Art-Tech Falcon Beginner Operating Manual page 19

1.
Head locking gyro
2 .
9g servo
3 .
Tail boom
4 . 3 8 0
himag brushed motor
5 .
Lipo battery
6 .
ESC( brushed )
7 .
Screw
PA1.4*3*D2.5mm
8 .
Screw
PA1.4*6*D2.5mm
9 .
Screw
PWA1.4*6*D2.5mm
.
10 Screw
PA1.4*6*D2.5mm
1 1 .
Screw
PB1.7*4*D3mm
.
12 Screw
PM2*8mm
1 3 .
Screw
PM1.5*7mm
.
14 Screw
KM2*6*D3mm
1 5 .
Screw
KM2*8*D3mm
.
16 Screw
PWA2*6*D5.5mm
1 7 .
Screw
PWA2*12*D5.5mm
.
18 Screw
PWA2*8*D5.5mm
1 9 .
Screw
PWM2*5*D6mm
.
20 Screw
PWM2*8*D5mm
2 1 .
Screw
PWM2.5*5*D6mm
.
22 Screw
HM2*6
2 3 .
Screw 2*10
M
H
.
24 Screw
HM2*18
2 5 .
Self-locking nut
2 6 .
Self-locking nut
2 7 .
∮5*∮2.1*0.5mm
shim
2 8 .
∮3.5*∮2*0.5mm
shim
2 9 .
∮7*∮5*1mm
shim
3 0 .
Copper gear
3 1 .
∮5*∮2*2.5mm
Bearing
3 2 .
∮7*∮4*2mm
Bearing
3 2 .
∮8*∮3*4mm
Bearing
3 4 .
∮10*∮5*4mm
Bearing
3 5 .
∮25*∮20*4mm
Bearing
3 6 .
∮6*∮2.5*1.8mm
Bearing
3 7 .
Single-way bearing
3 8.
Flange bearing
3 9 .
Dowel
4 0 .
Cross shaft
4 1.
Copper bush
4 2 .
Swashplate inn er ring
4 3 .
Ball
4 4 .
Retaining ring
4 5 .
Swashplate outer ring
4 6 .
Connector A
4 7 .
Connector B
4 8 .
Small gear
.
49 Big gear
5 0 .
Single-way bearing
5 1 L e v e r .
5 2 .
Tail gear box (left)
.
53 Tail gear box (right)
5 4 B a l l .
5 5 .
Tail shaft drive gear
∮10*∮6*12mm
∮5*∮2.5*0.6mm
56.
Tail control arm 1
.
57 Vertical fin
.
58 Fixing seat
.
59 Back tail driving gear
.
60 Horizontal fin
.
61 Plastic linkage sleeve
.
62 Lever
.
63 Tail boom
.
64 Front tail driving gear
.
65 Servo holder
.
66 Tail driving shaft
.
67 Bushing seat II
.
68 Tail shaft
.
69 Copper slide bushing
.
70 Ball buckle
.
71 Spacing sleeve
.
72 Tail boom brace
.
73 Tail rotor grip bushing
.
74 Tail rotor grip
.
75 Ball buckle
.
76 Maia blade set
.
77 Rotor brake
.
78 Paddle orientation
.
79 Main shaft
.
80 A-shaped arm
.
81 CCPM linkage rod
.
82 Cross holder
.
83 Main shaft spacing sleeve
.
84 Frame (left)
.
85 Frame (right)
.
86 Canopy
.
87 Landing ski
.
88 Canopy holder
.
89 Tail blade
.
90 Main rotor grip
.
91 Bell control arm
.
92 Rotor head
.
93 Spacing arm
.
94 Spacing ball
.
95 Balance bar
.
96 Stabilizer
.
97 shim
.
98 Lever
.
99 Slide bushing
.
100 Rubber gasket
.
101 Tail cross shaft
.
102 Swashplate oriented rod
.
103 Servo arm
.
104 motor heat insulation
.
105 Screw heat insulation
.
106 Rubber gasket
.
107 Screw
HIM3*3mm
.
108 Screw
HM3*14mm
.
109 Screw
HA2*6*3.5mm
