IMPORTANT: Users MUST read all instructions in the manual.
All manuals MUST be kept for future reference.

SAFETY SECTION

Safety signal words are used to designate a degree or level
of seriousness associated with a particular hazard. The
signal words for safety markings are WARNING, and
CAUTION.
a. WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
b. CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury. It is also used to alert against unsafe practices
and hazards involving only property damage.
▲ ▲
WARNING
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids or combustible materials in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier,
call the fire department.
— DO NOT RELY ON SMELL ALONE TO DETECT
LEAKS. DUE TO VARIOUS FACTORS, YOU MAY
NOT BE ABLE TO SMELL FUEL GASES.
• U.L. recognized fuel gas and CO detectors are
recommended in all applications, and their
installation should be in accordance with the
manufacturer's recommendations and/or local
laws, rules, regulations, or customs.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
User's Information Guide
Condensing Gas Furnaces- Fan Assisted
Combustion System
with Whole House Air Cleaner
Contents
Safety Section
General Information
To Start the Furnace
Proper Maintenance
The Problem Solver
Regular Dealer Maintenance
Warranty
WARNING
!
SAFETY WARNING
DO NOT USE THIS UNIT IF ANY PART HAS BEEN UN-
DER WATER. A FLOOD DAMAGED UNIT IS EXTREMELY
DANGEROUS. ATTEMPTS TO USE THE FURNACE CAN
RESULT IN FIRE OR EXPLOSION. A QUALIFIED SER-
VICE AGENCY SHOULD BE CONTACTED TO INSPECT
THE FURNACE AND TO REPLACE ALL GAS CONTROLS,
CONTROL SYSTEM PARTS, ELECTRICAL PARTS THAT
HAVE BEEN WET OR THE FURNACE IF DEEMED NECES-
SARY.
FAILURE TO FOLLOW THIS WARNING COULD RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
WARNING
!
SAFETY WARNING
IN THE EVENT THAT ELECTRICAL, FUEL OR MECHANI-
CAL FAILURES OCCUR, THE OWNER SHOULD IMME-
DIATELY TURN OFF THE GAS SUPPLY AT THE MANUAL
GAS VALVE LOCATED IN THE BURNER COMPARTMENT
AND ELECTRICAL POWER TO THE FURNACE AND CON-
TACT SERVICER.
FAILURE TO FOLLOW THIS WARNING COULD RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
WARNING
!
SAFETY WARNING
SHOULD OVERHEATING OCCUR, OR THE GAS SUPPLY
FAIL TO SHUT OFF, SHUT OFF THE MANUAL GAS VALVE
TO THE FURNACE BEFORE SHUTTING OFF THE ELEC-
TRICAL SUPPLY.
FAILURE TO FOLLOW THIS WARNING COULD RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
32- 5053- 03
Available in French Canadian (FC)
1
3
4
6
7
8
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV90i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trane XV90i

  • Page 1: Safety Section

    32- 5053- 03 Available in French Canadian (FC) User’s Information Guide Condensing Gas Furnaces- Fan Assisted Combustion System with Whole House Air Cleaner IMPORTANT: Users MUST read all instructions in the manual. All manuals MUST be kept for future reference. Contents SAFETY SECTION Safety Section...
  • Page 2: Safety Warning

    ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THESE OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. 32-5053-03 © 2008 Trane...
  • Page 3: Important Facts

    User’s Information General Information ▲ Furnaces must have air for proper performance. There WARNING must be a free fl ow of fresh air suffi cient for effi cient com- SAFETY WARNING bustion and safe ventilation of your furnace. BODILY INJURY CAN RESULT FROM HIGH VOLTAGE Never store gasoline, combustible materials, or other ELECTRICAL COMPONENTS, FAST MOVING FANS, fl...
  • Page 4: To Start The Furnace

    User’s Information To Start the Furnace Lighting instructions. 8. When thermostat is satisfi ed, main burners will Your furnace does not use a continuously burning pilot extinguish. fl ame. Therefore, manually lighting your furnace is not re- 9. Restore electrical supply panel. If main burners fail quired.
  • Page 5: User's Information

    User’s Information NOTE THE LOCATION OF THE MANUAL MAIN GAS SHUTOFF VALVE FOR YOUR FURNACE. Have your installer or servicer show you the location if you have any questions. UPFLOW FURNACE Manual Main Gas Shut-off Valve May Be Located on the Left or Right Side HORIZONTAL FURNACE Manual Main Gas Shut-off Valve May Be Located on the Top or Bottom Side TOP VIEW OF RIGHT SIDE PIPING 32-5053-03...
  • Page 6: Proper Maintenance

    User’s Information Proper Maintenance ▲ WHOLE HOUSE AIR CLEANER CAUTION ▲ CAUTION High Voltage is present within the air cleaner for operation. Turn the power off and wait at least 15 seconds to allow Never operate your unit for either heating or cooling with voltage to discharge.
  • Page 7: The Problem Solver

    User’s Information The Problem Solver ▲ Keep your furnace looking like new for years. WARNING Clean the enamel fi nish of your furnace with ordinary soap CARBON MONOXIDE POISONING HAZARD and water. For stubborn grease spots, use a household detergent. Lacquer thinner or other synthetic solvents may DO NOT ATTEMPT TO CHANGE THE VENTING SYSTEM.
  • Page 8: Regular Dealer Maintenance

    User’s Information Regular Dealer Maintenance d. The physical support of the furnace should be sound The following warning complies with State of California law, Proposition 65. without sagging, cracks, gaps, etc., around the base ▲ so as to provide a seal between the support and the WARNING base.
  • Page 9 File name 32-5053-03 Supersedes 32-5053-02 Date 12/08 Trane The manufacturer has a policy of continuous product and product data improvement, and it reserves the right 6200 Troup Highway to change design and specifi cations without notice. Tyler, TX 75707 32-5053-03...
  • Page 10 * This limited warranty is for residential usage of this equipment and not applicable when this equipment is used for a commercial applica- tion. A commercial use is any application where the end purchaser uses the product for other than personal, family or household purposes. As an ENERGY STAR Partner, Trane has deter- mined that this product meets the ENERGY STAR guidelines for energy effi...
