BURLEY G4237/8 IMAGE
INSTALLATION, SERVICING
FOR USE IN THE COUNTRIES STATED ON THE DATA PLATE AND CARTON
EVEN IF YOU HAVE FITTED THESE FIRES BEFORE,
PLEASE FOLLOW THESE INSTRUCTIONS STEP BY STEP.
Legislation and regulations do change over time!
LEAVE THESE INSTRUCTIONS WITH THE USER
TO OBTAIN YOUR FIRST YEAR GUARANTEE, THE INSTALLER AND CUSTOMER
MUST FILL IN THE SEPARATE GUARANTEE AND RETURN IT TO
A FREE SECOND YEAR GUARANTEE IS OFFERED SUBJECT TO THE FIRE BEING SERVICED
BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY CORGI) DURING THE FIRST YEAR OF OWNERSHIP.
FAILURE TO HAVE THIS APPLIANCE FITTED BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY
Burley Appliances Ltd,
Lands End Way, Oakham, Rutland, LE15 6RB
Telephone: +44 (0)1572 756956 Fax: +44 (0)1572 724390
e-mail:
info@burley.co.uk
FLUELESS GAS HEATER
& USER INSTRUCTIONS
WITH NATURAL GAS G20
OR LPG PROPANE GAS G31
(REFER TO RATING LABEL)
For the following countries: GB, IE
BURLEY WITIHIN 7 DAYS OF FITTING.
PROOF OF SERVICING MUST BE RETAINED
CORGI) FITTER INVALIDATES THE WARRANTY
web:
www.burley.co.uk
G4237/8InstUser
G20/31
Issue March09– v.3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Burley G4237 IMAGE
Summary of Contents for Burley G4237 IMAGE
-
Page 1: User Instructions
TO OBTAIN YOUR FIRST YEAR GUARANTEE, THE INSTALLER AND CUSTOMER MUST FILL IN THE SEPARATE GUARANTEE AND RETURN IT TO BURLEY WITIHIN 7 DAYS OF FITTING. A FREE SECOND YEAR GUARANTEE IS OFFERED SUBJECT TO THE FIRE BEING SERVICED BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY CORGI) DURING THE FIRST YEAR OF OWNERSHIP. -
Page 2: Appliance Data
INTRODUCTION Thank you for choosing this burley product. All of our products carry a CE mark which is awarded by an independent test house (notified body) and shows the fires have been type tested to meet the essential requirements of the European Gas Appliance Directive and the appropriate British Standards. -
Page 3: General Requirements
GENERAL REQUIREMENTS Gas appliances must be installed in accordance with the rules in force. In the UK it is the law that all gas appliances must be installed by Gas Safe ™ registered installer (formerly CORGI), in accordance with the Gas Safety (Installation and Use) regulations (as amended). The installation must also be in accordance with the relevant parts of local and national building regulations. -
Page 4: Installation Instructions
Note: The fires must be used as supplied with the smaller 60mm spacer fitted, failure to do so will make fitting the decorative case impossible & may overheat the fireplace and thus invalidate the warranty. Burley manufacture purpose made surrounds, which have been specially tested with the appliance for compatibility. The following guidelines must be adhered The hearth must be a minimum of 12mm thick with the top surface standing a minimum of 50mm above surrounding floor level or surrounded by a raised fixed fender of 50mm high. - Page 5 Overall dimensions are as shown. 632mm 197mm 590mm Hearths - For hearth mounting (or if the fire is less than 200mm above the ground) then the hearth must protrude at least 100mm in front of the fire and 50mm to either side. A minimum hearth of 732mm wide x 300mm deep is required, the hearth must be a minimum of 12mm thick and be of a non combustible material.
- Page 6 METHOD TWO - INSET ON HEARTH OR INSET WALL MOUNTED This method allows for the fire to be inset into a wall or fireplace opening. The appliance case has a 90mm deep spacer that needs to be removed and the corresponding deep brackets need to be taken off the case.
- Page 7 Fixing - The appliance should be secured to the wall using the fixing brackets on the flange of the appliance. If it is to be mounted above the ground, care should be taken to ensure the wall is able to take the weight of the appliance and that the fixings are of the correct type. Use all 6 screw holes in the brackets to attach to the wall.
- Page 8 When disposing of batteries, always do so in an environmentally friendly manner. Replacement rechargable batteries for the fire and replacement handsets are available from Burley Appliances on 01572 756956 or through your retailer. The 9 volt handset battery is available from normal retail outlets.
- Page 9 LIGHTING THE FIRE. FAILURE TO DO SO WILL RESULT IN BLOCKAGES WITHIN THE PILOT. BURLEY APPLIANCES IS THE ONLY COMPANY TO BENCH RUN AND THOROUGHLY TEST EVERY SINGLE GAS FIRE IT PRODUCES. BURLEY IS IN THE UNIQUE POSITION OF KNOWING THAT EVERY APPLIANCE LEAVES THE FACTORY IN PERFECT WORKING ORDER.
- Page 10 When disposing of batteries, always do so in an environmentally friendly manner. Replacement rechargeable batteries for the fire and replacement handsets are available from Burley Appliances on 01572 756956 or through your retailer. The 9 volt handset battery is available from normal retail outlets.
- Page 11 The customer must also be made aware that purpose provided ventilation should be checked regularly. If you have any questions or the fire is not operating correctly, phone the Burley help-line BEFORE you leave the installation.
- Page 12 minimum. We recommend the use of a HEPA filtered vacuum to remove any dust and soot accumulated in the heater before and after working on it. When replacing these articles, they should not be broken up, but sealed in heavy duty polythene bags labelled ‘RCF Waste’, which may be disposed of at a tipping site licensed for industrial waste.
- Page 13 USE ONLY GENUINE REPLACEMENT PARTS. User Instructions GENERAL REQUIREMENTS The heater is intended as a secondary heat source. Check that a primary source of heat (such as radiators) is present in the room. If insufficient primary heat is being used there may be a build up of condensation.
- Page 14 Ventilation openings must never be blocked or restricted in any way. Model Model Any purpose provided ventilation G4237 G4238 should be checked regularly to ensure it is free from obstruction. Cold air inlet Once the pebbles / coals have been...
-
Page 15: Cleaning And Maintenance
The fire is fitted with a special 7.2volt rechargeable battery available from your retailer or from Burley Appliances on 01572 756956. It can be changed by simply sliding it out of its housing under the fire, undoing the connector block and carefully replacing with a new one We regret that the warranty does not cover items such as batteries. - Page 16 Servicing must be carried out by a qualified service engineer. BURLEY APPLIANCES ARE THE ONLY COMPANY TO BENCH RUN AND THOROUGHLY TEST EVERY SINGLE GAS FIRE IT PRODUCES. BURLEY ARE IN THE UNIQUE POSITION OF KNOWING THAT EVERY APPLIANCE LEAVES THE FACTORY IN PERFECT WORKING ORDER.
-
Page 17: Additional Information
ADDITIONAL INFORMATION Flue Gas Analysers – Installation & Servicing Facts • Please read this sheet even if you have fitted our fires before. • Please leave this sheet with the customer as reference for future servicing of the appliance. • Please explain to the customer how the fire works and the details and facts listed on this sheet, particularly what the catalyst does and doesn’t do. - Page 18 After the equivalent of 30 years of use, the catalytic converter is as efficient as it was when brand new. Burley manages to achieve this by designing the fire to ensure that the catalytic converter is in exactly the right position for long life and maximum efficiency.
- Page 19 Gas rating of Burley Fluless Appliances Burley’s Flueless Gas Appliances are all gas input rated in the factory and undergo further line tests for combustion, sooting and visual performance. For Installers who wish to gas input rate appliances we need to establish tolerances for pass and fail.
- Page 20 The appliance has been used solely in accordance with the instruction book. • Any in guarantee work carried out by Burley Appliances will be charged for if the fault is caused by incorrect pressure or gas, incorrect installation, operator error, neglect or abuse.
