jacks (L/R) White Yellow Core filter To VIDEO output jack When an S-Video jack is available.
- Page 53 CONNECT DOCKING STATION TO TV OR VCR Connect as shown in the illustration pg. 50, 52). TURN ON POWER SELECT TV’S VIDEO MODE Set the TV to the channel or mode appropriate for video playback. If Using A VCR . . . go to step 4. If not .
-
Page 54: Playback Menu
Playback Menu The Playback Menu allows you to set the following functions: Playback Sound (32 kHz, 48 kHz), Synchro Comp, Display and Time Code . The following procedure applies to all except Synchro Comp ( LCD monitor 4 8 kHz MODE FULL SOUND 3 2 kHz MODE SOUND 1... - Page 55 Playback Sound During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. (32 kHz is preset to “SOUND 1” and 48 kHz is preset to “FULL SOUND”.) RECORDING SOUND 32 kHz 48 kHz...
-
Page 56: Advanced Features
Playback Zoom The recorded pictures can be magnified up to 10x at any time during playback. Normal playback Press T Press move image SELECT OPERATION MODE First make sure the LCD monitor is open fully. Turn the Power Dial to "PLAY" while pressing down the lock button located on the dial. - Page 57 Playback Effects These effects allow you to be creative with the playback picture. You can use any one of the 5 effects. E F F EC T SEL ECT C L AS S I C F I L M MONOTONE S EP I A STROBE V I DEO ECHO...
-
Page 58: Editing
Docking Station Refer to “Docking Station Attachment” on page 51 for attachment procedures. Make sure the camcorder is attached to the Docking Station before beginning editing. Dubbing You can copy recorded scenes from the camcorder onto a videotape. Refer to your VCR’s instruction manual for details. -
Page 59: Brand Setting
Brand Setting Before you can perform Automatic Dubbing, or control the VCR using the RM-V708U remote control, you must set the VCR brand. The remote control is capable of controlling basic VCR functions (PLAY, FF, REW, PAUSE, STOP). After you’ve set the brand, point the remote at the VCR’s sensor and press the appropriate button. * Some VCRs however will not be controlled by the RM-V708U. -
Page 60: Random Assemble Editing
Station to the VCR’s remote pause terminal using pg. 52). an editing cable. If you use a JVC VCR not equipped with a remote pause terminal or a non-JVC VCR, connect the Docking Station's editing jack to the remote control's remote pause terminal using an editing cable. - Page 61 Remote sensor SET EDIT-IN POINT At the beginning of the scene, press EDIT IN/ OUT on the remote control. The Edit-In position appears in the LCD monitor and on the connected TV. SET EDIT-OUT POINT At the end of the scene, press EDIT IN/OUT. The Edit-Out position appears in the LCD monitor and on the connected TV.
- Page 62 PREPARE SOURCE TAPE Rewind the tape in the camcorder to the beginning of the scene you want to edit and press PAUSE. ENGAGE VCR'S RECORD-PAUSE MODE Point the remote control toward the VCR's front panel and press VCR RECORD/ STANDBY, or manually engage the VCR's Record-Pause mode.
-
Page 63: For More Accurate Editing
For More Accurate Editing Some VCRs make the transition from Record/Standby to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you’ve recorded scenes you didn’t want. - Page 64 Adjustment of VCR‘s against Camcorder Timing IND/DISPLAY VCR (Recording deck) 4 8 kHz MODE FULL SOUND 3 2 kHz MODE SOUND 1 0 . 0 SYNCHRO D I SPLAY T I ME CODE I TEM –/+ BUTTON SET MENU BUTTON Playback Menu SELECT OPERATION MODE Open the LCD monitor and turn the Power...
-
Page 65: Audio Dubbing
Audio Dubbing The audio track can be customized only when recorded on the 32Khz mode ( NOTE: Audio Dubbing is not possible on a tape recorded at 48 kHz, on a tape recorded in the LP mode or on a blank portion of a tape. -
Page 66: Insert Editing
Insert Editing You can record a new scene into a previously recorded tape, replacing a section of the original recording with minimal picture distortion at the in- and out-points. The original audio remains unchanged. NOTE: Insert Editing is not possible on a tape recorded in the LP mode or on a blank portion of a tape. 12:34 FIND EDIT OUT POINT Open the LCD monitor and turn the Power... -
Page 67: Troubleshooting
TROUBLESHOOTING If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer or Technical Service Center. SYMPTOM 1. No power is supplied. 2. Recording cannot be performed. 3. There is no playback picture. - Page 68 SYMPTOM 10. Even though “GAIN UP” was set to “ A ”, scenes shot in dark places are not brightened. 11. Snapshot mode cannot be used. 12. Although the SNAPSHOT button is pressed, the white border does not appear. 13. Digital Zoom doesn’t work.
- Page 69 SYMPTOM 18. The Picture Wipe and Dissolve functions don’t work. 19. The Picture Wipe function doesn’t work. 20. Even when Slow (Slow Shutter) isn't selected, the image looks like it is activated. 21. The Video Echo effect doesn’t work. POSSIBLE CAUSES 18.
- Page 70 • When the LCD monitor's fluorescent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer or Technical Service Center. 29. •The light used to illuminate the LCD monitor causes it to become hot.
- Page 71 When it does, you can resume using the camcorder. If the indication remains, please consult your nearest JVC dealer or Technical Service Center. 38. •To protect the battery, it is recommended to charge it in places with a tempera- ture of 10°C to 30°C...
-
Page 72: After Use
Cleaning The Camcorder LCD monitor PUSH-OPEN CLEAN EXTERIOR Wipe gently with a soft cloth. REMOVE LENS COVER pg. 14. CLEAN LENS Blow it with a blower brush, then wipe gently with lens cleaning paper. RE-ATTACH LENS COVER Do not forcefully re-attach the lens cover as this may damage it. -
Page 73: Controls, Indications And Connectors
CONTROLS, INDICATIONS AND CONNECTORS Main Unit Stereo microphone Take care not to cover the sensor with your hand while shooting. White Balance Sensor Take care not to cover the sensor with your hand while shooting. Lens cover ... When using an optional conversion lens or lens filter (commercially available), you must first detach the lens cover. -
Page 74: Lcd Monitor Indications During Recording
CONTROLS, INDICATIONS AND CONNECTORS & LCD Monitor Indications During Recording NAME & FUNCTION Shooting mode selector position and setting indications Displays shooting mode selector position. When selecting functions, each name ("FOCUS", "EFFECT", "EXP.", etc.) is displayed. Snapshot indicator Wide mode Record-Standby indicator Digital image stabilizer indicator Recording mode indicator... -
Page 75: Lcd Monitor Indications During Playback
— “Tape End” indicator pg. 49) — An error number (E01, etc.) appears Consult your nearest JVC dealer. — "ERROR: REFER MANUAL" indicator Appears when Audio Dubbing or Insert Editing is impossible. ) blinks in the NAME & FUNCTION pg. -
Page 76: Docking Station
JLIP jack (joint Level Interface Protocol) • It is used to connect the camcorder to a device such as a personal computer. For further detail consult your nearest JVC dealer. Information (in English) is also available at our home page: http://www.jvc-victor.co.jp/ DC input jack ... -
Page 77: About Dv
ABOUT DV The digital video camera converts incoming audio and video signals into digital form for recording. A video signal is composed of a luminance signal (Y) and color signals (R-Y and B-Y). These signals are identified and recorded digitally (Digital Component Recording). The A/D (Analog to Digital) converter samples the Y signal at 13.5 MHz, and R-Y and B-Y at 3.375 MHz, and changes them to an 8-bit quantum signal. -
Page 78: Cautions
AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a "Siemens Plug", as shown. For this AC plug adapter, consult your nearest JVC dealer. INFORMATION This device complies with Part 15 of FCC Rules. -
Page 79: Lcd Monitor
20 seconds, it stops automatically. Also refer to the Cleaning Cassette’s instructions. If, after using the Cleaning Cassette, the problems still exist, consult your nearest JVC dealer. LCD monitor 1. To prevent damage to the LCD monitor, DO NOT . . . -
Page 80: Specifications
MAIN UNIT General Power Power consumption Format Signal format Video signal recording format Data compression rate Digital compression technology Cassette Tape Speed Maximum recording time Continuous recoring time Fast-Forward/Rewind Time Pickup Zoom Lens diameter (Filter Diameter) LCD monitor Minimum required illumination White balance Iris Microphone... - Page 81 BATTERY PACK BN-V812U Power Dimensions Weight REMOTE CONTROL UNIT Power Battery Life Effective distance Operating temperature Storage temperature Dimensions Weight AC ADAPTER/CHARGER AA-V80U Power Power consumption Output power Operating temperature Dimensions Weight JLIP VIDEO CAPTURE DOCKING STATION Connectors S-Video (S2 output) Video Audio JLIP (x 2)
-
Page 82: Glossary Of Terms
GLOSSARY OF TERMS Iris Works like the pupil of the human eye. In a well-lighted environment, the human pupil contracts to keep too much light from entering. In low lighting, the pupil dilates to allow more light in. Color temperature A measurement in Kelvin degrees which indicates the color contents of a light source;... -
Page 83: Index
INDEX Animation ... Audio Dubbing ... Auto Focus ... Auto Shut off ... Battery ... Battery Low ... Beep/Tally ... Charging ... Cleaning The Camcorder ... Connections ... Date/Time Display ... Date/Time Settings ... Digital Image Stabilizer ... Digital Zoom ... Docking Station ... - Page 84 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan U/U ( C ) COPYRIGHT© 1997 VICTOR COMPANY OF JAPAN, LTD. 0397MKV...
