Chrysler Vehicle Owner's Manual

Hide thumbs Also See for Vehicle:

User manual (1674 pages)

Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

SECTION

1

INTRODUCTION

2

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

3

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4

UNDERSTANDING YOUR INSTRUMENT PANEL

5

STARTING AND OPERATING

6

WHAT TO DO IN EMERGENCIES

7

MAINTAINING YOUR VEHICLE

8

MAINTENANCE SCHEDULES

9

IF YOU NEED CONSUMER ASSISTANCE

10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 493

INDEX

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 391

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 411

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 465

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 483

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

PAGE

1

2

3

4

5

6

7

8

9

10

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the Vehicle and is the answer not in the manual?

Questions and answers

Summary of Contents for Chrysler Vehicle

Page 1: Introduction
......9 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ......99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE .
Page 3: Table Of Contents
How To Use This Manual ....4 Vehicle Modifications/Alterations ... . 7 Warnings And Cautions ....6...
Page 4: Introduction
NOTE: After you read the manual, it should be stored symbols that may be used on your vehicle or throughout in the vehicle for convenient referencing and remain this Owner’s Manual: with the vehicle when sold, so that the new owner will be aware of all safety warnings.
Page 5 INTRODUCTION 5...
Page 6: Vehicle Identification Number
It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information. Observe all Warnings and Cautions.
Page 7: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
▫ Power Door Locks — If Equipped ..32 Vehicle Security Alarm — If Equipped ..16 ▫ Rearming Of The System ....17 Windows .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Enhanced Seat Belt Use Reminder System Sliding Side Door ..... . 40 (BeltAlert ) .
Page 11 (Commercial Vehicles Only) ....93 Vehicle ......97 Engine Break-In Recommendations .
Page 12: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch.
Page 13 Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the RKE transmitter go dead. The emergency key is also for locking the lower glove compartment.
Page 14: Sentry Key
ACC, a chime will sound to remind you to remove the key. NEVER leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a NOTE: The Key-In-Ignition reminder only sounds number of reasons. A child or others could be seri- when the Key Fob is placed in the LOCK or ACC ignition ously or fatally injured.
Page 15: Replacement Keys
Therefore, only Key Fobs that are programmed to the NOTE: The Sentry Key Immobilizer system is not vehicle can be used to start and operate the vehicle. The compatible with aftermarket remote starting systems. system will shut the engine off in two seconds if an Use of these systems may result in vehicle starting invalid Key Fob is used to start the engine.
Page 16: Vehicle Security Alarm - If Equipped
The Vehicle Security Alarm monitors the vehicle doors blank Key Fobs to the vehicle electronics. A blank Key for unauthorized entry and the ignition switch for unau- Fob is one that has never been programmed.
Page 17: Rearming Of The System
The engine will run only if a valid key is used to start the about 16 seconds to indicate that the alarm is being set. vehicle. After the alarm is set, the Vehicle Security Light will flash at a slower rate to indicate that the Vehicle Security Rearming Of The System Alarm is armed.
Page 18: Illuminated Entry System - If Equipped
Vehicle Security Alarm will arm regardless of whether The courtesy lights will turn on when you use the you are in the vehicle or not. If you remain in the vehicle Remote Keyless Entry (RKE) transmitter or open the and open a door, the alarm will sound. If this occurs, doors.
Page 19: Remote Keyless Entry (Rke) - If Equipped
• The Illuminated Entry System will not operate if the buttons for all RKE transmitters. dimmer control is in the extreme downward position. Two RKE transmitters may be supplied with the vehicle. REMOTE KEYLESS ENTRY (RKE) — IF Vehicles built without the powered options will be...
Page 20: Using The Rke Transmitter
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the RKE Transmitter (optional), power sliding doors, Remote Start feature Three-button RKE transmitters will provide basic UN- (optional). Some features can be programmed to the LOCK, LOCK and PANIC functions. customers preferences. For example, flash headlights or sound horn on LOCK.
Page 21 3. Release both buttons at the same time. Remote Key Unlock on First Press 4. Test the feature while outside of the vehicle by press- This feature lets you program the system to unlock either ing the LOCK/UNLOCK buttons on the RKE transmitter the driver’s side, or all doors, on the first press of the...
Page 22 3. Release both buttons at the same time. lower completely. Sound Horn with Remote Lock 4. Test the feature while outside of the vehicle by press- This feature will cause the horn to chirp when the doors ing the LOCK button on the RKE transmitter with the are locked with the RKE transmitter.
Page 23 NOTE: Pressing the LOCK button on the RKE transmit- Power Open/Close Power Liftgate — If Equipped ter while you are in the vehicle will activate the Vehicle Press the LIFTGATE button twice on the RKE transmitter Security Alarm. Opening a door with the Vehicle Security within five seconds to Open/Close the Power Liftgate.
Page 24 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Open/Close Left Power Sliding Door — If Turn Off Flash Lights with RKE Lock — If Equipped Equipped Press the LEFT Power Sliding Door button twice on the This feature will cause the turn signal lights to flash when...
Page 25 Unlock 1st Press Left Side 3. Release both buttons at the same time. Unlock All Doors 4. Test the feature while outside of the vehicle by press- Left Side Left Side ing the LOCK/UNLOCK buttons on the RKE transmitter Right Side...
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: General Information • Perchlorate Material — special handling may apply. This device complies with Part 15 of the FCC rules and See: www.dtsc.ca.gov/hazardouswaste/perchlorate. RSS 210 of Industry Canada. Operation is subject to the following conditions: •...
Page 27: Remote Starting System - If Equipped
• RKE PANIC button not pressed approximately 328 ft (100 m). WARNING! NOTE: The vehicle must be equipped with an auto- matic transmission to be equipped with Remote Start. • Do not start or run an engine in a closed garage or How to Use Remote Start confined area.
Page 28 To Enter the Vehicle After Remote Start programmed). Then, the engine will start and the vehicle To enter the vehicle while the engine is running during a will remain in the Remote Start mode for a 15-minute Remote Start, you must first unlock the vehicle using the cycle.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 • The hood is opened NOTE: • The ignition switch must be in the ON position in • The hazard switch is pressed order to drive the vehicle. • The shift lever is moved out of PARK •...
Page 30: Door Locks
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When to Reset Remote Start DOOR LOCKS The vehicle can be started remotely up to a maximum of Manual Door Locks two times. The vehicle is also allowed a maximum of one...
Page 31 • For personal security and safety in the event of an vehicle before closing the door. accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the key from the ignition switch, and lock your vehicle.
Page 32: Power Door Locks - If Equipped
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks — If Equipped accidentally locking your keys in the vehicle. Removing A power door lock switch is on each front door trim the Key Fob or closing the door will allow the locks to panel.
Page 33 LOCK position to the ON/RUN position a minimum of The Lock Doors Automatically feature is enabled when five times, ending in the ON position (do not start the your vehicle is shipped from the assembly plant and can engine). be disabled by using the following procedure: 5.
Page 34 The Unlock Doors Automatically On Exit feature unlocks 1. Enter your vehicle and close all doors. all of the vehicle doors when any door is opened. This will occur only after the shift lever has been shifted into 2. Fasten your seat belt. (Fastening the seat belt will...
Page 35: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 5. Within 30 seconds, press the driver’s door lock switch WINDOWS in the UNLOCK direction. Power Vent Windows — If Equipped 6. A single chime will sound to indicate the feature has Switches on the driver’s door trim panel let the driver...
Page 36: Power Windows
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Windows NOTE: Power Window switches will also remain active You can control either the front or rear windows using for up to 10 minutes after the ignition switch has been switches located on the driver’s door trim panel. The...
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Power Window Lockout Switch Front Passenger Power Window Switches Front Passenger Power Window Switch 1 - Window Open/Close 3 - Doors Unlock 2 - Doors Lock There is a single switch on the front passenger’s door trim panel which operates the passenger door window Sliding Side Door Power Window Switch —...
Page 38 The power window switches remain active for up to 10 minutes (depending on the accessory delay setting) after the ignition switch has been turned to LOCK. Opening a vehicle front door will cancel this feature. Auto Up Feature With Anti–Pinch Protection — If Equipped...
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 To stop the window from going all the way up during the WARNING! Auto Up operation, push down on the switch briefly. There is no anti-pinch protection when the window To close the window part way, lift the window switch to is almost closed.
Page 40: Sliding Side Door
(if equipped) in certain open or partially open positions. This is a normal occur- ing the door. This is very important when your vehicle rence and can be minimized. If the buffeting occurs with is parked on an incline as the door will slide faster in the rear windows open, open the front and rear windows the downhill direction.
Page 41: Power Sliding Side Door - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: The left side sliding door cannot be opened Press the button on the RKE transmitter twice within five while the fuel door is open. This feature operates only seconds to open a power sliding door. When the door is...
Page 42 NOTE: • The power sliding side door switches will not open if the shift lever is in gear or the vehicle speed is above 0 mph (0 km/h). To close the power sliding door with the shift lever in gear and vehicle speed at 0 mph...
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 • If the power sliding side door is not in the full open or The Sliding Side Door Open Flash can be enabled or close position, it will fully open when a power sliding disabled by performing the following procedure: door switch is pressed.
Page 44: Sliding Side Door Child Protection Lock
To Engage the Child Protection Door Lock 1. Open the sliding side door. 2. Slide the Child Protection Door Lock control inward (toward the vehicle) to engage the Child Protection Door Lock. Overhead Console Power Sliding Door Master Switch 1 — Left Door 3 —...
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 • When the Child Protection Door Lock system is en- gaged, (even if the inside door lock is in the unlocked position) the door can be opened only by using the outside door handle, the RKE transmitter, the switches on the overhead console or the switches located on the trim panel just in front of the power sliding door.
Page 46: Liftgate
• The power sliding side door switches will not open the on the trim panel just in front of the power sliding power sliding doors if the vehicle is in gear or the door when the Child Protection Door Locks are vehicle speed is above 0 mph (0 km/h).
Page 47: Power Liftgate - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 To open the liftgate, depress the liftgate release handle If the liftgate is locked and is not equipped with the located on the underside of the license plate bar and pull power liftgate feature, pressing the button on the RKE the liftgate open with one fluid motion.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power liftgate may also be opened and closed by The power liftgate may be closed by pressing the button, pressing the button located on the overhead console. located in the upper left trim in the liftgate opening.
Page 49 Make sure the liftgate is closed and latched • The power liftgate buttons will not operate if the shift before driving away. lever is in gear or the vehicle speed is above 0 mph (0 km/h). NOTE: • The power liftgate will not operate in temperatures •...
Page 50: Occupant Restraints
• Driving with the liftgate open can allow poison- • Advanced Front Airbags for driver and front passen- ous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep • Supplemental Rear Impact Active Head Restraints...
Page 51 • Front seat belts incorporate pretensioners to enhance up. You can strike the interior of your vehicle or other occupant protection by managing occupant energy passengers, or you can be thrown out of the vehicle.
Page 52: Lap/Shoulder Belts
Lap/Shoulder Belts WARNING! (Continued) All seats in your vehicle are equipped with lap/shoulder • Be sure everyone in your vehicle is in a seat and belts. using a seat belt properly. The belt webbing in the retractor is designed to lock •...
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is near the seatback of the front seats and next to your arm in the rear seats. Grasp the latch plate and pull out the belt.
Page 54 • A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries. Ribs aren’t as strong as shoulder bones.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
Page 56 (bent retractor, torn webbing, it could even cut into you. Be sure the belt is straight. etc.). If you can’t straighten a belt in your vehicle, take it to your authorized dealer and have it fixed. Third Row Center Shoulder Belt Instructions The shoulder belt for the third row center seat is located 5.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 is long enough to fit, insert the large latch plate into the buckle until you hear a “click.” The retractor should withdraw any slack in the belt. To release the small latch plate, position the end of the large latch plate against the red button on the small latch plate and push upward.
Page 58: Automatic Locking Retractors (Alr) Mode - If Equipped
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Retractors (ALR) Mode — If 3. Allow the belt to retract. As the belt retracts, you will Equipped hear a clicking sound. This indicates the safety belt is In this mode, the shoulder belt is automatically pre- now in the Automatic Locking Mode.
Page 59: Supplemental Rear Impact Active Head Restraints (Ahr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 NOTE: These devices are not a substitute for proper seat How the Active Head Restraints (AHR) work belt placement by the occupant. The seat belt still must be The Occupant Restraint Controller (ORC) determines worn snugly and positioned properly.
Page 60 All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of an accident.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 1. Grasp the deployed AHR from the rear seat. 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. Hand Positioning Points On AHR Down And Rearward Reset Movement 2.
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Down Movement To Engage Locking Mechanism AHR In Reset Position 4. The AHR front soft foam and trim half should lock NOTE: • If you have difficulties or problems resetting the head into the back decorative plastic half.
Page 63: Enhanced Seat Belt Use Reminder System (Beltalert )
If the driver’s seat belt has not been buckled within dealer or by following these steps: 60 seconds of starting the vehicle and if the vehicle speed NOTE: The following steps must occur within the first is greater than 5 mph (8 km/h), the BeltAlert will alert 60 seconds of the ignition switch being turned to the ON the driver to buckle the seat belt.
Page 64: Seat Belts And Pregnant Women
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Watch for the Seat Belt Reminder Light to turn Keep the belt low so that it does not come across the on while unbuckling and off while re-buckling the seat abdomen. That way the strong bones of the hips will take belt.
Page 65: Supplemental Restraint System (Srs) - Airbags
Supplemental Restraint System (SRS) - Airbags NOTE: Airbag covers may not be obvious in the interior This vehicle has airbags for both the driver and front trim; but they will open during airbag deployment. passenger as a supplement to the seat belt restraint Airbag System Components systems.
Page 66: Advanced Front Airbag Features
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front Seat Belt Pretensioners — if equipped WARNING! • Supplemental Side Airbag Inflatable Curtains (SABIC) — • Do not put anything on or around the airbag if equipped covers or attempt to open them manually. You may •...
Page 67 NOTE: • Should a vehicle rollover occur, the pretensioners and/or SABIC airbags on both sides of the vehicle Supplemental Seat Side Airbag Label may deploy. When the bag deploys, it opens the seam between the front and side of the seat’s trim cover.
Page 68 WARNING! the best interaction with the Advanced Front airbag. • If your vehicle is equipped with left and right Side Here are some simple steps you can take to minimize the Airbag Inflatable Curtain (SABIC), do not stack...
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Children that are not big enough to wear the vehicle seat The driver and front passenger seats should be moved belt properly (see Section on Child Restraints) should be back as far as practical to allow the Advanced Front secured in the rear seat in child restraints or belt- Airbags room to inflate.
Page 70: Airbag Deployment Sensors And Controls
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Deployment Sensors and Controls WARNING! Occupant Restraint Controller (ORC) • Relying on the airbags alone could lead to more The ORC is part of a Federally regulated safety system severe injuries in a collision. The airbags work required for this vehicle.
Page 71 Advanced Front Airbags may deploy in crashes with The ORC contains a backup power supply system that little vehicle front-end damage but that produce a severe may deploy the airbags even if the battery loses power or initial deceleration.
Page 72 If the light does not come The driver front airbag gas is vented through the vent on, stays on after you start the vehicle, or if it comes holes in the sides of the airbag. The passenger front...
Page 73 (SABIC) Inflator Units — If Equipped collision. During collisions where the impact is confined to a particular area of the side of the vehicle, the ORC may The ORC monitors the readiness of the electronic parts of deploy the SABIC Airbags, depending on severity and the system whenever the ignition switch is in the START type of collision.
Page 74 • Flash hazard lights as long as the battery has power or Because airbag sensors estimate deceleration over time, vehicle speed and damage are not good indicators of until the ignition key is turned off. whether or not an airbag should have deployed.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 passenger as the airbags deploy and unfold. The Do not drive your vehicle after the airbags have de- abrasions are similar to friction rope burns or those ployed. If you are involved in another collision, the you might get sliding along a carpet or gymnasium airbags will not be in place to protect you.
Page 76 • It is dangerous to try to repair any part of the advanced airbag system for persons with disabili- airbag system yourself. Be sure to tell anyone who ties, contact your authorized dealer. works on your vehicle that it has an airbag system. (Continued)
Page 77: Event Data Recorder (Edr)
Event Data Recorder (EDR) nance free, if any of the following occurs, have In the event of an accident, your vehicle is designed to an authorized dealer service the system immediately. record up to five seconds of specific vehicle data param- •...
Page 78 Chrysler Group LLC, such investigations may be re- hicle, or crash, will be treated confidentially. Confidential quested by customers, insurance carriers, government data will not be disclosed by Chrysler Group LLC to any officials, and professional crash researchers, such as those third party except when: associated with universities, and with hospital and insur- 1.
Page 79: Integrated Child Booster Seat - If Equipped
4. Otherwise required by law. The booster seat is designed to raise the child high enough to use the vehicle lap and shoulder belt. The Data parameters that are recorded: booster seat latch release handle is located at the front of •...
Page 80 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To position a child into the Integrated Child Booster Seat WARNING! follow these steps: Failure to comply with the following conditions 1. Pull the release handle forward to release the latch and could result in serious injury of death: seat cushion.
Page 81: Integrated Child Seat - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 NOTE: The lap portion of the seat belt should be low on 7. To release the seat belt, push the red button on the the hips and as snug as possible. buckle.
Page 82: Child Restraints
Child Restraints required to hold even an infant on your lap could Everyone in your vehicle needs to be buckled up all the become so great that you could not hold the child, no time, including babies and children. Every state in the matter how strong you are.
Page 83 Rearward-facing child seats must NEVER be used in of child restraints can be used rearward-facing: infant the front seat of a vehicle with a front passenger carriers and convertible child seats. Both types of child airbag. An airbag deployment could cause severe restraints are held in the vehicle by the lap/shoulder injury or death to infants in this position.
Page 84 40 lbs (18 kg), but who are still • If the shoulder belt contacts the face or neck, move the too small to properly fit the vehicle’s seat belts. If the child closer to the center of the vehicle. If this doesn’t...
Page 85 Standards. We also recommend that you make sure • A rearward-facing child restraint should only be that you can install the child restraint in the vehicle used in a rear seat. A rearward-facing child re- where you will use it, before you buy it.
Page 86 • In the rear seat, you may have trouble tightening the Don’t leave it loose in the vehicle. In a sudden stop or lap/shoulder belt on the child restraint because the...
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Installing the Child Restraint System Not all child restraint systems will be installed as we We urge you to carefully follow the directions of the have described here. Again, carefully follow the instruc- manufacturer when installing your child restraint.
Page 88 Ensure that the lower Remind all children in the vehicle that the seat belts are attachment strap is firmly engaged and that the hook is not toys and should not be played with, and never leave secure.
Page 89 (with either Lower Anchors or Vehicle Seat Belt): vehicle seat. Remove all slack in the lower attachment 1. Route the top tether strap under the adjustable head straps. Reference the child restraint instructions for infor- restraint between the steel posts.
Page 90 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The top tether strap is always to be secured, WARNING! regardless of if the child restraint is installed with the lower anchors or the vehicle seat belt. An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
Page 91: Rear Seat Delete Feature (Commercial Vehicles Only) - If Equipped
However, if you must carry a Once you have completed securing the child restraint child in a vehicle without a rear seat, the passenger seat with the seat belt secure the top tether strap. Refer to...
Page 92 WARNING! Rearward-facing infant restraints must never be se- cured in the passenger seat of a vehicle with a passenger airbag. In an accident, a passenger airbag may deploy causing severe injury or death to infants riding in rearward-facing infant restraints.
Page 93: Restraining Infants And Small Children With Seat Delete Feature (Commercial Vehicles Only)
Use the restraint that is vehicle seat should be adjusted to the rear most correct for your child: position.
Page 94 WARNING! extended tether strap. The vehicle tether anchor is designed to be used with 3. Route the tether strap under the head rest. a child restraint only. It should not be used for any NOTE: Ensure that the child restraint tether strap is other purpose.
Page 95: Engine Break-In Recommendations
• It is extremely dangerous to ride in a cargo area, high-quality energy conserving type lubricant. Oil inside or outside of a vehicle. In a collision, people changes should be consistent with anticipated climate riding in these areas are more likely to be seri- conditions under which vehicle operations will occur.
Page 96: Exhaust Gas
• Do not allow people to ride in any area of your out of the area. vehicle that is not equipped with seats and seat If it is necessary to sit in a parked vehicle with the engine belts. running, adjust your heating or cooling controls to force •...
Page 97: Safety Checks You Should Make Inside The Vehicle
In addition, authorized dealer. If the light stays on, flickers, or comes inspect the exhaust system each time the vehicle is raised on while driving, have the system checked by an autho- for lubrication or oil change. Replace as required.
Page 98: Periodic Safety Checks You Should Make Outside The Vehicle
Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns. Check for stones, nails, glass, or other objects engine coolant, oil, or other fluid leaks. Also, if gasoline lodged in the tread.
Page 99: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Tilt Mirrors In Reverse (Available With Mirrors ......104 Memory Seat Only) —...
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Third Row Power Seat — If Equipped ..139 Seats ......117 ▫...
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 ▫ Daytime Running Lights Electronic Speed Control — If Equipped ..164 (Canada/Fleet Vehicles Only) ... . 154 ▫ To Activate ......165 ▫...
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Cleaning Parksense ▫ Troubleshooting Tips ....187 ....173 ▫...
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 ▫ Driver Seatback Storage — If Equipped ..198 Console Features ..... . 203 ▫...
Page 104: Mirrors
Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle). The mirror should be adjusted while set in the day position (toward the windshield). Manual Rearview Mirror Automatic Dimming Mirror —...
Page 105: Outside Mirrors
Relying too much on side convex mirrors could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in a side convex Automatic Dimming Mirror mirror.
Page 106: Driver's Automatic Dimming Mirror - If Equipped
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver’s Automatic Dimming Mirror — If Equipped guard against accidentally moving a mirror position. The The driver’s outside mirror will automatically adjust for mirror selection will also automatically turn off after glare from vehicles behind you. This feature is controlled 30 seconds.
Page 107: Heated Mirrors - If Equipped
REVERSE. The driver’s Driver’s side power mirror preselected positions can be outside mirror will then return to the original position controlled by the optional Driver Memory Seat Feature.
Page 108: Illuminated Vanity Mirrors - If Equipped
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped uconnect™ phone — IF EQUIPPED An illuminated vanity mirror is located on the sun visor. Refer to “uconnect™ phone” in the uconnect™ User To use the mirror, rotate the sun visor down and swing Manual located on the DVD for further details.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 The BSM detection zone covers approximately one lane on both sides of the vehicle (11 ft or 3.35 m). The zone starts at the outside rear view mirror and extends ap- proximately 20 ft (6 m) to the rear of the vehicle. The BSM...
Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The area on the rear fascia where the radar sensors are The BSM system notifies the driver of objects in the located must remain free of snow, ice, and dirt/road detection zones by illuminating the BSM warning light contamination so that the BSM system can function located in the outside mirrors.
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 The BSM system can also be configured to sound an audible (chime) alert and mute the radio to notify the driver of objects that have entered the detection zones. Refer to “Modes Of Operation” in this section.
Page 112 If you pass another vehicle slowly (with a relative speed side and enter the rear detection zone with a relative less than 10 mph (16 km/h) and the vehicle remains in speed of less than 30 mph (48 km/h). the blind spot for approximately 1.5 seconds, the warning light will be illuminated.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your...
Page 114: Rear Cross Path
Opposing Traffic slowly and cautiously out of the parking space until the rear end of the vehicle is exposed. The RCP system will then have a clear view of the cross traffic and if an oncoming vehicle is detected, alert the driver.
Page 115 When RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including radio muting.
Page 116: Modes Of Operation
Electronic Vehicle Information Center (EVIC)” in signal is then activated, and it corresponds to an alert Section 4. present on that side of the vehicle, an audible chime will also be sounded. Whenever a turn signal and detected Blind Spot Alert...
Page 117: Seats
Each time the vehicle • Be sure everyone in your vehicle is in a seat and is started the previously stored mode will be recalled and using a seat belt properly.
Page 118: Manual Front And Second Row Seat Adjuster
The adjusting bar is located under the front of the seat. Pull the bar upward and move the seat to the desired Adjusting a seat while the vehicle is moving is position. Release the bar to lock the seat into position.
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 WARNING! DO NOT ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or fatally injured. Use the recliner only when the vehicle is parked.
Page 120: Manual Lumbar Adjust Lever - If Equipped
The lumbar adjustment lever is located on the outboard side of the seat. To increase the support, rotate the lever Adjusting a seat while the vehicle is moving is downward. To decrease the support, rotate the handle dangerous. The sudden movement of the seat could upward.
Page 121: Eight-Way Power Seats - If Equipped
The power seat switches are located on the outboard side of the seats. The front switch controls the up/down, Adjusting a seat while the vehicle is moving is forward/rearward and tilt adjustment. The rear switch dangerous. The sudden movement of the seat could controls the recline adjustment of the seatback.
Page 122: Heated Seats - If Equipped
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped This feature heats the front driver and passenger seats. The controls for front heated seats are located on the center instrument panel area. After turning the ignition ON, you can choose from High, Low, or Off heat settings.
Page 123: Adjusting Active Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Adjusting Active Head Restraints WARNING! Active Head Restraints can reduce the risk of injury in the event of a rear impact. The Active Head Restraint Persons who are unable to feel pain to the skin...
Page 124 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To raise the head restraint, pull upward on the head For comfort the Active Head Restraints can be tilted restraint (on some models, you may need to press the forward and backward. To tilt the head restraint closer to push button).
Page 125 “Resetting Active Head Restraints (AHR)” under “Occupant Restraints” in Section 2. WARNING! • Driving a vehicle with the head restraints removed or improperly adjusted could cause serious injury or death in the event of a collision. The head...
Page 126: Stow 'N Go Seating - If Equipped
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Stow ’n Go Seating — If Equipped On vehicles equipped with Stow ’n Go seating, the second and third row seats may be folded into the floor for convenient storage. To Fold Second Row Seats 1.
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Second Row Seat Release Strap Second Row Seatback Release Lever 6. Close the storage bin cover. 5. Pull rearward on the release strap located at the rear of the seat and tumble the seat forward into the storage bin.
Page 128 WARNING! In an accident, serious injury could result if the seat storage bin covers are not properly latched. • DO NOT drive the vehicle with the storage bin covers open. • Keep the storage bin covers closed and latched while the vehicle is in motion.
Page 129: Easy Access Seating
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 To tilt the seat, pull forward on the release strap located on the front of the seat between the seatback and seat cushion and tilt the seat fully forward. To return the seat to its upright position, push rearward on the seatback until it latches.
Page 130: Swivel 'N Go™ Premium Seating - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Seats are removable WARNING! In the event of a collision you could be injured if the seat is not fully latched. Swivel ’n Go™ Premium Seating — If Equipped Premium second row Swivel ’n Go™ Seating features include: •...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 WARNING! When the seatback release handle is lifted, the seat- back will rotate forward. To avoid injury, if you are not seated in the seat, stay clear from the area in the path of the rotating seatback.
Page 132 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Removing Swivel ’n Go™ Premium Seating — If WARNING! Equipped Failure to comply with the following conditions 1. Remove any obstructions from the floor behind the could result in serious injury or even death: seat, and stow the third row seat.
Page 133 Rollers are part of the seat frame and will ease the removal process. In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor 5. Lower the release handle located at the bottom front attachments.
Page 134 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Swivel ’n Go™ Premium Seating Table — If The table and leg are stored beneath the floor when not in Equipped use. To install the table follow these steps: The Swivel ’n Go™ Seating Table consists of an easily 1.
Page 135 WARNING! Failure to comply with the following conditions could result in serious injury or even death: • DO NOT install the table while vehicle is in motion. Installing Table Leg Into Base • NEVER drive the vehicle with only the pole in- 1 —...
Page 136 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • DO NOT place heavy or sharp objects on table. • DO NOT place liquid drinks on the table, use available cupholders. • Second row seats must be locked in the rearward facing position before installing the table.
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 2. Pull horizontally on the latch to activate the release 7. Once the pole and table top are secured, you may from the pole. place them in the floor storage bin in front of the second row seats.
Page 138: Second Row Bench Seat - If Equipped
A lock indicator button pops up when the seat is unlocked. The seat assembly can now be removed from the vehicle and moved on its Easy Out Rollers. Release Handles To reinstall the seat, align the seat into the detent posi- tions on the floor.
Page 139: Third Row Power Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! If not properly latched, the bench seats could become loose. Personal injuries could result. After reinstall- ing these seats, be sure the red indicator button on the release handles return into the handles.
Page 140 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The switch is only functional when the liftgate is open Left and right third row seats can be folded individually and the vehicle is in PARK. or together. The third row power folding seat adjusts to...
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 NOTE: 2. Pull release strap marked “1” located on the rear of the • Disconnect the center shoulder belt from the small seat to lower the seatback. buckle and lower the head restraints before attempting 3.
Page 142 4. Adjust the head restraint to the desired position. WARNING! In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor attachments. Always be sure the seats are fully latched.
Page 143: Driver Memory Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 WARNING! To avoid serious injury or death, NEVER operate the vehicle with occupants in the third row seat while in the tailgate mode. DRIVER MEMORY SEAT — IF EQUIPPED The Memory Buttons 1 and 2 on the driver’s door panel can be programmed to recall the driver’s seat, driver’s...
Page 144: Setting Memory Positions And Linking Rke
3. Adjust the driver’s seat, recliner, and driver’s side- the ON position. view mirror to the desired positions. 11. Select Remote Linked to Memory in the Electronic 4. Adjust the brake and accelerator pedals to the desired Vehicle Information Center (EVIC) and enter “Yes”. Refer positions.
Page 145 NOTE: The vehicle must be in PARK to recall memory remove the key. positions. If a recall is attempted when the vehicle is not in PARK, a message will be displayed in the EVIC. 2. Press and release MEMORY button 1. The system will recall any memory settings stored in position 1.
Page 146: Easy Entry/Exit Seat (Available With Memory Seat Only)
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Within five seconds, press and release MEMORY Easy Entry/Exit Seat button 1 on the driver’s door. A chime will sound (Available with Memory Seat ONLY) signaling to you that the driver memory has been set.
Page 147: To Open And Close The Hood
NOTE: The Easy Entry/Easy Exit feature can be en- abled or disabled through the programmable features in the Electronic Vehicle Information Center (EVIC). If your vehicle is not equipped with an EVIC, your dealership can activate/deactivate this feature for you. For details, Hood Release refer to “Automatically Move Seat Back on Exit,”...
Page 148 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Move to the front of the vehicle and look inside the Use the hood prop rod to secure the hood in the open center of the hood opening. Locate, then push the safety position.
Page 149: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 LIGHTS Interior Lighting All of the lights, except the Hazard Warning lights, Interior lights are turned on when a door or liftgate is headlight high beams and flash-to-pass, are controlled by opened, the Remote Keyless Entry (RKE) transmitter is...
Page 150 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dome Light Positions Parade Mode (Daytime Brightness Feature) Rotate the dimmer control completely Rotate the dimmer control to the first upward to the second detent (extreme detent. This feature brightens the odom- top position) to turn on the interior eter, radio and overhead displays when lights.
Page 151: Parking Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Halo Lights — If Equipped Parking Lights Halo lights are strategically placed soft lighting that help Turn the headlight switch knob to the first detent to illuminate specific areas to aid the occupants in to turn the parking lights on.
Page 152: Automatic Headlights - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped This system automatically turns your headlights on or off based on ambient light levels. To turn the system on, turn the headlight switch to the extreme counterclockwise position aligning the indicator with the “A” on the headlight switch.
Page 153: Headlights On With Wipers - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Headlights On With Wipers — If Equipped When exiting the vehicle the driver can choose to have When your headlights are in the Automatic mode and the the headlights remain on for 30, 60, or 90 seconds or not engine is running, the headlights will automatically turn remain on.
Page 154: Daytime Running Lights (Canada/Fleet Vehicles Only)
Also, if a turn signal is activated, the DRL lamp on the until the next cycle of the ignition switch or headlight same side of the vehicle will turn off for the duration of switch. the turn signal activation. Once the turn signal is no The battery protection feature will be disabled if the longer active, the DRL lamp will illuminate.
Page 155: Multifunction Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Multifunction Lever The multifunction lever is located on the left side of the steering column. The multifunction lever controls the: • Turn Signals • Headlight Beams Low/High • Flash-To-Pass (Optical Horn) • Front and Rear Wipers — Washer Functions...
Page 156: High/Low Beam Switch
When the headlights are turned on, pushing the multi- low beams until the approaching vehicle is out of view. function lever toward the instrument panel will switch from low beams to high beams. Pulling back to the...
Page 157: Windshield Wipers And Washers
(closer to the vehicle). Also, dirt, film and other obstructions on the windshield NOTE: This system will not activate until the vehicle is or camera lens will cause the system to function at, or above, 25 mph (40 km/h).
Page 158 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Always remove any buildup of snow that pre- 1. Mist, Front Wiper and Washer vents the windshield wiper blades from returning to the Press the end of the multifunction lever inward to the off position.
Page 159 NOTE: Rear window wipers function in the intermittent seconds, to a maximum of 20 seconds between cycles. wiper speed only. The time delay will be doubled if the vehicle speed is less than 10 mph (16 km/h). WARNING! Low-speed is achieved by rotating the multifunction Sudden loss of visibility through the windshield lever past the intermittent settings, to the first detent.
Page 160: Rain Sensing Wipers - If Equipped
• The Rain Sensing feature may not function properly from the windshield washers of the vehicle ahead. Rotate when ice or dried saltwater is present on the wind- the end of the multifunction lever to one of the five shield.
Page 161: Tilt Steering Column - If Equipped
ON, and the trans- mission shift lever is in the NEUTRAL position, and the vehicle speed is less than 5 mph (8 km/h), unless the wiper control on the multifunction lever is moved or the shift lever is moved out of the NEUTRAL...
Page 162: Adjustable Pedals - If Equipped
Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped. Be sure it is locked before driving.
Page 163 • The pedals can be adjusted with the ignition OFF. • The pedals can be adjusted while driving. • The pedals cannot be adjusted when the vehicle is in REVERSE or when the Electronic Speed Control Sys- tem is on. The following messages will be displayed...
Page 164: Electronic Speed Control - If Equipped
WARNING! Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always Electronic Speed Control Lever adjust the pedals while the vehicle is parked.
Page 165: To Activate
SET lever downward and then release. Lift your foot sage window of the odometer) will illuminate, showing off the accelerator and the vehicle will operate at the that the Electronic Speed Control system is on. To turn selected speed.
Page 166: Varying The Speed Setting
Press the accelerator as you normally would. When the increase. Each time the Electronic Speed Control lever is pedal is released, the vehicle will return to the set speed. tapped speed increases, so tapping the Electronic Speed Control lever three times will increase speed by 3 mph NOTE: The Electronic Speed Control system maintains (4.8 km/h), etc.
Page 167: Parksense Rear Park Assist - If Equipped
REVERSE. If ParkSense is enabled at this shift lever hicle could go too fast for the conditions, and you position, the system will be active until the vehicle speed could lose control. An accident could be the result. is increased to approximately 11 mph (18 km/h) or Do not use Electronic Speed Control in heavy traffic above.
Page 168: Parksense Sensors
The ParkSense sensors, located in the rear fascia/ The ParkSense Warning screen will only be displayed if bumper, monitor the area behind the vehicle that is Sound and Display is selected from the Customer- within the sensors’ field of view.
Page 169: Parksense Display
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 ParkSense Display When the vehicle is in REVERSE, the warning display will turn ON indicating the system status. ParkSense Warning Display Park Assist ON...
Page 170 The system will indicate a detected obstacle by showing three solid arcs and will produce a ⁄ second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Fast Tone Continuous Tone The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone. The following chart shows the warning display operation when the system is detecting an obstacle:...
Page 172 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING DISPLAY DISTANCES DISPLAY MESSAGE OBSTACLE DISTANCE FROM: ARC’s AUDIBLE SIGNAL REAR CORNERS REAR CENTER Park Assist ON None None Warning Object Detected 78.7 in (200 cm) 3 Solid Yes, 1/2 second Warning Object Detected 39.3 in (100 cm)
Page 173: Enabling/Disabling Parksense
EVIC will display the “PARK mud, dirt and debris, see your authorized dealer. ASSIST DISABLED” message for as long as the vehicle is Cleaning ParkSense in REVERSE.
Page 174: Parksense System Usage Precautions
ParkSense is turned off, the instrument not detect an obstacle behind the fascia/bumper, or it cluster will display “PARK ASSIST DISABLED” mes- could provide a false indication that an obstacle is sage for as long as the vehicle is in REVERSE. behind the fascia/bumper.
Page 175 ParkSense sensors will not be detected when they are in close proximity. • The vehicle must be driven slowly when using ParkSense to be able to stop in time when the obstacle is detected. It is recommended that the driver looks over his/her shoulder when using ParkSense .
Page 176: Parkview Rear Back Up Camera - If Equipped
Back Up Camera that allows you to see an on-screen mount and hitch ball assembly is disconnected image of the rear of your vehicle whenever the shift lever from the vehicle when the vehicle is not used for is put into REVERSE. The image will be displayed on the towing.
Page 177: Turning Parkview On Or Off - With Navigation Radio
6. When the vehicle is shifted into REVERSE, an image of NOTE: If snow, ice, mud, or anything else builds up on the rear of the vehicle will appear with a caution note to the camera lens, clean the lens, rinse with water, and dry check entire surroundings displayed across the top of with a soft cloth.
Page 178: Turning Parkview On Or Off - Without Navigation Radio
4. When the vehicle is shifted into REVERSE, an image of Automatic Temperature Control Sensor (ATC equipped the rear of the vehicle will appear with a caution note to only), two swiveling LED lights, flip-down sunglass check entire surroundings displayed across the top of storage, conversation mirror, optional power sliding door the screen.
Page 179 The courtesy lights also function as reading lights. Press in on each lens to turn these lights on while inside the vehicle. Press a second time to turn each light off. You may adjust the direction of these lights by pressing the outside ring, which is identified with four directional arrows (LED lamps only).
Page 180 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE From the closed position, press the door over-travel latch to open the compartment. The door will slowly rotate to the full open position. From this position, the door can be fully closed or, by rotating upward about 3/4 of the way and releasing, positioned for conversation mirror use.
Page 181: Garage Door Opener - If Equipped
Press the lens a second time to turn each light off. door openers, motorized gates, lighting or home security You may adjust the direction of these lights by pressing systems.
Page 182 • Vehicle exhaust contains carbon monoxide, a dan- HomeLink Buttons gerous gas. Do not run your vehicle in the garage NOTE: HomeLink is disabled when the Vehicle Secu- while training the transceiver. Exhaust gas can rity Alarm is active.
Page 183: Programming Homelink
When it changes, it is programmed. It may take up to transmission of the radio-frequency signal. 30 seconds or longer in rare cases. The garage door may Your vehicle should be parked outside of the garage open and close while you train. when programming.
Page 184 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After training a HomeLink channel, if the garage This can usually be found where the hanging antenna door does not operate with HomeLink and the ga- wire is attached to the garage door opener motor. It is...
Page 185 LEARN button has been pressed. transmitter of the device may also be used at any time. 7. Return to the vehicle and press the programmed Reprogramming a Single HomeLink Button HomeLink button twice (holding the button for two To reprogram a channel that has been previously trained, seconds each time).
Page 186: Gate Operator/Canadian Programming
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming successfully accepted the frequency signal. The indica- Canadian radio frequency laws require transmitter sig- tor light will flash slowly and then rapidly when fully nals to time-out (or quit) after several seconds of trans- trained.
Page 187: Troubleshooting Tips
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 Troubleshooting Tips 2. This device must accept any interference that may be If you are having trouble programming HomeLink , here received including interference that may cause undesired are some of the most common solutions: operation.
Page 188: Power Sunroof Operation
WARNING! seat belt properly and make sure all passengers are properly secured. Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unattended children, can become entrapped by the power sun- roof while operating the power sunroof switch. Such...
Page 189 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Express Open WARNING! Press the switch rearward and release, and the sunroof will open automatically from any position. The sunroof Do not allow small children to operate the sunroof. will open fully, then stop automatically. This is called Never allow your fingers, other body parts, or any “Express Open”.
Page 190: Electrical Power Outlets - If Equipped
The upper power outlet will also operate a conventional ears. Your vehicle may exhibit wind buffeting with the cigar lighter unit (if equipped with an optional Smoker’s windows down, or the sunroof (if equipped) in certain Package).
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 The outlet in the rear quarter panel near the liftgate and the upper outlet in the instrument panel are both con- trolled by the ignition switch. Each of these outlets can support 160 Watts (13 Amps). Do not exceed 160 Watts (13 Amps) for each of these outlets.
Page 192 • After the use of high power draw accessories, or long periods of the vehicle not being started (with CAUTION! accessories still plugged in), the vehicle must be • Many accessories that can be plugged in draw driven a sufficient length of time to allow the alternator to recharge the vehicle’s battery.
Page 193: Power Inverter - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 POWER INVERTER — IF EQUIPPED A 110 Volt, 150 Watt inverter outlet (if equipped) converts DC current to AC current, and is located on the left rear trim panel immediately behind the second row left passenger seat.
Page 194: Cupholders
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To turn on the power outlet, press the switch once. Press CUPHOLDERS the switch a second time to turn the power outlet off. There are nine cupholders in the interior. Two cupholders in the center front instrument panel, four in the floor consoles and three more are located in the third row quarter trim panel.
Page 195: Instrument Panel Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 Instrument Panel Cupholders Pull the drawer out firmly until it stops, and place the The instrument panel cupholders are located in a pull-out container to be held in either one of the cupholder wells.
Page 196: Smoker's Package Kit - If Equipped
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Two outboard mesh pockets are on intermediate seating. WARNING! The mesh pockets are flexible enough to hold juice boxes, toys, games or MP3 players, etc. If containers of hot liquid are placed in the bottle holder, they can spill when the door is closed, burn- Smoker’s Package Kit —...
Page 197: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 STORAGE Glove Compartments Upper Glove Compartment To open the upper compartment, press inward on the release button (2). The door will spring open about 1 in (2.54 cm). Manually lift the front edge of the door upward, until fully opened, and the detent is engaged.
Page 198: Door Trim Panel Storage
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Trim Panel Storage Driver Seatback Storage — If Equipped The drivers seatback has a primary storage pocket on all Front Door Storage models and an optional secondary mesh pocket. Both interior front door panels have multiple pockets for storage.
Page 199: Umbrella Holder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 Umbrella Holder Second Row Floor Storage Bins An umbrella holder has been conveniently molded into The area below the floor covers, located in front of the the left front door entry scuff molding.
Page 200: Storage Bin Safety Warning
Once in the storage bin, storage bin covers are not properly latched. young children may not be able to escape. If • Do not drive the vehicle with the storage bin trapped in the storage bin, children can die from covers open.
Page 201 Seat Storage Bin Cover Emergency Release Lever Storage Bin Cover Emergency Release Lever As a security measure, your vehicle may be built with a NOTE: In the event of an individual being locked inside Storage Bin Cover Emergency Release is built into the the storage bin, the storage bin cover can be opened from storage bin cover latching mechanism.
Page 202: Center And Rear Overhead Console Storage - If Equipped
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Center And Rear Overhead Console Storage — If Coat Hooks Equipped Coat hooks are located along the headliner for the second The overhead storage system comes in several options. and third row seating positions. The coat hook load limit is 10 lbs (4.5 kg).
Page 203: Console Features
• The cupholders are removable to access a large storage bin. • The basic console is removable from the vehicle for additional floor space by removing the cap and clip at Rear Cargo Area Loading Limit the console base.
Page 204: Premium Console - If Equipped
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Reinstall The Basic Floor Console Premium Console — If Equipped The three-compartment console with sliding storage bin, 1. Position the console at a slight angle (front slightly sliding upper tray with storage and large console storage higher than the rear).
Page 205 The cupholders will also accommodate large • Removable from vehicle for additional floor space. size cups and 20 oz (.6 L) bottles. Position 1 shows the console closed with four cupholders and a convenient storage tray.
Page 206 206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Position 2 shows the raised storage tray revealing a large Dual Storage Bins storage area below. Position 3 shows the top portion of the console in a rearward position. This is accomplished by lifting the upper most latch at the front of the console.
Page 207 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 Position 4 shows the complete console in its rearmost 2. Lift the rear of the console up several inches/centi- position. Again, lifting second latch handle at the front of meters. the console, allows complete access to a lower storage bin 3.
Page 208: Rear Window Features
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: WARNING! • You can turn off the heated mirror feature at anytime by pressing the rear window defroster switch a second In an accident, serious injury could result if the time. removable floor console is not properly installed.
Page 209: Load-Leveling System
A hydraulic pump contained within the shock absorbers at the upper edge of each crossbar approximately six raises the rear of the vehicle to the correct height. It takes turns, then move the crossbar to the desired position, approximately 1 mile (1.6 km) of driving for the leveling keeping the crossbars parallel to the rack frame.
Page 210 CAUTION! (Continued) crossbars make sure the arrows marked on the underside • To avoid damage to the roof rack and vehicle, do not of the crossbars are facing the front of the vehicle. When exceed the maximum roof rack load capacity of the crossbars are not in use, the front crossbar should be 150 lbs (68 kg).
Page 211: Sun Screens - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the Roof Rack Cautions when carrying cargo on your roof rack.
Page 212 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gently pull up on the tab to raise the sun screen. Once the screen is completely to the top of the window, Continue pulling the sun screen until the tab is near the extend the top bar of the sun screen over the two hooks top of the window.
Page 213 Instrument Panel Features ....217 Electronic Vehicle Information Center (EVIC) — If Equipped ......236 Instrument Cluster .
Page 214 214 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM/CD/DVD Radio (RER & RBZ) – Sales Code RES/RSC — AM/FM Stereo Radio If Equipped ......248 With CD Player (MP3 AUX Jack) And Sirius Radio.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 215 ▫ Play Mode ......274 ▫ Operating Instructions - uconnect™ phone (If Equipped) .
Page 216 216 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Three-Zone Temperature Control — ▫ Winter Operation ....305 If Equipped ......291 ▫...
Page 217: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 217 INSTRUMENT PANEL FEATURES 1 — Air Vents 5 — Analog Clock 9 — DVD – If Equipped 13 — Switch Bank 2 — Instrument Cluster 6 — Upper Glove Compartment 10 — Cup Holders 14 — Ignition Switch 3 —...
Page 218: Instrument Cluster
218 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 219: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 219 INSTRUMENT CLUSTER DESCRIPTIONS vehicle has completely stopped and the shift lever is placed in the PARK position, the light should turn off. 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when If the light remains lit with the engine running, your the ignition switch is in the ON position.
Page 220 220 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle is experiencing a problem with the charging As an added safety feature, your vehicle has been system. Obtain SERVICE IMMEDIATELY. See an autho- equipped with a Tire Pressure Monitoring System rized dealer. (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated.
Page 221 TPMS, as damage to the sensors may result. alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the 6. Oil Pressure Warning Light TPMS malfunction telltale after replacing one or more This light indicates low engine oil pressure.
Page 222 If the light turns on while driving, safely pull over and chime will sound for four minutes when this light turns stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the ve- hicle.
Page 223 The vehicle should have service performed, and Brake Booster has been detected by the Anti-Lock Brake the brake fluid level checked.
Page 224 Part of the brake system may have failed. NOTE: This light shows only that the parking brake is It will take longer to stop the vehicle. You could have applied. It does not show the degree of brake application.
Page 225 ESC system. If this light remains on after indicates that the Anti-Lock portion of the brake system several ignition cycles, and the vehicle has been driven is not functioning and that service is required. However, several miles (kilometers) at speeds greater than 30 mph...
Page 226 MIL after 18. Seat Belt Reminder Light engine start. The vehicle should be serviced if the light When the ignition switch is first turned ON, this stays on through several of your typical driving cycles. In...
Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 227 20. Airbag Warning Light CAUTION! This light turns on and remains on for seven seconds as a bulb check when the ignition Prolonged driving with the MIL on could cause switch is first turned ON. If the light is not on damage to the engine control system.
Page 228 If temperature gauge reads “H” either of two trip odometer settings or the ECO display. pull over and stop the vehicle. Idle the vehicle with The letter “A” or “B” will appear when in the trip the air conditioner turned off until the pointer drops odometer mode.
Page 229 Exceeds Safe Threshold depending on driving habits and vehicle usage. Press the noFUSE ......Fuse Fault Odometer / Trip Odometer / ECO (Fuel Saver Indicator) CHAngE OIL .
Page 230 NOTE: When this message is displayed, bring the gASCAP vehicle to a stop and idle the engine until the message If the vehicle diagnostic system determines that the fuel clears. filler cap is loose, improperly installed, or damaged, a noFUSE “gASCAP”...
Page 231 To reset the oil change indicator vehicle ownership, the seller certify to the purchaser the system (after performing the scheduled maintenance), correct mileage that the vehicle has been driven. If your perform the following steps. odometer needs to be repaired or serviced, the repair technician should leave the odometer reading the same 1.
Page 232: Compass Mini-Trip Computer (Cmtc) - If Equipped
28. Fuel Door Reminder direction the vehicle is facing, and the current radio The arrow in this symbol is a reminder that the station. For more information refer to “Compass Mini- Fuel Filler Door is located on the left side of the Trip Computer”...
Page 233: Cmtc Reset Buttons
UNDERSTANDING YOUR INSTRUMENT PANEL 233 • If the vehicle is equipped with a Chrysler uconnect™ To reset the display shown, turn the ignition switch to the gps (Navigation Radio), the NAV system will provide ON position, then press and hold the reset button for the compass direction, and the variance and calibra- approximately two seconds.
Page 234: Compass/Temperature Display
Trip A ing to the variance map for the zone where the vehicle Shows the total distance traveled for Trip A since the last will be driven. When properly set, the compass will reset.
Page 235 UNDERSTANDING YOUR INSTRUMENT PANEL 235 • Magnetic and battery powered devices, (such as cell To Set the Variance phones, iPod’s, radar detectors, PDA’s and laptops) Start the engine and leave the transmission gear selector should be kept away from the top of the instrument lever in the PARK position.
Page 236: Electronic Vehicle Information Center (Evic) - If Equipped
CAL indicator on continuously in the display. 4. To complete the compass calibration, drive the vehicle in one or more complete 360–degree circles, under 5 mph (8 km/h) in an area free from power lines and large metallic objects, until the CAL indicator turns off.
Page 237 UNDERSTANDING YOUR INSTRUMENT PANEL 237 • Vehicle information warning message displays Press and release the MENU button, and the mode displayed will change between Compass/ • Tire Pressure Monitor System Temperature, Trip, System Status, and Personal • Personal Settings (Customer-Programmable Features) Settings.
Page 238: Electronic Vehicle Information Center (Evic) Displays
When the appropriate conditions exist, the EVIC displays the following messages: • Left Rear Turn Signal Light Out • Door(s) Ajar (with a single chime, if vehicle is in • Right Front Turn Signal Light Out motion) • Right Rear Turn Signal Light Out •...
Page 239 • Blind Spot System Not Available — This message is Oil Change Required displayed to indicate the Blind Spot Monitor (BSM) Your vehicle is equipped with an engine oil change system is temporarily unavailable due to sensor block- indicator system. The Oil Change Required message will...
Page 240: Trip Functions
Average Fuel Economy to a text display of LOW FUEL. This display will Shows the average fuel economy since the last reset. continue until the vehicle runs out of fuel. Adding a When the fuel economy is reset, the display will read...
Page 241: Compass Display / Eco (Fuel Saver Mode) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 241 significant amount of fuel to the vehicle will turn off the Compass Display / ECO (Fuel Saver Mode) — If LOW FUEL text and a new DTE value will display. Equipped The compass readings indicate the direction Elapsed Time the vehicle is facing.
Page 242 Calibration Mode manually, as follows: differences, the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly 1. Turn ON the ignition switch. set, the compass will automatically compensate for the 2.
Page 243: Personal Settings (Customer-Programmable Features)
(Customer-Programmable Features) Personal Settings allows you to set and recall features when the transmission is in PARK. If the transmission is out of PARK or the vehicle begins moving, a warning Compass Variance Map message PERSONAL SETTING NOT AVAILABLE , 1.
Page 244 When ON is selected, all doors will lock automatically the doors will unlock on the first press of the RKE when the vehicle reaches a speed of 15 mph (24 km/h). transmitter UNLOCK button. To make your selection, To make your selection, press and release the RESET press and release the RESET button until “Driver Door...
Page 245 ON or OFF appears. Tilt MIRR. In Reverse Headlamp Off Delay When this feature is selected and the vehicle is placed in When this feature is selected, the driver can choose to a reverse gear, the driver’s side mirror will tilt downward...
Page 246 10 minutes Alert Lights” mode. When this mode is selected the Blind after the ignition switch is turned OFF. Opening a vehicle Spot Monitor (BSM) system is activated and will only door will cancel this feature.
Page 247 REVERSE and the RKE transmitter LOCK button is pressed. This feature the vehicle speed is less than 11 mph (18 km/h). The may be selected with or without the Flash Lamp Lock system can be enabled with Sound Only, Sound and feature.
Page 248: Am/Fm/Cd/Dvd Radio (Rer & Rbz)
248 UNDERSTANDING YOUR INSTRUMENT PANEL Display ECO — If Equipped The RBZ and RER radios contain a CD/DVD player, USB The “ECO” message can be turned on or off. To make port, and a 30-gigabyte hard drive (HDD). Sirius Satellite your selection, press and release the FUNCTION SE- Radio is optional.
Page 249: Clock Setting Procedure - Rbz Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 249 Clock Setting Procedure — RBZ Radio Changing Daylight Savings Time When selected, this feature will display the time of day in To Manually Set the Clock daylight savings time. Proceed as follows to change the 1.
Page 250: Clock Setting Procedure - Rer Radio
250 UNDERSTANDING YOUR INSTRUMENT PANEL 3. When this feature is on, a check mark will appear in Clock Setting Procedure — RER Radio the box next to the words “Show Time if Radio is Off.” uconnect gps Touch the screen where the words “Show Time if Radio is The GPS receiver used in this system is synchronized to Off”...
Page 251 UNDERSTANDING YOUR INSTRUMENT PANEL 251 5. To move the minute forward, touch the screen where 3. When this feature is on, a check mark will appear in the word “Min” with the arrow pointing upward is the box next to the words “Daylight Savings.” Touch the displayed.
Page 252: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
252 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone SALES CODE RES — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) 1. Turn on the radio. NOTE: The radio sales code is located on the lower right 2. Touch the screen where the time is displayed. side of the radio faceplate.
Page 253: Operating Instructions - Radio Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 253 Operating Instructions — Radio Mode SEEK Buttons Press and release the SEEK buttons to search for the next NOTE: The ignition switch must be in the ON or ACC listenable station in AM/FM mode. Press the right switch position to operate the radio.
Page 254 254 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Adjust the minutes using the right side TUNE/ Push the rotary TUNE/SCROLL control knob a second SCROLL control knob. Press the TUNE/SCROLL control time and MID will display. Turn the TUNE/SCROLL knob to save time change. control knob to the right or left to increase or decrease the mid-range tones.
Page 255 UNDERSTANDING YOUR INSTRUMENT PANEL 255 AM/FM Button display window. Each button can be set for SET 1 and Press the buttons to select either AM or FM mode. SET 2 in both AM and FM. This allows a total of 12 AM and 12 FM stations to be stored into pushbutton memory.
Page 256: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
256 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — CD MODE For CD And If you insert a disc with the ignition ON and the radio MP3 Audio Play ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will NOTE: show the track number, and index time in minutes and •...
Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 257 EJECT Button - Ejecting a CD TIME Button Press the EJECT button to eject the CD. Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold the FF (Fast Forward) button and the CD If you have ejected a disc and have not removed it within...
Page 258: Notes On Playing Mp3 Files
258 UNDERSTANDING YOUR INSTRUMENT PANEL Press the RND button a second time to stop Random The radio uses the following limits for file systems: Play. • Maximum number of folder levels: 8 Notes on Playing MP3 Files • Maximum number of files: 255 The radio can play MP3 files;...
Page 259 UNDERSTANDING YOUR INSTRUMENT PANEL 259 Multisession disc formats are supported by the radio. rates (VBR) are also supported. The majority of MP3 files Multisession discs may contain combinations of normal use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or CD audio tracks and computer files (including MP3 files).
Page 260: Operation Instructions - Auxiliary Mode
MP3 player, or cassette player, and utilize the vehicle’s time to start playing the MP3 files.
Page 261: Sales Code Res/Rsc - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 261 SALES CODE RES/RSC — AM/FM STEREO Operating Instructions — Radio Mode RADIO WITH CD PLAYER (MP3 AUX JACK) AND NOTE: The ignition switch must be in the ON or ACC SIRIUS RADIO position to operate the radio. NOTE: The radio sales code is located on the lower right Power Switch/Volume Control (Rotary) side of the radio faceplate.
Page 262 Voice Recognition System (Radio) — If Equipped Refer to “Voice Recognition (VR)” in the uconnect™ User If your vehicle is not equipped with or this feature is not Manual located on the DVD for further details. available on your vehicle, a “Not Equipped With UConnect”...
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 263 3. After adjusting the hours, press the right side TUNE/ INFO Button SCROLL control knob to set the minutes. The minutes Press the INFO button for an RDS station (one with call will begin to blink. letters displayed).
Page 264 264 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the MUSIC TYPE Button mid-range tones.
Page 265 UNDERSTANDING YOUR INSTRUMENT PANEL 265 Program Type 16-Digit Character Display Program Type 16-Digit Character Display College College Soft Rhythm and Blues Soft R&B Country Country Sports Sports Foreign Language Language Talk Talk Information Inform Top 40 Top 40 Jazz Jazz Weather Weather News...
Page 266 266 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button window. Select the button (1–6) you wish to lock onto this Pressing the SETUP button allows you to select between station and press and release that button. If a button is the following items: not selected within five seconds after pressing the SET/ RND button, the station will continue to play but will not •...
Page 267: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 267 DISC/AUX Button radio display. If a CD does not go into the slot more than Pressing the DISC/AUX button will allow you to switch 1.0 in (2.5 cm), a disc may already be loaded and must be from AM/FM modes to DISC/AUX mode.
Page 268 268 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Button CAUTION! (Continued) Press the right SEEK button for the next selection on the • Dual-media disc types (one side is a DVD, the CD. Press the left SEEK button to return to the beginning other side is a CD) should not be used, and they of the current selection, or return to the beginning of the can cause damage to the player.
Page 269: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 269 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 270 270 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the • Level 1: 12 (including a separator . and a three- following table are supported.
Page 271: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 271 Playlist files are not supported. MP3 Pro files are not To increase the speed of disc loading, it is recommended supported. to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option Playback of MP3 Files before writing to the disc.
Page 272 Refer to “uconnect™ phone” in the uconnect™ User MP3 player or cassette player and utilize the vehicle’s Manual located on the DVD for further details. audio system to amplify the source and play through the vehicle speakers.
Page 273: Universal Consumer Interface (Uci) - If Equipped
UCI with these radios. feature to control the connected device. This feature allows you to plug an iPod into the vehicle’s Connecting The iPod sound system through a 16–pin connector, using the Use the provided connection cable to connect an iPod to provided interface cable.
Page 274: Using This Feature
UCI 16–pin connector port: • Use the TUNE control knob to select the next or • The iPod audio can be played on the vehicle’s sound previous track. system, providing metadata (artist, track title, album, etc.) information on the radio display.
Page 275 UNDERSTANDING YOUR INSTRUMENT PANEL 275 jump to the previous track in the list. Turning this beginning of the track. If you press the SEEK >> button at any other time in the track, will jump to button during play mode, it will jump to the next track the beginning of the current track.
Page 276: List Or Browse Mode
276 UNDERSTANDING YOUR INSTRUMENT PANEL • RND button (available on sales code RES radio only): knob fast will scroll through the list faster. During Pressing this button toggles between Shuffle ON and fast scroll, you may notice a slight delay in updating Shuffle OFF modes for the iPod .
Page 277 • Leaving the iPod (or any supported device) any- the second line. where in the vehicle in extreme heat or cold can • To Exit List mode without selecting a track, press the alter the operation or damage the device. Follow same PRESET button again to go back to Play the device manufacturer’s guidelines.
Page 278: Uconnect™ Studios (Satellite Radio) - If Equipped (Ren/Rer/Rbz/Res Radios Only)
With the ignition switch in the ON/RUN or ACC posi- radio system in your vehicle. Sirius will supply a wel- tion and the radio on, press the SETUP button and scroll come kit that contains general information, including using the TUNE/SCROLL control knob until Sirius ID is how to setup your on-line listening account.
Page 279: Selecting Uconnect™ Studios (Satellite) Mode
• The vehicle is parked in an underground parking Next, touch the SUBSCRIPTION tab on the touch screen. All the ESNs that apply to your vehicle will display. structure or under a physical obstacle. • Dense tree coverage may interrupt reception in the Selecting uconnect™...
Page 280: Operating Instructions - Uconnect™ Studios
280 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - uconnect™ studios INFO Button (Satellite) Mode Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- NOTE: The ignition switch must be in the ON or ACC able).
Page 281 UNDERSTANDING YOUR INSTRUMENT PANEL 281 or turning the TUNE/SCROLL control knob within five SET Button – To Set the Pushbutton Memory seconds will allow the program format type to be se- When you are receiving a channel that you wish to lected.
Page 282: Operating Instructions - Uconnect™ Phone (If Equipped)
282 UNDERSTANDING YOUR INSTRUMENT PANEL Every time a preset button is used, a corresponding NOTE: SIRIUS service is not available in Hawaii or button number will display. Canada and has limited coverage in Alaska. Buttons 1 - 6 Refer to your Video Entertainment System (VES)™, RER These buttons tune the radio to the channels that you Navigation, RBZ Multimedia or REN Multimedia User commit to pushbutton memory (12 Satellite stations).
Page 283 UNDERSTANDING YOUR INSTRUMENT PANEL 283 • Integrated remote storage in either screen location The LCD screen(s) are located in the overhead compart- ment console. • Three different medias can be played simultaneously (Cabin speakers and Headphone Channels 1 and 2) •...
Page 284: Remote Sound System Controls - If Equipped
284 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED VES™ Remote Control Location NOTE: Refer to the “uconnect™ studios” section of uconnect™ User Manual located on the DVD for further Remote Sound System Controls details. (Back View Of Steering Wheel) The remote sound system controls are located on the rear surface of the steering wheel, at the three and nine o’clock positions.
Page 285: Radio Operation
AM to FM, or Tape to CD track on the CD. Pressing the bottom of the switch once mode, depending on which radio is in the vehicle. will go to the beginning of the current track, or to the...
Page 286: Radio Operation And Cellular Phones
Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from 3. Do not apply paper or tape to the disc; avoid scratch- your radio. This condition may be lessened or eliminated ing the disc.
Page 287: Manual Heating And Air Conditioning System - If Equipped
Front Blower Control Equipped There are four blower speeds. Use this The controls for the manual system in this vehicle contain control to regulate the amount of air a series of outer rotary dials and inner push knobs. These forced through the system in any comfort controls can be set to obtain desired interior mode you select.
Page 288: Understanding Your Instrument Panel
288 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Mode Control (Air Direction) Use this control to regulate the tem- Mode control allows you to choose perature of the air inside the passenger from several selections of air distribu- compartment. Rotating the knob coun- tion.
Page 289 Press this button to choose between outside air intake or recirculation of the air inside the Mix Mode vehicle. A lamp will illuminate when you are in Air is directed through the floor, defrost and side RECIRCULATION mode. Only use the RECIR- window demist outlets.
Page 290 Conditioning (A/C). A light will illu- TION mode will cause windows to fog on the inside minate when the A/C System is en- because of moisture buildup inside the vehicle. For gaged. maximum defogging, select the outside air position. • In order to prevent fogging, when the RECIRCULA-...
Page 291: Three-Zone Temperature Control - If Equipped
With the Three-Zone Temperature Control System, each front seat occupant can independently control the Heat- ing, Ventilation, and Air Conditioning operations coming from the outlets on their side of the vehicle. Front Upper Three Zone Temperature Control 1 – Left Temperature 7 –...
Page 292: Rear Manual Climate Control - If Equipped
The rear blower and temperature controls for the rear Front Lower Three-Zone Temperature Control Features seat passengers are located in the headliner, near the 1 – Left Heated Seat 3 – Rear Temperature center of the vehicle. 2 – Rear Blower 4 – Right Heated Seat...
Page 293 The rear blower control, located in the rear overhead console, has an off position and a range of blower speeds. This allows the second row seat occupants to control the volume of air circulated in the rear of the vehicle. Rear Manual Climate Controls 1 – Rear Blower 3 –...
Page 294 Do not block or place objects directly in front of the inlet grille or To change the temperature in the rear of the vehicle, heater outlets. The electrical system could overload, rotate the temperature control knob counterclockwise for causing damage to the blower motor.
Page 295: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 295 The rear airflow modes will mirror the front unit opera- Bi-Level Mode tion. Rear PANEL mode is automatically selected when Air comes from both the headliner outlets and the the front control is in the PANEL mode. When the front floor outlets.
Page 296 296 UNDERSTANDING YOUR INSTRUMENT PANEL • Occupants in the vehicle select AUTO mode operation by a button press on the right rotary knob and a comfort temperature setting using rotary knobs on the control unit. • The system can be controlled manually, if desired.
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 297 Automatic Operation 1. Press the AUTO button on the Front Upper ATC Panel and the word AUTO will illuminate in the front ATC display, along with three temperatures for driver, front passenger, and rear seats. The system will then automati- cally regulate the amount of airflow.
Page 298 If any one feature is controlled manually, customer-programmable feature. Refer to the “Elec- the temperature doors will continue to operate automati- tronic Vehicle Information Center (EVIC) — Customer- cally. Programmable Features” in this Section. The blower fan speed can be set to any fixed speed by...
Page 299 UNDERSTANDING YOUR INSTRUMENT PANEL 299 Panel Mode Floor Mode Air is directed through the outlets in the instrument Air comes from the floor outlets. A slight amount of panel. These outlets can be adjusted for direction, air is directed through the defrost and side window and turned on or off to control airflow.
Page 300 RECIRCULATION mode NOTE: LED and allow outside air into the vehicle. • If the system is in Mix or Defrost Mode, the SNOW- FLAKE can be turned off, but the A/C system shall NOTE: In cold weather, use of the RECIRCULATION remain active to prevent fogging of the windows.
Page 301 Rear Automatic Temperature Control (ATC) — If The Rear ATC System is located in the headliner, near the Equipped center of the vehicle. The Rear ATC System has floor air outlets at the rear of the right side sliding door, and overhead outlets at each outboard rear seating position.
Page 302 This allows the rear seat occupants to control the volume of air circulated in the rear of the vehicle.
Page 303 UNDERSTANDING YOUR INSTRUMENT PANEL 303 Rear Temperature Control CAUTION! To change the temperature in the rear of the vehicle, rotate the temperature knob counterclockwise to lower Interior air enters the Rear Automatic Temperature the temperature, and clockwise to increase the tempera- Control System through an intake grille, located in ture.
Page 304: Summer Operation
304 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Mode Control NOTE: In many temperature positions, the BI-LEVEL mode is designed to provide cooler air out of the head- Auto Mode liner outlets and warmer air from the floor outlets. The rear system automatically maintains the correct mode and comfort level desired by the rear seat occupants.
Page 305: Winter Operation
Winter Operation Window Fogging To ensure the best possible heater and defroster perfor- Vehicle windows tend to fog on the inside in mild, rainy mance, make sure the engine cooling system is function- and/or humid weather. To clear the windows, select...
Page 306: Operating Tips
306 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips A/C Air Filter— If Equipped On vehicles equipped with Automatic Temperature Con- trol (ATC), the climate control system filters out dust and pollen from the air. Refer to “Air Conditioning” in Sec- tion 7 of this manual for filter replacement instructions.
Page 307 STARTING AND OPERATING CONTENTS Starting Procedures ....311 Automatic Transaxle ....314 ▫...
Page 308 308 STARTING AND OPERATING Driving Through Water ....322 Tire Safety Information ....334 ▫...
Page 309 ..... . 371 ▫ E-85 General Information ....366 ▫ Vehicle Certification Label ....371...
Page 310 310 STARTING AND OPERATING ▫ Towing Tips ......388 Trailer Towing ......375 ▫...
Page 311: Starting Procedures
STARTING AND OPERATING 311 STARTING PROCEDURES Automatic Transaxle Before starting your vehicle, adjust your seat, adjust the The shift lever must be in the NEUTRAL or PARK inside and outside mirrors, fasten your seat belt, and if position before you can start the engine. Press the brake present, instruct all other occupants to buckle their seat pedal before shifting into any driving gear.
Page 312: Extreme Cold Weather (Below 20°F Or -29°C)
NOTE: This vehicle is equipped with a transaxle shift WARNING! (Continued) interlocking system. The brake pedal must be pressed • Do not attempt to push or tow your vehicle to get to shift out of PARK. it started. Vehicles equipped with an automatic Extreme Cold Weather (Below 20°F or –29°C)
Page 313: After Starting
The engine block heater cord is routed under the hood on the accelerator pedal and the key fob once the engine is the driver’s side of the vehicle. It has a removable cap running smoothly. that is located on the driver side of the Integrated Power Module.
Page 314: Automatic Transaxle
• Move the shift lever into PARK only after the reverse. You could lose control of the vehicle and hit vehicle has come to a complete stop. someone or something. Only shift into gear when the •...
Page 315: Brake/Transaxle Interlock System
Brake/Transaxle Interlock System This system prevents the key fob from being removed This vehicle is equipped with a Brake Transmission Shift unless the shift lever is in PARK. It also prevents moving Interlock System (BTSI) that holds the shift lever in the...
Page 316: Gear Ranges
The transaxle electronics are self- This range supplements the parking brake by locking the calibrating; therefore, the first few shifts on a new vehicle transaxle. The engine can be started in this gear. Never may be somewhat abrupt. This is a normal condition, and attempt to use PARK while the vehicle is in motion.
Page 317 • Unintended movement of a vehicle could injure ensure the shift lever is in the PARK position. those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is • When engaged in PARK, you will not be able to move running.
Page 318 318 STARTING AND OPERATING REVERSE DRIVE — Six-Speed Transaxle This range is for moving the vehicle backward. Shift into This range should be used for most city and highway REVERSE only after the vehicle has come to a complete driving. It provides the smoothest upshifts, downshifts, stop.
Page 319 Switching from ERS to DRIVE can be done at any vehicle speed. To shift from DRIVE mode to ERS mode, move the CAUTION! shift lever to the left (-) once.
Page 320 3. Turn the ignition switch to the OFF position. shift lever to the left (-). The transaxle will shift to the range from which the vehicle can best be slowed down. 4. Restart the engine. Reset Mode - Electronic Transaxle 5.
Page 321: Driving On Slippery Surfaces
You could lose control of the vehicle 5. Maintain sufficient distance between your vehicle and and possibly have an accident. Accelerate slowly and the vehicle in front of you to avoid a collision in a sudden carefully whenever there is likely to be poor traction stop.
Page 322: Flowing/Rising Water
• Determine the condition of the road or the path and cause your vehicle to sink into deeper water. that is under water and if there are any obstacles in...
Page 323 Therefore, after driving through Do not continue to operate the vehicle if any fluid standing water, drive slowly and lightly press on appears contaminated, as this may result in further the brake pedal several times to dry the brakes.
Page 324: Power Steering
If for some reason the power assist is interrupted, it will assist could pose a safety risk to yourself and others. still be possible to steer your vehicle. Under these condi- Service should be obtained as soon as possible. tions, you will observe a substantial increase in steering...
Page 325: Power Steering Fluid Check
Parts” in Section 7 for the correct fluid type. steering components. Such damage is not covered by the New Vehicle Limited Warranty. PARKING BRAKE When the parking brake is applied with the ignition switch ON, the “Brake Warning Light”...
Page 326 WARNING! • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also be certain to leave the transaxle in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury.
Page 327: Anti-Lock Brake System (Abs)
WARNING! (Continued) wheel lock-up and help avoid skidding on slippery • Never leave children alone in a vehicle. Leaving surfaces. unattended children in a vehicle is dangerous for a ABS is activated during braking under certain road or number of reasons.
Page 328: Anti-Lock Brake Warning Light
Pumping makes the stopping distance longer. Just All vehicle wheels and tires must be the same size and press firmly on your brake pedal when you need type, and tires must be properly inflated to produce to slow down or stop.
Page 329: Electronic Brake Control System
ELECTRONIC BRAKE CONTROL SYSTEM service is required. However, the conventional brake Your vehicle is equipped with an advanced electronic system will continue to operate normally if the “Brake brake control system that includes the Traction Control Warning Light”...
Page 330: Brake Assist System (Bas)
This ics from acting on the vehicle, nor can it increase will allow more engine torque to be applied to the wheel the traction afforded.
Page 331: Electronic Stability Control (Esc)
WARNING! or the safety of others. • The BAS cannot prevent the natural laws of phys- ics from acting on the vehicle, nor can it increase Electronic Stability Control (ESC) the traction afforded by prevailing road condi- The Electronic Stability Control (ESC) enhances direc- tions.
Page 332 • ESC cannot prevent accidents, including those path of the vehicle. When the actual path does not match resulting from excessive speed in turns, driving on the intended path, ESC applies the brake of the appro- very slippery surfaces, or hydroplaning.
Page 333 STARTING AND OPERATING 333 • The ESC system will make buzzing or clicking sounds several ignition cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph when it is active. This is normal; the sounds will stop...
Page 334: Tire Safety Information
Light” will be illuminated. When in the “Partial Off” mode, ESC will operate without engine torque manage- ment. This mode is intended to be used if the vehicle is in deep snow, sand or gravel conditions and more wheel spin than ESC would normally allow is required to gain traction.
Page 335 STARTING AND OPERATING 335 • LT (Light Truck) - Metric tire sizing is based on U.S. NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. The size designation for LT-Metric design standards. P-Metric tires have the letter “P” tires is the same as for P-Metric tires except for the molded into the sidewall preceding the size designa- letters “LT”...
Page 336 336 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 337 — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions — The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle loading, road conditions, and posted speed limits) Load Identification: ..blank..
Page 338: Tire Identification Number (Tin)
Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side. Tires...
Page 339: Tire Loading And Tire Pressure
This placard tells you important information about the: Tire Placard Location 1) number of people that can be carried in the vehicle NOTE: The proper cold tire inflation pressure is listed 2) total weight your vehicle can carry on the driver’s side B-Pillar.
Page 340 The vehicle maximum load on the tire must not exceed vehicle, locate the statement “The combined weight of the load carrying capacity of the tire on your vehicle. You occupants and cargo should never exceed XXX lbs or will not exceed the tire’s load carrying capacity if you XXX kg”...
Page 341 STARTING AND OPERATING 341 3. Subtract the combined weight of the driver and pas- 6. If your vehicle will be towing a trailer, load from your sengers from XXX lbs or XXX kg. trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available 4.
Page 342 342 STARTING AND OPERATING...
Page 343: Tires - General Information
Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause accidents. recommended load capacity for your vehicle. Never •...
Page 344 The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to The tire pressure should be checked and adjusted, and the right or left.
Page 345 “cold tire inflation pressure.” Cold tire inflation pressure outside temperature is 32°F (0°C), then the cold tire is defined as the tire pressure after the vehicle has not inflation pressure should be increased by 3 psi (21 kPa), been driven for at least three hours, or driven less than which equals 1 psi (7 kPa) for every 12°F (7°C) for this...
Page 346 You could have a The compact spare is for temporary emergency use with serious accident. Do not drive a vehicle loaded to the radial tires. It is engineered to be used on your style maximum capacity at continuous speeds above vehicle only.
Page 347 30 seconds continuously, without stop- failure and loss of vehicle control. ping. Refer to “Freeing A Stuck Vehicle” in Section 6 of this Do not install a wheel cover or attempt to mount a manual for additional information.
Page 348 348 STARTING AND OPERATING Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original-equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
Page 349 Some combinations Replacement Tires of unapproved tires and wheels may change sus- The tires on your new vehicle provide a balance of many pension dimensions and performance characteris- characteristics. They should be inspected regularly for tics, resulting in changes to steering, handling, and wear and correct cold tire inflation pressure.
Page 350: Tire Chains
350 STARTING AND OPERATING WARNING! (Continued) CAUTION! • Failure to equip your vehicle with tires having To avoid damage to your vehicle or tires, observe the adequate speed capability can result in sudden tire following precautions: failure and loss of vehicle control.
Page 351: Snow Tires
Snow tires generally have lower speed ratings than what turer, if different from the speed recommended by was originally equipped with your vehicle and should the vehicle manufacturer. not be operated at sustained speeds over 75 mph (120 km/h).
Page 352: Tire Pressure Monitor System (Tpms)
352 STARTING AND OPERATING unequal rates, and tend to develop irregular wear pat- terns. These effects can be reduced by timely rotation of tires. The benefits of rotation are especially worthwhile with aggressive tread designs such as those on All-Season type tires.
Page 353 This is defined as the tire in order for the “TPMS Warning Lamp” to be turned off. pressure after a vehicle has not been driven for more than The system will automatically update and the “TPMS three hours - and in outside ambient temperature.
Page 354 • Driving on a significantly under-inflated tire causes age. Do not use aftermarket sealants or balance beads if your vehicle is equipped with a TPMS, as the tire to overheat and can lead to tire failure. damage to the sensors may result.
Page 355: Base System
Sensors, mounted to each wheel as part of the valve Should this occur, you should stop as soon as possible, stem, transmit tire pressure readings to the Receiver check the inflation pressure of each tire on your vehicle, Module. and inflate each tire to the vehicle’s recommended cold...
Page 356 356 STARTING AND OPERATING NOTE: The vehicle may need to be driven for up to 3. Accumulation of excessive snow and/or ice around 20 minutes above 15 mph (25 km/h) to receive this the wheels or wheel housings. information. 4. Using tire chains on the vehicle.
Page 357: Premium System - If Equipped
• Three Trigger Modules (mounted in three of the four of the four active road tires. The vehicle may need to be wheel wells) driven for up to 20 minutes above 15 mph (25 km/h) for •...
Page 358 “TPMS Telltale Warning Light” will extinguish once the updated tire pressure(s) have been received. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) to receive this information. Check TPMS Message The “TPMS Telltale Warning Light”...
Page 359 3. Accumulation of excessive snow and/or ice around the wheels or wheel housings. Check TPM System Display 4. Using tire chains on the vehicle. If the ignition switch is cycled, this sequence will repeat, 5. Using wheels/tires not equipped with TPMS sensors.
Page 360 5. Once you repair or replace the original road tire, and tire that has a pressure below the low-pressure warning reinstall it on the vehicle in place of the compact spare, limit, upon the next ignition switch cycle, the “TPMS the TPMS will update automatically.
Page 361: Fuel Requirements
If you experience these of premium gasoline is not recommended, symptoms, try another brand of “regular” gasoline be- as it will not provide any benefit over regular gasoline in fore considering service for the vehicle. these engines.
Page 362: Reformulated Gasoline
The winter months to reduce carbon monoxide emissions. manufacturer recommends the use of gasolines that meet Fuels blended with these oxygenates may be used in the WWFC specifications if they are available.
Page 363: E-85 Usage In Non-Flex Fuel Vehicles
The manufacturer recommends that gasoline • increased risk for fuel system component corrosion without MMT be used in your vehicle. The MMT content of gasoline may not be indicated on the gasoline pump, To fix a Non-FFV vehicle inadvertently fueled once with...
Page 364: Materials Added To Fuel
MMT in Canada, because MMT can be used at levels CAUTION! higher than those allowed in the United States. MMT is prohibited in Federal and California reformu- Follow these guidelines to maintain your vehicle’s lated gasolines. performance: • The use of leaded gas is prohibited by Federal law.
Page 365: Carbon Monoxide Warnings
If the the manufacturer. vehicle is stopped in an open area with the engine running for more than a short period, adjust the NOTE: Intentional tampering with emissions control...
Page 366: Flexible Fuel (3.3L Engines Only) - If Equipped
366 STARTING AND OPERATING WARNING! (Continued) • Keep the liftgate closed when driving your vehicle to prevent carbon monoxide and other poisonous exhaust gases from entering the vehicle. FLEXIBLE FUEL (3.3L ENGINES ONLY) — IF EQUIPPED E-85 General Information The information in this section is for Flexible Fuel Ve- hicles (FFV) only.
Page 367: Ethanol Fuel (E-85)
Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank. Do not use E-85 as a cleaning agent and never use it near an open flame.
Page 368: Selection Of Engine Oil For Flexible Fuel Vehicles E-85 And Gasoline Vehicles
368 STARTING AND OPERATING • you drive the vehicle immediately after refueling for at Selection Of Engine Oil For Flexible Fuel Vehicles least 5 miles (8 km) E-85 and Gasoline Vehicles FFV vehicles operated on E–85 require specially formu- Observing these precautions will avoid possible hard lated engine oils.
Page 369: Cruising Range
The gas cap is located behind the fuel filler door on the that your vehicle is serviced with correct ethanol com- left side of the vehicle. If the gas cap is lost or damaged, patible parts. be sure the replacement cap is for use with this vehicle.
Page 370 • Tighten the fuel filler cap until you hear a “clicking” • Never have any smoking materials lit in or near sound. This is an indication that the fuel filler cap is the vehicle when the gas cap is removed or the properly tightened. tank filled.
Page 371: Loose Fuel Filler Cap Message
STARTING AND OPERATING 371 Loose Fuel Filler Cap Message If seats are removed for carrying cargo, do not exceed the If the vehicle diagnostic system determines that the fuel specified GVWR and GAWR. filler cap is loose, improperly installed, or damaged, a Vehicle Certification Label “gASCAP”...
Page 372: Starting And Operating
GAWR. WARNING! Curb Weight The curb weight of a vehicle is defined as the total weight Because the front wheels drive and steer the vehicle, of the vehicle with all fluids, including vehicle fuel, at full...
Page 373 The best way to figure out the total weight of your have exceeded either GAWR, but the total load is within vehicle is to weigh it when it is fully loaded and ready for the specified GVWR, you must redistribute the weight.
Page 374 2,544 lbs 2,544 lbs (1 154 kg) (1 154 kg) A loaded vehicle is shown in the above table. Note that neither the GVWR nor the GAWR capacities have been exceeded. NOTE: Refer to the “Vehicle Certification Label” at- tached to the rear of the driver’s door for your vehicle’s...
Page 375: Trailer Towing
The recommended way to and safely as possible. measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be To maintain warranty coverage, follow the requirements supported by the scale.
Page 376 This type of Trailer Tongue Weight (TW) hitch is the most popular on the market today and is The TW is the downward force exerted on the hitch ball commonly used to tow small- and medium-sized trailers.
Page 377 Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier tongue weights (TW), and may be required depending on vehicle and trailer configuration/loading to comply with gross axle weight rating (GAWR) requirements.
Page 378 378 STARTING AND OPERATING With Weight-Distributing Hitch (Correct) Improper Adjustment of Weight-Distributing Hitch (Incorrect)
Page 379 STARTING AND OPERATING 379 Trailer Hitch Classification TRAILER HITCH CLASSIFICATIONS Your vehicle may be factory-equipped for safe towing of Max. GTW Class trailers weighing over 2,000 lbs (907 kg) with the optional (Gross Trailer Wt.) Trailer Tow Prep Package. See an authorized dealer for...
Page 380 380 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. GCWR (Gross Com- Max. GTW Engine/Transaxle Frontal Area Max. Tongue Wt. bined Wt. Rating) (Gross Trailer Wt.) Up to 2 persons &...
Page 381 Gross Trailer Weight (GTW) on the tow hitch of your Always load a trailer with 60% to 65% of the weight in vehicle. Loads balanced over the wheels or heavier in the the front of the trailer. This places 10% to 15% of the...
Page 382 382 STARTING AND OPERATING which will cause loss of control of the vehicle and trailer. Consider the following items when computing the Failure to load trailers heavier in front is the cause of weight on the rear axle of the vehicle: many trailer accidents.
Page 383 STARTING AND OPERATING 383 Towing Requirements WARNING! To promote proper break-in of your new vehicle drive- train components, the following guidelines are recom- Improper towing can lead to an injury accident. mended: Follow these guidelines to make your trailer towing...
Page 384 Always connect the chains to 4. Trailer tongue weight rating for that trailer hitch. the frame or hook retainers of the vehicle hitch. (This requirement may limit the ability to always Cross the chains under the trailer tongue and achieve the 10% to 15% range of trailer tongue weight allow enough slack for turning corners.
Page 385 • Do not interconnect the hydraulic brake system or loaded, it should have its own brakes and they vacuum system of your vehicle with that of the trailer. should be of adequate capacity. Failure to do this This could cause inadequate braking and possible could lead to accelerated brake lining wear, higher personal injury.
Page 386 Towing Requirements — Trailer Lights and Wiring WARNING! Whenever you pull a trailer, regardless of the trailer size, • Do not connect trailer brakes to your vehicle’s stop lights and turn signals on the trailer are required for motoring safety.
Page 387 STARTING AND OPERATING 387 Four-Pin Connector Seven-Pin Connector 1 — Female Pins 4 — Park 1 — Battery 5 — Ground 2 — Male Pin 5 — Left Stop/Turn 2 — Backup Lamps 6 — Left Stop/Turn 3 — Ground 6 —...
Page 388: Towing Tips
(with six-speed trans- • Do not use in hilly terrain or with heavy loads. axle) while operating the vehicle under heavy operating conditions will improve performance and extend trans- • When using the speed control, if you experience speed axle life by reducing excessive shifting and heat build up.
Page 389: Recreational Towing (Behind Motorhome, Etc.)
NEUTRAL but do not increase engine idle speed. towing with all four wheels on the ground) is not recommended. • Highway Driving Reduce speed. NOTE: If the vehicle requires towing, make sure all four • Air Conditioning wheels are off the ground. Turn off temporarily.
Page 391: What To Do In Emergencies
▫ Jack Location ..... . . 394 Freeing A Stuck Vehicle ....408 ▫...
Page 392: Hazard Warning Flasher
This is an emergency warning system and should not be NOTE: There are steps that you can take to slow down used when the vehicle is in motion. Use it when your an impending overheat condition: vehicle is disabled and is creating a safety hazard for •...
Page 393: Jacking And Tire Changing
You could be crushed. Never get any part of your into the normal range. If the pointer remains on the body under a vehicle that is on a jack. If you need “H”, turn the engine off immediately, and call for to get under a raised vehicle, take it to a service service.
Page 394: Jack Location
The spare tire is stowed inside a protective cover located behind the rear left side trim panel in the rear cargo area. under the center of the vehicle by means of a cable winch Turn the two cover latches to release the cover.
Page 395: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 395 Preparations For Jacking 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid being hit when operating the jack or changing the wheel.
Page 396: Jacking Instructions
• Never start or run the engine with the vehicle on a jack. WARNING! • Do not let anyone sit in the vehicle when it is on a Carefully follow these tire changing warnings to jack. • Do not get under the vehicle when it is on a jack.
Page 397 This will allow enough slack in the cable to allow securely stowed, spares must be stowed with the you to pull the spare tire out from under the vehicle. valve stem facing the ground. • Turn on the Hazard Warning flasher.
Page 398 You could be crushed. Never get any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 399 • Rear jack locations are between a pair of down-facing tabs on the sill flange of the vehicle side body. • Front jack locations are on the sill flange of the vehicle side body, and align with front door edges.
Page 400 400 WHAT TO DO IN EMERGENCIES Jack Location...
Page 401 Do not pry the wheel cover off. Then pull the wheel off the hub. 7. Raise the vehicle by turning the jack screw to the right, using the swivel wrench. Raise the vehicle only until the 9.
Page 402: Wheel Nuts
402 WHAT TO DO IN EMERGENCIES 10. Lower the vehicle by turning the jack screw to the 13. Place the deflated (flat) tire and compact spare tire left. cover assembly. in the rear cargo area. Do not stow the deflated tire in the spare tire location. Have the full- 11.
Page 403: Secure The Spare Tire
Tighten the nuts to final torque in increments. Progress the occupants of the vehicle. Always stow the com- around the bolt circle, tightening the nut opposite to the pact spare tire with the cover assembly in the place nut just previously tightened until final torque is provided.
Page 404 control.
Page 405: Jump-Starting Procedure
JUMP-STARTING PROCEDURE • Battery fluid is a corrosive acid solution that can Do not attempt to push or tow your vehicle to get it cause serious burns; do not allow battery fluid to started. Vehicles equipped with an automatic transmis- contact eyes, skin or clothing.
Page 406 2. When a boost is provided by a battery in another WARNING! (Continued) vehicle, park that vehicle within booster cable reach and • A battery generates hydrogen gas which is flam- do not let the vehicles touch. Set the parking brake, place mable and explosive.
Page 407 WHAT TO DO IN EMERGENCIES 407 5. Connect the other cable, first to the negative terminal 6. Start the engine in the vehicle that has the booster of the booster battery, and then to the engine of the battery. Let the engine idle a few minutes, then start the vehicle with the discharged battery.
Page 408: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE may lead to transmission overheating and failure. If your vehicle becomes stuck in mud, sand or snow, it It can also damage the tires. Do not spin the can often be moved by a rocking motion. Turn your wheels above 30 mph (48 km/h).
Page 409: Towing A Disabled Vehicle
Do not spin your vehi- cle’s wheels faster than 30 mph (48 km/h) or for If the transmission is inoperative, or if the vehicle is to be longer than 30 seconds continuously without stop- towed more than 100 miles (160 km), the vehicle must be ping when you are stuck and do not let anyone near towed with the front wheels off the ground.
Page 410 CAUTION! (Continued) Special care must be taken when the vehicle is towed • Do not tow the vehicle from the rear. Damage to with the ignition in the OFF position. The only approved the rear sheet metal, liftgate and fascia will occur.
Page 411: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.3/3.8L ..413 Maintenance Procedures ....418 ▫ Engine Oil ......419 Engine Compartment —...
Page 412 ▫ License Lamp ..... . . 460 Vehicle Storage ..... . . 455 Fluids And Capacities .
Page 413: Engine Compartment - 3.3/3.8L
MAINTAINING YOUR VEHICLE 413 ENGINE COMPARTMENT — 3.3/3.8L 1 — Air Cleaner Filter 7 — Engine Oil Fill 2 — Automatic Transmission Dipstick (3.3L Only) 8 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 9 — Coolant Pressure Cap 4 —...
Page 414: Engine Compartment - 4.0L
414 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 4.0L 1 — Power Steering Fluid Reservoir 7 — Engine Oil Dipstick 2 — Air Cleaner Filter 8 — Engine Oil Fill 3 — Brake Fluid Reservoir 9 — Coolant Pressure Cap 4 — Battery 10 —...
Page 415: Onboard Diagnostic System - Obd Ii
Loose Fuel Filler Cap Message assist your service technician in making repairs. Al- If the vehicle diagnostic system determines that the fuel though your vehicle will usually be drivable and not filler cap is loose, improperly installed, or damaged, a need towing, see your authorized dealer for service as “gASCAP”...
Page 416: Emissions Inspection And Maintenance Programs
If the OBD II system should be determined not will turn on the MIL. Resolving the problem will turn the ready for the I/M test, your vehicle may fail the test. MIL light off. Your vehicle has a simple ignition key-actuated test, which you can use prior to going to the test station.
Page 417: Replacement Parts
MIL symbol come on as part of vehicle as you normally would in order for your OBD II a normal bulb check. system to update. A recheck with the above test routine may then indicate that the system is now ready.
Page 418: Dealer Service
CAUTION! systems may void your warranty and could result in civil penalties being assessed against you. • Failure to properly maintain your vehicle or per- form repairs and service when necessary could WARNING! result in more costly repairs, damage to other...
Page 419: Engine Oil
Checking the oil while the vehicle is on level ground will your vehicle and also allow extended maintenance improve the accuracy of the oil level readings. Maintain intervals.
Page 420 American Petroleum Institute (API) Engine Oil The oil change indicator system will remind you that it is Identification Symbol time to take your vehicle in for scheduled maintenance. This symbol means that the oil has Refer to the “Maintenance Schedule” in Section 8 for been certified by the American information on this system.
Page 421 Lubricants that do not have both the engine oil certifica- temperatures. This engine oil improves low temperature tion mark and the correct SAE viscosity grade number, starting and vehicle fuel economy. Your engine oil filler should not be used. cap also shows the recommended engine oil viscosity for your vehicle.
Page 422: Engine Oil Filter
Care should be taken in disposing of used engine oil and Refer to the “Maintenance Schedule” in Section 8 for the oil filters from your vehicle. Used oil and oil filters, proper maintenance intervals. indiscriminately discarded, can present a problem to the WARNING! environment.
Page 423: Exhaust System
Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the CAUTION! vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- The catalytic converter requires the use of unleaded plete exhaust system and adjacent body areas for broken, fuel only.
Page 424 In system. Do not park or operate your vehicle in areas the event of engine malfunction, particularly involv- where your exhaust system can contact anything that ing engine misfire or other apparent loss of perfor- can burn.
Page 425: Maintenance-Free Battery
• Do not shut OFF the engine or interrupt the ignition • Battery fluid is a corrosive acid solution and can when the transaxle is in gear and the vehicle is in burn or even blind you. Do not allow battery fluid motion.
Page 426: Air Conditioner Maintenance
• If a “fast charger” is used while the battery is in Do not use chemical flushes in your air conditioning the vehicle, disconnect both vehicle battery cables system as the chemicals can damage your air condi- before connecting the charger to the battery. Do tioning components.
Page 427 MAINTAINING YOUR VEHICLE 427 Refrigerant Recovery and Recycling WARNING! R-134a air conditioning refrigerant is a hydrofluoro- • Use only refrigerants and compressor lubricants carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- approved by the manufacturer for your air condi- ever, the manufacturer recommends that air conditioning tioning system.
Page 428 428 MAINTAINING YOUR VEHICLE A/C Air Filter — If Equipped Refer to the “Maintenance Schedule” in Section 8 for the proper maintenance intervals. WARNING! Do not remove the A/C air filter while the blower is operating or personal injury may result.
Page 429: Body Lubrication
MAINTAINING YOUR VEHICLE 429 hood latching components to ensure proper function. CAUTION! When performing other underhood services, the hood latch, release mechanism and safety catch should be The A/C air filter is labeled with an arrow to indicate cleaned and lubricated.
Page 430 430 MAINTAINING YOUR VEHICLE Avoid using the wiper blades to remove frost or ice from The washer fluid reservoir will hold a full gallon of fluid the windshield. Keep the blade rubber out of contact with when the Low Washer Fluid Light illuminates.
Page 431: Maintaining Your Vehicle ▫ Cooling System
MAINTAINING YOUR VEHICLE 431 Cooling System rusty in appearance, the system should be drained, flushed and refilled with fresh coolant. Check the front of WARNING! the A/C condenser for any accumulation of bugs, leaves, etc. If dirty, clean by gently spraying water from a garden •...
Page 432 (antifreeze) and may plug the radiator. • This vehicle has not been designed for use with Propylene Glycol-based engine coolant (anti- freeze). Use of Propylene Glycol-based engine...
Page 433 MAINTAINING YOUR VEHICLE 433 Adding Coolant Use only high purity water such as distilled or deionized Your vehicle has been built with an improved engine water when mixing the water/engine coolant (antifreeze) coolant (antifreeze) that allows extended maintenance solution. The use of lower quality water will reduce the intervals.
Page 434 • Do not use a pressure cap other than the one engine cold, the level of the engine coolant (antifreeze) in the coolant recovery bottle should be between the ranges specified for your vehicle. Personal injury or en- indicated on the bottle. gine damage may result.
Page 435 Points to Remember required, or if the level in the coolant recovery bottle NOTE: When the vehicle is stopped after a few miles (a does not drop when the engine cools, the cooling few kilometers) of operation, you may observe vapor system should be pressure tested for leaks.
Page 436: Brakes
Riding the brakes can lead to brake failure and • Keep the front of the radiator clean. If your vehicle is possibly an accident. Driving with your foot resting equipped with air conditioning, also keep the front of or riding on the brake pedal can result in abnormally the condenser clean.
Page 437 The proper type of brake fluid for your (Continued) vehicle is also labeled on the original factory installed hydraulic master cylinder reservoir. (Continued)
Page 438: Automatic Transaxle
The fluid level in the automatic transaxle should be the transmission fluid be maintained at the prescribed checked whenever the vehicle is serviced. Operation with level using the recommended fluid. No chemical flushes an improper fluid level will greatly reduce the life of the should be used in any transaxle;...
Page 439 Using a transmission fluid other than the following procedure must be used: manufacturer’s recommended fluid will result in 1. The vehicle must be on level ground. more frequent fluid and filter changes. Refer to “Fluids, Lubricants and Genuine Parts” in this sec- 2.
Page 440 CAUTION! or warm. Hot fluid is approximately 180°F (82°C), which is the normal operating temperature after the vehicle has Do not overfill. Dirt and water in the transaxle can been driven at least 15 miles (24 km). The fluid cannot be cause serious damage.
Page 441: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 441 the use of special dyes to aid in detecting fluid leaks. In road surfaces on which the vehicle is operated, extreme addition, avoid using transaxle sealers as they may hot or cold weather and other extreme conditions will adversely affect seals.
Page 442 The cost of such repairs is that may diminish the gloss or thin out the paint considered the responsibility of the owner. finish. • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective...
Page 443 Your authorized dealer • Remove as much of the stain as possible by blotting has touch up paint to match the color of your vehicle. with a clean, dry towel. Wheel and Wheel Trim Care •...
Page 444 444 MAINTAINING YOUR VEHICLE • For grease stains, apply MOPAR Multi-Purpose if absolutely necessary. Do not use harsh cleaners or Cleaner or a equivalent high quality cleaner to a clean, Armorall. Use MOPAR Total Clean or equivalent to damp cloth and remove the stain. Use a fresh, damp clean vinyl upholstery towel to remove soap residue.
Page 445 Cleaning Plastic Instrument Cluster Lenses reducing light output, avoid wiping with a dry cloth. To The lenses in front of the instruments in this vehicle are remove road dirt, wash with a mild soap solution fol- molded in clear plastic. When cleaning the lenses, care lowed by rinsing.
Page 446: Cleaning The Instrument Panel Cupholders
446 MAINTAINING YOUR VEHICLE 1. Clean with a wet soft rag. A mild soap solution may be Cleaning the Instrument Panel Cupholders used, but do not use high alcohol content or abrasive Removal cleaners. If soap is used, wipe clean with a clean damp Pull the flexible liner from the cupholder drawer starting rag.
Page 447: Fuses
MAINTAINING YOUR VEHICLE 447 Installation CAUTION! Place the liner into the cupholder drawer and press the • When installing the Totally Integrated Power liner into place so that the retention tabs seat into the corresponding openings in the drawer. Module cover, it is important to ensure the cover is properly positioned and fully latched.
Page 448 448 MAINTAINING YOUR VEHICLE The numbers inside the TIPM cover correspond to the FUSES/TIPM following table. Cartridge Mini- Cavity Description FUSES/TIPM Fuse Fuse Cartridge Mini- 30 Amp — Anti-Lock Brake Sys- Cavity Description Fuse Fuse Pink tem (ABS) Valve/ESP 40 Amp —...
Page 449 MAINTAINING YOUR VEHICLE 449 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse 30 Amp — Rear Blower — 15 Amp Center High Mounted Pink Blue Stop Light (CHMSL)/ Brake Switch 40 Amp — Starter Solenoid Green —...
Page 450 450 MAINTAINING YOUR VEHICLE FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 20 Amp Front Heated Seat — 10 Amp (Ignition Off Draw) Yellow (If Equipped) IOD-HVAC/ATC — 20 Amp Rear Heated Seat —...
Page 451 MAINTAINING YOUR VEHICLE 451 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 20 Amp Spare Fuse — 10 Amp Occupant Restraint Yellow Controller/Occupant Classification Module — 20 Amp Rear View Mirror (ORC/OCM) Yellow...
Page 452 452 MAINTAINING YOUR VEHICLE FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 15 Amp Cabin Compartment — 20 Amp Fuel Pump (FUEL Blue Node Interior Light Yellow PUMP), Diesel Lift (CCN INT LIGHT),...
Page 453 MAINTAINING YOUR VEHICLE 453 FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 10 Amp Next Generation Con- — 20 Amp Back-Up Lamps troller (NGC), PCM, Yellow (B/U LAMPS) Transmission Feed — 10 Amp...
Page 454 454 MAINTAINING YOUR VEHICLE FUSES/TIPM FUSES/TIPM Cartridge Mini- Cartridge Mini- Cavity Description Cavity Description Fuse Fuse Fuse Fuse — 10 Amp Park Assist (PRK — 20 Amp Power Outlet #3 ASST), Heater Ventila- Yellow (BATT) tion, Air Conditioning — 10 Amp...
Page 455: Vehicle Storage
MAINTAINING YOUR VEHICLE 455 • Anytime you store your vehicle, or keep it out of are fused with self-resetting fuses that are only service- able by an authorized dealer. The power seats are fused service for two weeks or more, run the air conditioning by a 30 Amp circuit breaker located under the driver’s...
Page 456: Bulb Replacement
Front Side Marker ..... . W5W yourself. If a headlamp bulb fails, take your vehicle to Headlamp — (Low and High Beam Halogen) ..H11 an authorized dealer for service.
Page 457: Quad Headlamps
MAINTAINING YOUR VEHICLE 457 3. Twist the headlamp bulb and pull the bulb from the WARNING! headlamp housing. A transient high voltage occurs at the bulb sockets of 4. Install the new headlamp bulb and twist until locked High Intensity Discharge (HID) headlamps when the into the headlamp housing.
Page 458: Front Side Marker Lamp
458 MAINTAINING YOUR VEHICLE 3. Push the new bulb into the socket and reinstall the Fog Lamp socket by twisting until locked into the headlamp NOTE: Access to the fog lamp bulb is from the rear of housing. the fascia. On the left rear side of the fascia, remove the...
Page 459: Rear Tail, Stop, Turn Signal, Side Marker And Backup Lamp
Tail Lamp Housing Fastener Removal NOTE: • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to scratch the paint.
Page 460: Center High-Mounted Stop Lamp (Chmsl)
460 MAINTAINING YOUR VEHICLE • The PRY location is best closest to the studs while 5. Replace the bulb, reinstall the socket, and reattach the dislodging them separately. lamp assembly. Center High-Mounted Stop Lamp (CHMSL) The CHMSL uses LED lamps that are not serviceable separately.
Page 461: Fluids And Capacities
MAINTAINING YOUR VEHICLE 461 FLUIDS AND CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.3L and 3.8L Engine (SAE 5W-20, API Certified) 5 Quarts 4.7 Liters 4.0L Engine (SAE 10W-30, API Certified) 5.5 Quarts 5.2 Liters Cooling System * 3.3L, 3.8L, and 4.0L Engine (MOPAR Engine Coolant/...
Page 462: Fluids, Lubricants And Genuine Parts
Use API Certified SAE 5W-20 Engine Oil, meeting the requirements Engine Oil (3.3L and 3.8L Engines) of Chrysler Material Standard MS-6395. Refer to your oil filler cap for correct SAE grade. Use API Certified SAE 10W-30 Engine Oil, meeting the requirements Engine Oil (4.0L Engine)
Page 463: Chassis
MAINTAINING YOUR VEHICLE 463 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transaxle MOPAR ATF+4 Automatic Transmission Fluid or equivalent. MOPAR DOT 3 and SAE J1703 should be used or equivalent. If Brake Master Cylinder DOT 3 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids.
Page 465 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..466 Maintenance Schedule ....466 ▫ Required Maintenance Intervals ..468...
Page 466 NOTE: Maintenance, replacement or repair of the emis- indicator message will illuminate. This means that ser- sions control devices and systems on your vehicle may be vice is required for your vehicle. Have your vehicle performed by any automotive repair establishment or...
Page 467 OFF. Checking the oil • Under no circumstances should oil change intervals level while the vehicle is on level ground will improve exceed 6,000 miles (10 000 km) or six months, which- the accuracy of the oil level reading. Add oil only ever comes first.
Page 468 • Check the fluid levels of the coolant reservoir, the Failure to perform the required maintenance items brake master cylinder, the power steering and the may result in damage to the vehicle. transaxle and add as needed. Required Maintenance Intervals •...
Page 469 ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 470: Service Schedule
Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 471 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 472 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 473 ❏ Rotate tires. ❏ Inspect the brake linings, replace if necessary. ❏ Change the automatic transaxle fluid & filter if using your vehicle for any of the following: police, taxi, fleet or frequent trailer towing. ❏ Flush and replace the engine coolant at 60 months if not done at 102,000 miles (170 000 km).
Page 474 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 475 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 476 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 477 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 478 ❏ Replace accessory drive belt(s). ❏ Change the automatic transaxle fluid & filter. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 479 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. ❏ Rotate tires. engine air cleaner filter, replace if necessary.
Page 480 480 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer...
Page 481 Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the filter. engine air cleaner filter, replace if necessary. ❏ Rotate tires.
Page 482 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 483: If You Need Consumer Assistance
Suggestions For Obtaining Service For Your Vehicle......485 Speech Impaired (TDD/TTY) ... . 487 ▫...
Page 484 484 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... 491 Publication Order Forms ....489 ▫...
Page 485: Suggestions For Obtaining Service For Your Vehicle
YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 486: Chrysler Group Llc Customer Center
Mexico, D. F. • Owner’s name and address In Mexico City: 5081-7568 Outside Mexico City: 1-800-505-1300 • Owner’s telephone number (home and office) • Authorized dealership name • Vehicle Identification Number (VIN) • Vehicle delivery date and mileage...
Page 487: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date. If you cation Devices for the Deaf) equipment at its customer have any questions about the service contract, call the center.
Page 488: Warranty Information (U.s. Vehicles Only)
WARNING! available from an authorized dealer. They are recom- Engine exhaust, some of its constituents, and certain mended for your vehicle in order to help keep the vehicle vehicle components contain, or emit, chemicals operating at its best. known to the State of California to cause cancer and REPORTING SAFETY DEFECTS birth defects, or other reproductive harm.
Page 489: In Canada
• Service Manuals In Canada These comprehensive Service Manuals provide the in- If you believe that your vehicle has a safety defect, you formation that students and professional technicians should contact the Customer Service Department imme- need in diagnosing/troubleshooting, problem solving, diately.
Page 490 490 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in acquaint you with specific Chrysler Group LLC ve- straightforward language with illustrations, diagrams, hicles. Included are starting, operating, emergency and charts. and maintenance procedures as well as specifications, capabilities and safety tips.
Page 491: Traction Grades
C. These grades represent the tire’s ability to stop on your vehicle. wet pavement, as measured under controlled conditions All passenger car tires must conform to Federal safety on specified government test surfaces of asphalt and requirements in addition to these grades.
Page 492: Department Of Transportation Uniform Tire ▫ Temperature Grades
C corresponds to a level of performance, which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law.
Page 493 INDEX...
Page 494 Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 422 Alterations/Modifications, Vehicle ... . . 7 Air Conditioner Maintenance ....426 Antenna, Satellite Radio .
Page 495 Brake/Transmission Interlock ....315 Break-In Recommendations, New Vehicle ..95 Battery ....... 425 Bulb Replacement .
Page 496 Climate Control ......286 Cargo (Vehicle Loading) ....202 Clock .
Page 497 Points to Remember ....435 Disabled Vehicle Towing ....409...
Page 498 Engine Oil ......422 Electronic Vehicle Information Domelight ......150 Center (EVIC) .
Page 499 INDEX 499 Flooded, Starting ..... . 312 Fabric Care ......444 Fuel Requirements .
Page 500 Garage Door Opener (HomeLink ) ... 181 Freeing A Stuck Vehicle ....408 Gas Cap (Fuel Filler Cap) .
Page 501 Gross Axle Weight Rating ....372,375 High Beam/Low Beam Select (Dimmer) Switch . . 156 Gross Vehicle Weight Rating ... . . 372,375 Hitches Trailer Towing .
Page 502 Key, Sentry (Immobilizer) ....14 Information Center, Vehicle ....236 Key-In Reminder .
Page 503 INDEX 503 Lights ......98,149 High Beam/Low Beam Select ... . . 156 Airbag .
Page 504 Memory Feature (Memory Seat) ... . . 143 Loading Vehicle ....202,371,373 Memory Seat .
Page 505 Viscosity ......421,461 New Vehicle Break-In Period ....95 Onboard Diagnostic System .
Page 506 506 INDEX Pets, Transporting ......91 Pretensioners Phone, Cellular ......108 Seat Belts .
Page 507 Inspection ......97 Safety Checks Inside Vehicle ....97 Pretensioners .
Page 508 508 INDEX Seats ....... . . 117 Service Engine Soon Light Adjustment .
Page 509 Tires ......98,343,491 Storing Your Vehicle ..... . 455 Aging (Life of Tires) .
Page 510 High Speed ......345 Disabled Vehicle ..... . . 409 Inflation Pressures .
Page 511 Trip Computer ......232 Vehicle Storage ..... . . 305,455 Trip Odometer .
Page 512 Rear Vent ......35 Washing Vehicle ......442 Windows, Express Down .
