16.4 Specifications
Overview
Overview
The BW MK2014 uses the latest technology developed to provide the ultimate video-projection experience. LCoS
(Liquid Crystal on Silicon) technology based on a reflective principle features an extremely high-definition
picture and seamless color gradations.
Emission method
Display panel size
Display Resolution
Contrast ratio
Projection lens
Brightness
Screen size
Distance range
Inputs:
HDMI 1 input
HDMI 2 input
Color Management
Video Processing
Light source lamp
Power Requirements
Power Consumption
Unit size (W x D x H)
Net Weight
Box size (W x D x H)
Gross Weight
Operation Environment
• Design and specifications are subject to change without prior notice.
• Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized
in order to aid comprehension. Images may differ from the actual product.
3-CHIP LCOS SYSTEM
LCoS is the abbreviation of Liquid Crystal on Silicon. The 3-Chip LCoS systems feature dedicated panels
for each color channel and render seamless color graduations without any flickering or rainbow effect
artifacts
R599840 - BW MK2014 User Manual
LCoS (Reflective Active Matrix Principle)
0.7" LCoS panels
3840 x 2160 pixels (3D video is rendered in 1920 x 1080)
60,000:1, 120,000:1 and 150,000:1
Throw ratio 1.4:1 - 2.8:1 with 2x Zoom
Electronic zoom, focus and shift.
Electronic aperture control (16x steps Aperture)
1300 ANSI Lumens
60" to 250" (Aspect ratio 16:9)
from 150cm to 1200cm
with HDCP and CEC
with HDCP and CEC
Advanced color settings (7-axis: primaries, secondaries and orange)
MPC v2.0 with Detail Enhancement, BG Blur and True-4K rendition.
2x Full HD frames per picture with advanced 1/16 pixel alignment
230W NSH
100V - 240V AC, 50Hz/60Hz
<360W (0.4W in standby mode)
54 x 56 x 22 cm - 21.3" x 22.0" x 8.7" (excluding feet)
15,8 Kg - 34.8 lbs for Blackwing One
16,6 Kg - 35.3 lbs for BW 2&3
58 x 61 x 41cm - 22.8" x 24.0" x 16.1"
21 Kg - 46.3 lbs for Blackwing One
23 Kg - 50.7 lbs for BW 2&3
Temperature: 5°C to 35°C (Storage Temperature: -10°C to 60°C)
Humidity: 20% to 80% without condensation
MISCELLANEOUS
