BW Broadcast TX5 FM Broadcast Transmitter Technical Manual page 2

This transmitter should never be operated without a suitable antenna or test dum-
my load! Failure to observe this requirement may result in damage to the transmit-
ter that is not covered by the warranty.
This transmitter has been shipped with the internal stereo generator enabled. The
internal jumper J5 (MPX loop-through) is set to ON.
If you intend to connect a MPX signal to the MPX input
BNC connector you will need to move J5 (MPX loop-
through) to the OFF position.
Examples of configurations requiring setting J5 to OFF
include:
● Routing the internal MPX signal through an external RDS encoder.
● Connecting an external audio processor or stereo generator to the
transmitter.
● Connecting a re-broadcast or STL receiver to the transmitter.
Consult the manual for further information on the transmitter's jumpers and con-
nections.
WARNING
IMPORTANT
MPX Loopthrough Jumper
in off position
