Fantech AEV 1000 Nstallation, Operation And Maintenance Manual
  1. Manuals
  2. Brands
  3. Fantech Manuals
  4. Fan
  5. AEV 1000
  6. Nstallation, operation and maintenance manual

Fantech AEV 1000 Nstallation, Operation And Maintenance Manual

Aev series air exchange ventilator
Hide thumbs
Table of Contents

Advertisement

Quick Links

IMPORTANT -
MANUAL BEFORE INSTALLING UNIT
CAUTION -
Before installation, careful consideration must be given to how this sys-
tem will operate if connected to any other piece of mechanical equipement, i.e. a forced air
furnace or air handler, operating at a higher static. After installation, the compatibility of the
two pieces of equipment must be confirmed by measuring the airflow's of the Air Exchange
Ventilator by using the balancing procedure found in this manual.
It is always important to assess how the operation of any AEV may interact with vented
combustion equipment (i.e. Gas Furnaces, Oil Furnaces,Wood Stoves, etc.).
NEVER -
install a ventilator in a situation where its normal operation, lack of operation
or partial failure may result in the backdrafting or improper functioning of vented combus-
tion equipment!!!
Your ventilation system should be installed in conformance with the appropriate provincial or state require-
ments or in the absence of such requirements with the current edition of the National Building Code, and /
or ASHRAE's " good Engineering Pratice".
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Call 1-800-667-8721 anywhere in the US and Canada -
PLEASE READ THIS
AEV Models
AEV 1000
Fan Tech at
AEV Series
Air Exchange Ventilator
C C
C
kitchen
::
accessories
U
N
L
I
M
I
T
E
D
www.kitchensource.com
R
US

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEV 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fantech AEV 1000

Summary of Contents for Fantech AEV 1000

  • Page 1 Your ventilation system should be installed in conformance with the appropriate provincial or state require- ments or in the absence of such requirements with the current edition of the National Building Code, and / or ASHRAE’s “ good Engineering Pratice”. AEV Models AEV 1000 INSTALLATION, OPERATION AND MAINTENANCE MANUAL kitchen Fan Tech at...

  • Page 2: Table Of Contents

    Limited Warranty in the Business TECHNICAL DATA AEV Series ........................1 • The motors found in all Fantech AEV’s require no lubrication, and are factory balanced to prevent vibration and OPERATION ..........................2 promote silent operation. Modes Of Operation ........................2 •...

  • Page 3: Technical Data

    Model quality insulation. High FILTER - Synthetic high quality filter for better indoor air quality and clean air. AEV 1000 49 (104) 38 (60) 20 (42) UNIT CONTROLS - Case mounted rocker switches provide the following functions. ON/OFF switch is to engage the operations of the ventilation system.

  • Page 4: Operation

    NOTE: Some products may not be exactly as illustrated in the Installation, Operation and Maintenance Manual. Fantech Inc. reserves the right to modify, at any time and without notice, any or all of its products’ features, designs, components and specifications, to maintain their technological leadership position.

  • Page 5: Optional Remote Controls

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com OPERATION (CON’T) OPTIONAL REMOTE CONTROLS Dehumidistat I PRACTICAL The wall mount dehumidistat monitors the humidity level in TIPS the area it is installed.When the humidity level rises above the desired set-point, the AEV will activate to high speed/override To avoid window mode.

  • Page 6: Installation

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com INSTALLATION LOCATION The Air Exchanger must be located in a heated space where it will be possible to conve- niently service the unit.Typically the AEV would be located in the mechanical room or an area close to the outside wall where the weatherhoods will be mounted.

  • Page 7: Location & Ducting

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com INSTALLING DUCTS GOING TO / FROM OUTSIDE A well designed and installed ducting system will allow the AEV to operate at its maximum efficiency. Always try to keep duct runs as short and straight as possible. See Installation Diagrams for installation examples.

  • Page 8: Exhaust Air Ducting

    6” (152 mm) to 12” (305 mm) from the ceiling. 4 Push the Fantech grille {MGE (metal) or PGE (plastic)} into the optional mounting collar or directly into installed elbow. kitchen Fan Tech at...
  • Page 9 Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com INSTALLATION (CON’T) Radiant, Hydronic and Electric Baseboard Heating • This diagram shows the installation of your unit with radiant hydronic or baseboard heating. As shown, the stale air is extracted from the rooms with high humidity levels, and the fresh air is delivered in the living areas. In this case, a complete ducting system for ventilation must be installed.

  • Page 10: Air Flow Balancing

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com AIR FLOW BALANCING PRACTICAL TIPS • If the unit’s airflows are not properly balanced... - The unit may not operate at it’s maximum efficiency. - The unit’s use could cause negative or positive pressure in your home causing cold air to enter or other combustible...

  • Page 11: Pitot Tube Balancing Procedure

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com AIR FLOW BALANCING (CONT’) 1 For this flow measuring station, cut 2 Before taking the reading, make sure 3 The airflow is regulated by a the duct and place the flow that the magnehelic gauge is level balancing damper located inside the measuring station between each...
  • Page 12 Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com PITOT TUBE BALANCING PROCEDURE (CONT’) * Pitot tube should be kept at least 12” away from fans elbows and dampers to ensure acurate reading. kitchen Fan Tech at accessories...

  • Page 13: Maintenance

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com MAINTENANCE CAUTION MAKE SURE UNIT IS UNPLUGGED BEFORE ATTEMPTING ANY MAINTENANCE WORK The following components should also be inspected regularly and well maintained. FILTER PRACTICAL The filter needs to be checked TIPS and cleaned every three months or when it appears dirty.

  • Page 14: Parts List

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com SERVICING PARTS LIST Description Part # 1 Motorized Impeller 500000 2 Filter 017068 3 Override Relay Board 410150 4 Capacitor 410428 5 Auto-Transformer 410350 6 Control Panel 200422 7 5” Collar 530172 8 Filter Door 200426...

  • Page 15: Troubleshooting

    Call 1-800-667-8721 anywhere in the US and Canada - www.kitchensource.com TROUBLESHOOTING Problem Causes Solutions Air is too dry Dehumidistat control is set too low Increase the desired level of humidity. Change ventilation mode from continuous mode to standby. AEV out of balance Balance AEV Reduce the desired level of humidity.
