Black Magic
DECORATIVE FUEL EFFECT GAS FIRE
User Instructions
These instructions should be read by the user before operating the
appliance and retained for future reference
Model No. KRDCD0MN are for use on Natural Gas (G20) at a supply
pressure of 20 mbar in G.B. / I.E.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Black Magic KRDCD0MN and is the answer not in the manual?

Questions and answers

Summary of Contents for Kinder Black Magic KRDCD0MN

  • Page 1 Black Magic DECORATIVE FUEL EFFECT GAS FIRE User Instructions These instructions should be read by the user before operating the appliance and retained for future reference Model No. KRDCD0MN are for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.
  • Page 2: Installation Information

    INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a competent (e.g. CORGI Registered) Installer in G.B, in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998. Failure to install appliances correctly could lead to prosecution.
  • Page 3: Important Safety Information

    ABOUT YOUR NEW KINDER BLACK MAGIC GAS FIRE The Kinder Black Magic coal effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose coal layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.
  • Page 4: Operating The Fire

    The ceramic fuel bed remains hot for a considerable period after use and sufficient time should be allowed for the fire to cool before cleaning etc. The fire must only be operated with the Black Magic trim supplied with the product. OPERATING THE FIRE The controls are located behind the ashpan cover which is situated behind the Ashpan / Fender.
  • Page 5: Spillage Monitoring System

    SPILLAGE MONITORING SYSTEM This appliance is fitted with a spillage monitoring system which shuts down the fire if the evacuation of combustion products from the fire is affected by a partially or fully blocked flue. If this system operates the fire will go out. If this occurs, leave the fire for at least three minutes then follow the lighting procedure as described in the previous sec- tion.
  • Page 6: Re-Assembling The Fuel Bed

    RE-ASSEMBLING THE FUEL BED NOTE : The position of the fuel-bed components are critical to the performance of the product. Therefore please ensure that the fuel-bed components are positioned as described in the following section prior to requesting a service call due to soot build up, poor flame pattern etc. Place the ribbed ceramic fuelbed base on top of the fuelbed support and pull fully forwards to the burner.
  • Page 7 Fit five of the large sized coals onto the front ceramic rail, ensuring that they are evenly spaced. Use the recess’s in the front ceramic rail as a guide for placement. (See fig. 3 below) Fig. 3 Select four of the large coals and arrange behind the front row of coals, ensuring that flame paths as indicated below are not interupted.
  • Page 8 Select three of the large coals and arrange along the rear of the fuelbed, using the ribs in the rear of the fuelbed as a guide for placement. (See fig. 5 below) Fig. 5 Select the two small coals and position to fill the gaps at each end of the third row of coals, as shown.
  • Page 9 Select the remaining four coals and position along the rear edge of the fuelbed (see fig. 7 below) Fig. 7 The exact position and fit of the coals may be finely adjusted to give the most pleasing and random appearance. Warning : Use only the coals supplied with the fire.
  • Page 12: Fitting The Trim

    FITTING THE TRIM Position onto the fixing flange. The trim is secured with magnets. USER REPLACEABLE PARTS The only user replaceable parts on this fire are the fuelbed components and coals which may be replaced as described in the above section. Replacement of any other parts must be carried out by a competent person such as a CORGI registered gas installer.
