1.2.2 Charging the Battery
Plug battery charger adaptor output cable into the battery charger connector as shown
in Figure 3.
Plug battery charger adaptor into the appropriate AC line voltage socket.
The Yellow/Amber charging LED will illuminate indicating that the battery is being
charged
The battery will be fast charged and after about 180 minutes. The LED will turn off
To remove the battery cartridge, open the battery door and tip the battery out of the
.
printer
Note: To ensure a full charge do not operate the printer while charging.
Note: The wall mounted charger is a Class II equipment (
comply with most international standards. The wall mounted charger is not supplied with
plugs for use in Korea
Model
Input Voltage/Current
Input Frequency
Output Voltage/Current (
ANDES3 User's Guide
FIGURE 3 – BATTERY CHARGER
)
Rev 1.0
)
. Multiple plug configurations
ANDES 3
100-240 VAC/0.4A
47-63 Hz
10VDC/1.32A
