Page 1: Bluetooth Gps Receiver
HOLUX M-1000 Bluetooth GPS Receiver User’s Manual Bluetooth GPS Receiver M-1000 User’s Guide May 2007 Rev.C Technology, Inc. 1F, No. 30, R&D Rd. II, HsinChu City 300, Science-based Industrial Park, Taiwan TEL: 03-6687000 FAX: 03-6687111 Website: www.holux.com All Right Reserved... - Page 2 HOLUX M-1000 Bluetooth GPS Receiver User’s Manual...
-
Page 3: Table Of Contents
HOLUX M-1000 Bluetooth GPS Receiver User’s Manual TABLE OF CONTENTS ...3 OVERVIEW ...4 PACKING LIST ...5 MAIN FEATURES...6 4.1. ASIC PECIFICATION 4.2. CQUISITION 4.3. ECEIVER CCURACY 4.4. IMITATION 4.5..7 OWER UPPLY 4.6. UTPUT AND NTERFACE 4.7..8 HYSICAL 4.8. -
Page 4: Overview
Bluetooth interface. M-1000 meets the requirement of field application, such as car navigation, mapping, agriculture surveying and security use under clear view of sky. M-1000 contacts to other device through Bluetooth interface, and built-in rechargeable Li-ion battery to save satellite information such as the status of satellite signal, the previous available location, date and time. -
Page 5: Packing List
HOLUX M-1000 Bluetooth GPS Receiver Manual 2. Packing List Thank you for purchasing the M-1000 Bluetooth GPS Receiver. Before you start, make sure that the following items are included in your package. If any of these items are missing, please contact your original local HOLUX dealer or distributor. -
Page 6: Main Features
HOLUX M-1000 Bluetooth GPS Receiver Manual 3. Main features Built in MTK MT3318 Low power consumption GPS chipset. 32 parallel satellite-tracking channels for fast acquisition and reacquisition. Superior sensitivity up to -159 dBm. Built-in WAAS/EGNOS Demodulator without any additional hardware. -
Page 7: Basic Specification
HOLUX M-1000 Bluetooth GPS Receiver Manual 4.1. Basic Specification Chipset：MTK MT3318 Channels： 32 parallel satellite-tracking channels. Frequency： 1575.42 MHz Receiver： L1, C/A code. 4.2. Acquisition Time (refer to MTK chip specification) Reacquisition： 0.1 second. Colm4fttš chipset... -
Page 8: Physical
HOLUX M-1000 Bluetooth GPS Receiver Manual Stop bit： 1 II. Format. NMEA0183 V3.01： GPGGA (1time/1 sec), GPGSA (1 time/5 sec.), GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL, or MTK NMEA Command for optional). III. Datum： WGS84. -
Page 9: Getting Started
HOLUX M-1000 Bluetooth GPS Receiver Manual 5. Getting Started STEP 1. Charge Battery Please charge battery till LED off for the first time. Power cable plug in Power cable connect to power socket ↓ Charge Battery Battery indicator light: Power too low --------... -
Page 10: Hardware Description
HOLUX M-1000 Bluetooth GPS Receiver Manual 5.1. Hardware Description 1). M-1000 Body description see Fig. 2: Power switch LED of GPS (Orange) Bluetooth LED (Blue) LED of Battery(Red / Green) (Fig.2) - Page 11 HOLUX M-1000 Bluetooth GPS Receiver Manual 2). LED status : SYMBOL COLOR Blue Bluetooth Green Battery Orange 3). Power Switch : a. Power on, Orange b. Power off, Orange 4). Power Jack & Data Port, see Fig.3 Jack type: Mating face of 5 pin Mini USB Type B female.
- Page 12 5). Optional accessories, and connector description, see Fig. 4 PC/Notebook USB port USB Cable (GR230-A2) Mini USB Notics : This data cable is designed by HOLUX specially for G-mouse function, can’t be replaced by common USB cable. The ordinary USB cable can only provide the charging function. (Fig.4)
-
Page 13: Bluetooth Device Connection Installation
HOLUX M-1000 Bluetooth GPS Receiver Manual 5.2. Bluetooth device connection installation The following is the steps of software installation to setup on PDA, DELL AXIM x51v with Bluetooth Manager. For other PDA or laptop device, the steps might vary. 1. In Pocket PC setting system panel, enable “manage GPS automatically”. -
Page 14: Installation Of Mini Gps Viewer Program
HOLUX M-1000 Bluetooth GPS Receiver Manual 6. Go to the “COM ports” panel to tap “New Outgoing Port”, choose “HOLUX_M-1000” device and tap “Next”. 7. Select the COM port, then tap finish, it will show as right figure, and tap “OK”... - Page 15 GPS receiver is over 0.5 hour power off but you are no longer in the previous position , it takes more time for the GPS receiver to get GPS position fix soon. We suggest you can click “Cold Start” or “Warm start”...
-
Page 16: Optional Cable Accessory
II. Connect GR-230-A2 USB data cable to computer. System will search new hardware and install the driver automatically III. Connect M-1000 GPS receiver with USB data cable. 7.3 Important Verify the COM port to start using your own navigation software. -
Page 17: Warranty
HOLUX M-1000 Bluetooth GPS Receiver Manual 8. Warranty The M-1000 is warranted to be free from defects in material and functions for a period of one year from the date of purchase. Any failure of this product within this period under normal conditions will be replaced at no charge to the customers. -
Page 18: Troubleshooting
HOLUX M-1000 Bluetooth GPS Receiver Manual Troubleshooting Problems Possible Reasons Weak or no GPS signal at the place of M-1000 No GPS output but GPS timer is The ephemeris and almanac data counting in GPS memory is no longer valid after no use for a long time. -
Page 19: Federal Communications Commission (Fcc) Statement
HOLUX M-1000 Bluetooth GPS Receiver Manual Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 20 HOLUX M-1000 Bluetooth GPS Receiver Manual...
