Portable Automobile Navigation System
Registered info
HOLUX and GPSmile are trademarks of HOLUX Technology, Inc.
All other trademarks belong to registered companies.
Note
The contents of this manual will be modified without further notice.
The operation temperature for the product is between -10℃~50℃.
Operating or recharging in an environment with a temperature
over 50℃ might cause the system to malfunction. However, this
should be considered a normal phenomenon. Please do not
operate under extreme temperatures.
Product User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Holux GPSmile 61
Summary of Contents for Holux GPSmile 61
- Page 1 Portable Automobile Navigation System Product User Manual Registered info HOLUX and GPSmile are trademarks of HOLUX Technology, Inc. All other trademarks belong to registered companies. Note The contents of this manual will be modified without further notice. The operation temperature for the product is between -10℃~50℃.
-
Page 2: Safety Precautions
Safety Precautions The device should only be used with the supplied batteries. • About the battery • 1. A Lithium battery is built into the device. To prevent fire or skin burns, do not disassemble, pierce, impact, or expose the battery to fire. -
Page 3: Warranty Statement
Holux Technology, or repairs done by anyone other than Holux Technology and authorized retail/service providers. -
Page 4: Technical Support
Technical Support If there are any questions regarding the use of this product, please • log on to the website www.holux.com and see the FAQ. Maintenance Service HOLUX Technology, Inc. +886-3-6687000 Web Site: www.holux.com Contact your nearest dealer, for further support. -
Page 5: Table Of Contents
Table of Contents Safety Precautions............ii Warranty Statement ............iii Technical Support............iv Maintenance Service............iv Preface ................1 Precautions and Notices ..........1 Copyright ...............2 Important Notice ............2 First time use..............3 Package Contents ............3 Basic Operation ..............4 Introduction ..............4 Front View................4 Rear View................4 Accessories ..............5 Cradle................... -
Page 6: Preface
Preface We appreciate your purchase of the HOLUX car navigation. Please read all instructions thoroughly for a full understanding of the products’ features. Precautions and Notices For your own safety, do not operate the controls of the product while •... -
Page 7: Copyright
Copyright Without the written consent of HOLUX Technology, Inc, this manual, including the product and the software, may not be duplicated, transmitted, recorded or saved on storage devices. Furthermore, it shall not be translated under any circumstances into any other languages. -
Page 8: First Time Use
First time use Package Contents Your product should include the following accessories: Device Cradle DC-DC Adapter Car Charger Quick Guide CD-ROM Warranty Card... -
Page 9: Basic Operation
Basic Operation Introduction Front View Main menu button 4.3’’ LCD touch screen Power button Rear View Micro SD card slot (Under battery cover) Mini-USB connector (Under battery cover) Battery cover... -
Page 10: Accessories
Accessories Cradle I/O interface Release button Screw I/O cap Optional Accessories Extension UART cable Bluetooth headset... -
Page 11: Getting Started
Getting Started Install Cradle 1. Press release button of cradle back. 2. Open the I/O cap. 3. Insert the device concave into the cradle tabs. ※ Please make sure the I/O pin is not wet or dirty. Concave 4. Slide the GPS into the cradle fitting holes to secure. -
Page 12: Remove Cradle
6. Tighten the screw on the back of the cradle Remove Cradle 1. Loosen the screw on the back of the cradle. 2. Press release button 3. Remove the device 4. Restore the I/O cap... -
Page 13: Install/ Remove Battery
Install/ Remove Battery Please make sure the battery is installed before using the device. 1. Open the battery lid 2. Install or Remove the battery Printing side facing up Pull the plastic to remove the battery 3. Restore the battery lid. -
Page 14: Device Connection Diagram
Device connection Diagram UART Cable Car Charger GPSmile 61CS DC-DC Adapter (12V 5V) - Page 15 Install SD Card (Optional) 1. Open the battery lid and remove the battery. 2. Open SD card slot 3. Insert SD card with its chip facing down and flat into the SD card slot. 4. Push upward to lock the SD card slot.
-
Page 16: Charging Battery (Optional)
6. Restore the battery lid. Charging Battery (Optional) Connect the Cradle or AC adapter to charging. The charging temperature ℃ 50 . ℃ for the product is between 0 ~ 1. Open the battery lid AC adapter 2. Connect the USB adapter to a wall outlet.
