7.6

Hub Oil

7.6.1

Checking the Hub Oil Level

-
Position the vehicle on its central stand on
a flat surface
-
Unscrew the oil dipstick «A», dry it with a
clean cloth and reinsert it, screwing it in
completely.
-
Pull out the dipstick and check that the oil
level reaches the lower notch (see figure);
if the level is below the MAX mark, restore
the proper amount of oil in the hub.
-
Reinsert the dipstick and screw it tightly.
The notches on the hub oil dipstick, with the
exception of the MAX mark, refer to other
PIAGGIO
models
function as far as this vehicle is concerned.
7.6.2

Replacing the Hub Oil

-
Remove oil filler cap «A».
-
Unscrew oil drain cap «B» and let the oil
drain out completely.
-
Retighten the oil drain cap and then fill the
hub with fresh oil
Recommended oil: TUTELA ZC 90
Oil capacity:
Rear hub
Tightening torques:
Hub oil draining screw
and
have
no
specific
~0.16 quarts
(~150 cm
11.0-12.5 lbs·ft
(15-17 N·m)
3
)
61
