FACTSHEET F-200
Surface
SMT
STANDARD SOCKET
Mount
Mates with:
SPECIFICATIONS
FTSH, FTS, FW
Materials:
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Current Rating:
1.75A @ 80°C ambient
Operating Temp Range:
-65°C to +125°C
Plating:
Au over 10µ" (0,25µm) Ni
Contact Resistance:
15mΩ max
Insertion Depth:
(1,83mm) .072" to
(4,37mm) .172" with
(0,38mm) .015" or
pass-through
Insertion Force:
1.5oz (0,42N)
Normal Force:
100 grams (0,98N)
Withdrawl Force:
1.5oz (0,42N)
Max Cycles:
100+
Note: Some lengths, styles
and options are non-standard,
non-returnable.
Processing:
Max Processing Temp:
230°C for 60 seconds
SMT Lead Coplanarity:
(0,10mm) .004" max
Suggested Paste
Thickness:
For most applications add
(0,05mm) .002" to max SMT
lead coplanarity
Suggested PCB Layouts:
Your specific layout may
vary (0,74)
(1,27)
.029
(1,47)
.050
.058
(0,74 -0,00
)
+0,08
-.000
.029 (1,27)
+.003
.050
DIA (2)
TYP
(0,74)
.029
DIA
(5,21)
(Pass-Thru)
.205
Board fixturing may be required
to assure proper alignment for
pass-through applications.
SAMTEC USA • Tel: 1-800-SAMTEC-9 or 812-944-6733 • Fax: 812-948-5047
SAMTEC GERMANY • Tel: +49 (0) 89 / 89460-0 • Fax: +49 (0) 89 / 89460-299
SAMTEC JAPAN • Tel: 81-424-42-8318 • Fax: 81-424-42-8319
APPLICATION
FLE
Series
Flex
Cable
NO. PINS
1
FLE
PER ROW
05 thru 50
No. of Positions x (1,27) .050 + (0,11) .0045
(1,27)
.050
(3,33)
.131
(4,36)
.172
SAMTEC UK • Tel: 01236 739292 • Fax: 01236 727113
SAMTEC FRANCE • Tel: 01 60 95 06 60 • Fax: 01 60 95 06 61
SAMTEC CHINA • Tel: 86-21-5385-4089 • Fax: 86-21-5385-4047
Due to technical progress, all designs, specifications and components are subject to change without notice.
FLE–110–01–G–DV
FLE–140 –01–G–DV
Tiger Beam
contact
Surface
FTSH
Mount
Series
(1,27mm) .050"
micro pitch
PLATING
01
OPTION
µ
= 10 " (0,25
(1,27)
.050
(0,51)
.020
(4,55)
.179
SAMTEC ASIA PACIFIC • Tel: 65-745-5955 • Fax: 65-841-1502
SAMTEC TAIWAN • Tel: (02) 2395-1677 • Fax: (02) 2395-1689
FLE–120–01–G–DV
FLE SERIES
Ideal for
pass-through
applications
Available with optional
pick-and-place pads
DV
OPTIONS
= Alignment Pin
–G
(Metal or plastic at
µ
Samtec discretion)
m) Gold
= (Best Cost Option)
(4,00mm) .157" DIA
Polyamide film
Pick & Place Pad
(5 Positions minimum)
(6,35)
.250
x
= Metal Pick &
(4,17)
Place Pad
.164
(5 Positions minimum)
(4,74)
.187
= Tape & Reel
–P OPTION
Packaging
(4,60)
.181
SAMTEC ITALY • Tel: 39 039 6890337 • Fax: 39 039 6890315
–A
–K
–P
–TR
