Burley G4237-8 IMAGE Installation, Servicing & User Instructions

Flueless gas heater for use in the countries stated on the data plate and carton with natural gas g20 or lpg propane gas g31
Hide thumbs Also See for G4237-8 IMAGE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation, Service and User Instructions
FOR USE IN THE COUNTRIES STATED ON THE DATA PLATE AND CARTON
EVEN IF YOU HAVE FITTED THESE FIRES BEFORE,
PLEASE FOLLOW THESE INSTRUCTIONS STEP BY STEP.
Legislation and regulations do change over time!
This product is not suitable for primary heating purposes.
LEAVE THESE INSTRUCTIONS WITH THE USER
TO OBTAIN YOUR FIRST YEAR GUARANTEE, THE INSTALLER AND CUSTOMER
MUST FILL IN THE SEPARATE GUARANTEE AND RETURN IT TO
A FREE SECOND YEAR GUARANTEE IS OFFERED SUBJECT TO THE FIRE BEING SERVICED
BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY CORGI) DURING THE FIRST YEAR OF OWNERSHIP.
FAILURE TO HAVE THIS APPLIANCE FITTED BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY
Burley Appliances Ltd,
Lands End Way, Oakham, Rutland, LE15 6RB
Telephone: +44 (0)1572 756956 Fax: +44 (0)1572 724390
e-mail:
info@burley.co.uk
BURLEY G4237-8 IMAGE
FLUELESS GAS HEATER
INSTALLATION, SERVICING
& USER INSTRUCTIONS
WITH NATURAL GAS G20
OR LPG PROPANE GAS G31
(REFER TO RATING LABEL)
For the following countries: GB, IE
BURLEY WITIHIN 7 DAYS OF FITTING.
PROOF OF SERVICING MUST BE RETAINED
CORGI) FITTER INVALIDATES THE WARRANTY
web:
www.burley.co.uk
G4237/8InstUser
G20/31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G4237-8 IMAGE and is the answer not in the manual?

Questions and answers

Related Manuals for Burley G4237-8 IMAGE

Summary of Contents for Burley G4237-8 IMAGE

  • Page 1: User Instructions

    TO OBTAIN YOUR FIRST YEAR GUARANTEE, THE INSTALLER AND CUSTOMER MUST FILL IN THE SEPARATE GUARANTEE AND RETURN IT TO BURLEY WITIHIN 7 DAYS OF FITTING. A FREE SECOND YEAR GUARANTEE IS OFFERED SUBJECT TO THE FIRE BEING SERVICED BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY CORGI) DURING THE FIRST YEAR OF OWNERSHIP.
  • Page 2 Issue July18 INTRODUCTION Thank you for choosing this burley product. All of our products carry a CE mark which is awarded by an independent test house (notified body) and shows the fires have been type tested to meet the essential requirements of the European Gas Appliance Directive and the appropriate British Standards.
  • Page 3 WARNING Read the instructions before using this appliance. This appliance requires installation and annual servicing by Gas Safe™ registered installer (formerly CORGI). Use only in a correctly sized and Hot air outlet Hot air outlet ventilated area. Ventilation openings must never be blocked or restricted in any way.

  • Page 4: Manual Control

    LIGHTING PROCEDURE. Identify the control valve fitted to the appliance and follow the appropriate instructions. MANUAL CONTROL There are 2 control knobs on the appliance. The right hand one controls On/Off and pilot/main burner. The left hand one is the comfort level thermostat which turns the fire down once the indicated temperature is reached.
  • Page 5 Main burner position Main burner operational & thermostatically controlled To turn the fire off, rotate the right-hand knob fully clockwise back to its OFF position. - 5 -...

  • Page 6: On/Off Switch

    Total Control Ensure that the ON/OFF switch is in the ON position (-) & that the manual knob is also pointing downwards towards its ON position (see below). ON/OFF Switch Manual Knob Gas Rate Adjusting Knob Simultaneously press and hold the (red circle) and (large flame) buttons until an acoustic signal confirms the start sequence has begun, then release the buttons.

  • Page 7: Battery Replacement

    Battery Replacement Handset 1.10 On the back of the handset remove the battery cover by pressing down the top of the cover & sliding it down. Remove & unclip the old battery & replace with a new PP3 9 volt battery. Receiver Unit (located under burner) Remove the heat shield surrounding the unit.

  • Page 8: Appliance Data

    *The inlet pressure must be within +/- 1mBar of specification with all gas appliances in the house switched on and also with just the Burley appliance operating. If outside of this tolerance the fault is most likely to be in the installation pipe work or service governor at the meter. If the problem is the meter governor, this is the property of the gas service provider (such as Transco / National Grid 0800 111999 or Bord Gais) and they should be called to rectify this.

  • Page 9: General Requirements

    The installation must also be in accordance with the relevant parts of local and national building regulations and in accordance with BS5871 pt4 except where Burley instructions state differently. For the Republic of Ireland, reference should be made to IS813 and ICP3 and any guidance notes from Bord Gais.

  • Page 10: Preparing The Appliance

    CLEARANCES TO COMBUSTIBLE MATERIALS AND SHELVES A non combustible shelf may be fitted to within 100mm of the top edge of the fire frame. Note that shelves will get hot and delicate ornaments, wax candles etc should be kept away from hot surfaces.

  • Page 11: Installation Instructions

    Note: The appliance must be used as supplied with the smaller 60mm spacer fitted, failure to do so will make fitting the decorative case impossible & may overheat the fireplace and thus invalidate the warranty. Burley manufacture purpose made surrounds, which have been specially tested with the appliance for compatibility. The following guidelines must be adhered The hearth must be a minimum of 12mm thick with the top surface standing a minimum of 50mm above surrounding floor level or surrounded by a raised fixed fender of 50mm high.
  • Page 12 The fire surround, back panel, hearth and all paints / lacquers etc must be of minimum 150 rating. Please ensure this is the case and if necessary check with the manufacturer, as we cannot be held responsible for subsequent damage. Note that paint and wall coverings on surfaces subject to heat can discolour and great care should be taken when choosing wall coverings.
  • Page 13 METHOD TWO - INSET ON HEARTH OR INSET WALL MOUNTED This method allows for the appliance to be inset with the 60mm spacer attached into a wall or fireplace opening. The appliance case has a 90mm deep spacer that needs to be removed and the corresponding deep brackets need to be taken off the case.
  • Page 14 Alternatively, hearth mounted appliances can use the cable fixing method by fixing eyebolts to the wall or fireplace behind and pulling it back into place. (See diagram). Do not fix the appliance directly to plasterboard as prolonged exposure to heat could affect it or the vapour layer behind.
  • Page 15 Warranty call outs to fires with incorrect pressures will be chargeable. BURLEY APPLIANCES IS THE ONLY COMPANY TO BENCH RUN AND THOROUGHLY TEST EVERY SINGLE GAS FIRE IT PRODUCES. BURLEY IS IN THE UNIQUE POSITION OF KNOWING THAT EVERY APPLIANCE LEAVES THE FACTORY IN PERFECT WORKING ORDER.

  • Page 16: Servicing Instructions

    I.e. pressure, model, room size and Gas Safe™ registered installer (formerly CORGI) Number If you have any questions or the fire is not operating correctly, phone the Burley help- line BEFORE you leave the installation.
  • Page 17 not be broken up, but sealed in heavy duty polythene bags labelled ‘RCF Waste’, which may be disposed of at a tipping site licensed for industrial waste. Normal hygiene rules of not smoking, eating or drinking in the work area should be followed.

  • Page 18: Parts List

    Burley Appliances are the only company to bench run and thoroughly test every single Flueless gas fire it produces. Burley is in the unique position of knowing that every appliance leaves the factory in perfect working order.
  • Page 19 After the equivalent of 30 years of use, the catalytic converter is as efficient as it was when brand new. Burley manages to achieve this by designing the fire to ensure that the catalytic converter is in exactly the right position for long life and maximum efficiency.
  • Page 20 • The appliance has been used solely in accordance with the instruction book. Any in guarantee work carried out by Burley Appliances will be charged for if the fault is caused by incorrect pressure or gas, incorrect installation, operator error, neglect or abuse.
  • Page 21 Gas rating of Burley Fluless Appliances Burley’s Flueless Gas Appliances are all gas input rated in the factory and undergo further line tests for combustion, sooting and visual performance. For Installers who wish to gas input rate appliances we need to establish tolerances for pass and fail.
  • Page 22 Disposal Recycling Information: The metallic & glass parts of the appliance & its packaging should be sorted for environmental-friendly recycling. WEEE: Dispose of electrical equipment in an environmentally correct manner. When disposing components containing Refractory Ceramic Fibres (RCF), we recommend that the items are not broken up, but are sealed within heavy duty polythene bags, and clearly labelled as RCF waste.
  • Page 23 - 23 -...
  • Page 24 Burley Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Burley Appliances Ltd, Lands’ End Way, Oakham, Rutland, LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.burley.co.uk Email: info@burley.co.uk - 24 -...
