Stereo with processing preset. (Factory Setting)
As the above stereo with no processing mode except the internal processor is used. See loopthrough
below *
AC
JUMPERS. J5 (ON), J6 (STEREO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3
(Default)
(STEREO), DSW4 (ON), DSW5-8 (OFF)
JUMPERS. J5 (ON), J6 (STEREO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3
HOT
(STEREO), DSW4 (OFF), DSW5 (ON), DSW5-8 (OFF)
JUMPERS. J5 (ON), J6 (STEREO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3
LOUD
(STEREO), DSW4-5 (OFF), DSW6 (ON), DSW7-8 (OFF)
JUMPERS. J5 (ON), J6 (STEREO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3
SMOOTH
(STEREO), DSW4-6 (OFF), DSW7 (ON), DSW8 (OFF)
JUMPERS. J5 (ON), J6 (STEREO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3
TALK
(STEREO), DSW4-7 (OFF), DSW8 (ON)
Mono from two independent channels.
Essentially the same as the stereo mode except the stereo pilot is disabled which will enable receivers to
receive you in mono. See loopthrough mode below *
JUMPERS. J5 (ON), J6 (MONO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3 (MONO), DSW4-8 (OFF /
ON)
Mono from one channel input.
Essentially the same as the stereo mode except the stereo pilot is disabled which will enable receivers to
receive you in mono. You can provide one audio feed to the transmitter via the left balanced input. See
loopthrough mode below *
JUMPERS. J5 (ON), J6 (MONO), DSW1 (ON / OFF), DSW2 (50 / 75), DSW3 (MONO), DSW4-8 (OFF / ON
* Loopthrough mode
The transmitter has been provided with a multiplex output socket to present the output of the internal
audio stages to the outside world. This allows you to connect the signal from the internal limiter and stereo
encoder to an external piece of equipment before being injected back into the transmitter via the multiplex
input socket.
The most common application is for RDS encoders which nearly always have a loopthrough connection for
this purpose. Other applications include SCA generators and composite clippers. You will need to set the
internal jumper to off for external loopthrough. This is to stop the internal stereo encoder's multiplex output
signal from being fed to the exciter section internally.
More information on loopthrough setup is provided at the end of the advanced setup procedure section.
