Chrysler Pacifica 2020 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Pacifica and Voyager
2 0 2 0
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading

Related Manuals for Chrysler Pacifica 2020

Summary of Contents for Chrysler Pacifica 2020

  • Page 1 Pacifica and Voyager 2 0 2 0 O W N E R ’ S M A N U A L...
  • Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle.
  • Page 3 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Chrysler brand vehicle and to provide a convenient reference source for common questions.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................9 GETTING TO KNOW YOUR VEHICLE ...................11 GETTING TO KNOW YOUR INSTRUMENT PANEL ............126 SAFETY ............................152 STARTING AND OPERATING ....................216 IN CASE OF EMERGENCY ....................296 SERVICING AND MAINTENANCE ..................340 TECHNICAL SPECIFICATIONS .................... 383 MULTIMEDIA ..........................

  • Page 5: Introduction

    INTRODUCTION VEHICLE SECURITY ALARM — IF EQUIPPED..22 HEAD RESTRAINTS ..........52 To Arm The System ........22 Head Restraints — Front Seats....53 HOW TO USE THIS MANUAL........9 To Disarm The System ........ 22 Head Restraints — Second Row Quad Essential Information ........

  • Page 6: Getting To Know Your Instrument Panel

    EXTERIOR LIGHTS..........60 WINDOWS ............. 94 INTERNAL EQUIPMENT ........114 Multifunction Lever........60 Power Windows..........94 Storage............114 PANORAMIC SUNROOF — IF EQUIPPED ... 96 Sun Screens — If Equipped....... 118 Headlight Switch .......... 60 Daytime Running Lights (DRLs) — Power Outlets ..........119 Opening Sunroof..........

  • Page 7: Safety

    TRIP COMPUTER ..........140 OCCUPANT RESTRAINT SYSTEMS ....171 ENGINE BREAK-IN RECOMMENDATIONS ..222 WARNING LIGHTS AND MESSAGES ....140 Occupant Restraint Systems Features ..171 PARK BRAKE............222 Red Warning Lights........141 Important Safety Precautions....171 Electric Park Brake (EPB) ......222 Seat Belt Systems ........172 Yellow Warning Lights .......144 AUTOMATIC TRANSMISSION ......

  • Page 8: In Case Of Emergency

    ADAPTIVE CRUISE CONTROL (ACC) — PARKSENSE FRONT AND REAR PARK TRAILER TOWING ..........284 IF EQUIPPED ............236 ASSIST — IF EQUIPPED ........256 Common Towing Definitions .....284 Trailer Hitch Classification ......286 Adaptive Cruise Control (ACC) ParkSense Sensors ........257 Trailer Towing Weights (Maximum Trailer Operation............238 ParkSense Visual Alert ......257 Weight Ratings) ........286...

  • Page 9: Servicing And Maintenance

    JACKING AND TIRE CHANGING — SERVICING AND MAINTENANCE RAISING THE VEHICLE ........361 IF EQUIPPED ............314 TIRES ..............361 SCHEDULED SERVICING ........340 Jack And Spare Tire Location....314 Tire Safety Information ......361 Maintenance Plan ........341 Equipment Removal .........314 Tires — General Information ....369 Heavy Duty Use Of The Vehicle....343 Preparations For Jacking ......315 Tire Types ...........373...

  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES ..........387 STEERING WHEEL AUDIO CONTROLS — FLUIDS AND LUBRICANTS ........388 IF EQUIPPED ............461 IDENTIFICATION DATA ........383 Engine............388 Radio Operation......... 461 Vehicle Identification Number ....383 Chassis ............390 Media Mode..........461 BRAKE SYSTEM ..........383 AUX/USB/MP3 CONTROL ....... 461 WHEEL AND TIRE TORQUE MULTIMEDIA UCONNECT THEATER —...

  • Page 11: Customer Assistance

    Play A DVD/Blu-ray™ Or USB Media RADIO OPERATION AND CUSTOMER ASSISTANCE File From Uconnect System ......468 MOBILE PHONES..........485 SUGGESTIONS FOR OBTAINING SERVICE Disc Menu ..........470 Regulatory And Safety Information...485 FOR YOUR VEHICLE .......... 493 Blu-ray™ Controls – Disc Specific UCONNECT VOICE RECOGNITION Prepare For The Appointment ....
  • Page 12 INTRODUCTION HOW TO USE THIS MANUAL This Owner's Manual describes all versions of Dear Customer, this vehicle. Options and equipment dedicated Congratulations on selecting your new vehicle. Essential Information to specific markets or versions are not expressly Be assured that it represents precision work- indicated in the text.
  • Page 13 INTRODUCTION WARNINGS AND CAUTIONS WARNING! WARNING! This Owner’s Manual contains WARNINGS To prevent SERIOUS INJURY or DEATH when To prevent SERIOUS INJURY or DEATH: against operating procedures that could result using “Track-Use” parts and equipment: ALWAYS remove any “Track-Use” equip- ...
  • Page 14 GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED while the vehicle is in motion, the system will Features/Benefits display: Feature not available while the vehicle Pre-installed on your Uconnect touchscreen  Access your Owner’s Information right through is in motion.
  • Page 15 GETTING TO KNOW YOUR VEHICLE KEYS NOTE: In case the ignition switch does not change with The emergency key allows for entry into the the push of a button, the key fob may have a low Key Fob vehicle should the battery in the vehicle or the or fully depleted battery.
  • Page 16 GETTING TO KNOW YOUR VEHICLE To Unlock The Doors NOTE: To remove the emergency key, press the Your vehicle is equipped with Passive Entry; mechanical button on the side of the key fob NOTE: refer to “Keyless Enter-N-Go — Passive Entry” in with your thumb and pull the emergency key out Uconnect Settings lets you program the system to this chapter for further information.
  • Page 17 GETTING TO KNOW YOUR VEHICLE Key Fob Battery Replacement 1. Remove the emergency key by pushing the mechanical release button on the side of The recommended replacement battery is one the key fob with your thumb and then pull CR2032 battery. the key out with your other hand.
  • Page 18 GETTING TO KNOW YOUR VEHICLE Programming Additional Key Fobs programming a blank key fob to the vehicle electronics. A blank key fob is one that has Programming the key fob may be performed by never been programmed. an authorized dealer. NOTE: NOTE: When having the Sentry Key Immobilizer...
  • Page 19 GETTING TO KNOW YOUR VEHICLE The following features are always enabled when 1. This device may not cause harmful interfer- NOTE: this key is in use: ence, and Changes or modifications not expressly approved by the party responsible for compli- Entertainment audio muted if 1st row occu- ...
  • Page 20 GETTING TO KNOW YOUR VEHICLE ON/RUN NOTE: The key fob may not be able to be detected by Driving position  the vehicle keyless-go system if it is located next All the electrical devices are available  to a mobile phone, laptop or other electronic device;...
  • Page 21 GETTING TO KNOW YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED How To Use Remote Start WARNING! (Continued) If applicable, refer to the “Hybrid Supplement” If applicable, refer to the “Hybrid Supplement” Do not leave the key fob in or near the vehicle, ...
  • Page 22 GETTING TO KNOW YOUR VEHICLE Brake switch inactive (brake pedal not Remote Start Cancel Message — If Equipped NOTE:  pushed) The following messages will display in the If an engine fault is present or fuel level is  instrument cluster if the vehicle fails to remote Battery at an acceptable charge level low, the vehicle will start and then shut down ...
  • Page 23 GETTING TO KNOW YOUR VEHICLE To Exit Remote Start Mode And Drive The General Information La operación de este equipo está sujeta a las siguientes dos condiciones: Vehicle The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this Before the end of 15 minute cycle, push and 1.
  • Page 24 GETTING TO KNOW YOUR VEHICLE After placing the ignition switch in the ON/RUN All of the key fobs provided with your new When having the Sentry Key Immobilizer vehicle have been programmed to the vehicle System serviced, bring all vehicle keys with you position, the vehicle security light will turn on for three seconds for a bulb check.
  • Page 25 GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY ALARM — IF EQUIPPED Le présent appareil est conforme aux CNR 2. Perform one of the following methods to d`Innovation, Science and Economic Develop- lock the vehicle: The vehicle security alarm monitors the vehicle ment applicables aux appareils radio exempts Push lock on the interior power door lock ...
  • Page 26 GETTING TO KNOW YOUR VEHICLE Cycle the vehicle ignition system out of the alarm will arm regardless of whether you are in the ribbing is visible. To unlock the rear doors,  OFF position. the vehicle or not. If you remain in the vehicle rotate the door lock button until the red indi- and open a door, the alarm will sound.
  • Page 27 GETTING TO KNOW YOUR VEHICLE Central Lock/Unlock — If Equipped WARNING! (Continued) A power door lock switch is on each front door Never use the PARK position as a substi-  trim panel. Use this switch to lock or unlock the tute for the parking brake.
  • Page 28 GETTING TO KNOW YOUR VEHICLE Unlock Doors Automatically On Exit — If If wearing gloves on your hands, or if it has To Unlock From The Driver's Side:  been raining/snowing on the Passive Entry Equipped With a valid key fob within 5 ft (1.5 m) of the door handle, the unlock sensitivity can be driver’s door handle, grab the driver’s front door The Unlock Doors Automatically On Exit feature...
  • Page 29 GETTING TO KNOW YOUR VEHICLE To Unlock From The Passenger Side: A lock request is made by the door panel To Enter The Liftgate  switch while the door is open. With a valid key fob within 5 ft (1.5 m) of the With a valid key fob within 5 ft (1.5 m) of the lift- passenger door handle, grab the front gate, cycle the handle to open the liftgate and...
  • Page 30 GETTING TO KNOW YOUR VEHICLE unlock the doors, using either Passive Entry Le présent appareil est conforme aux CNR door handle. This is done to allow you to d`Innovation, Science and Economic Develop- check if the vehicle is locked by pulling the ment applicables aux appareils radio exempts door handle, without the vehicle reacting and de licence.
  • Page 31 GETTING TO KNOW YOUR VEHICLE Manual Sliding Side Door important when your vehicle is parked on Push the button on the key fob twice an incline as the door will slide faster in the within five seconds to open, close, or The sliding door may be opened from the inside downhill direction.
  • Page 32 GETTING TO KNOW YOUR VEHICLE There are power sliding side door switches WARNING! (Continued) located on the B-Pillar trim panel, just in front of the power sliding door for the rear seat Before driving off, check the instrument  passengers. cluster for a sliding door or door open message or warning indicator.
  • Page 33 GETTING TO KNOW YOUR VEHICLE When a valid kicking motion is completed, the If the power sliding doors encounters  sliding door will chime, the hazard lights will multiple obstructions within the same cycle, the system will automatically stop. flash and the sliding door will open almost instantaneously.
  • Page 34 GETTING TO KNOW YOUR VEHICLE To avoid unintentional operation of the power NOTE: Manual Adjustment (Front Seats) — If  sliding door from the rear seats, push the Equipped After disengaging (or engaging) the Child  Sliding Door Power Off button, located in the Protection Door Lock, always test the inside overhead console.
  • Page 35 GETTING TO KNOW YOUR VEHICLE Manual Front Adjuster Manual Reclining Seats — If Equipped WARNING! Both front seats are adjustable forward or rear- For models equipped with manual seats, the Adjusting a seat while driving may be  ward. The manual seat adjustment handle is recline lever is located on the outboard side of dangerous.
  • Page 36 GETTING TO KNOW YOUR VEHICLE Manual Adjustment (Rear Seats) Manual Recline — Quad Seats Second Row Bench Seat — If Equipped The second row bench seat can accommodate WARNING! two passengers, while providing easy access to the third row seats without any folding of the Adjusting a seat while the vehicle is moving ...
  • Page 37 GETTING TO KNOW YOUR VEHICLE Removing The Bench Seat NOTE: 1. Adjust the driver and passenger seats Due to the weight of the bench seat, it is  recommended that two people are utilized forward to allow room for the bench seat for its removal.
  • Page 38 GETTING TO KNOW YOUR VEHICLE Second Row Removable 8th Seat — If The release strap is located on the front of the To reinstall the seat, align the seat into the detent positions on the floor. Tilt seat rearward Equipped seat, near the floor.
  • Page 39 GETTING TO KNOW YOUR VEHICLE Fold-Flat — Quad Seats NOTE: Easy Entry If applicable, refer to the “Hybrid Supplement” If applicable, refer to the “Hybrid Supplement” The seatback may lock into the fold-flat  for additional information. for additional information. position.
  • Page 40 GETTING TO KNOW YOUR VEHICLE Easy Entry — With The Seat Folded Flat 2. Pull the strap on the back of the seat and the seat will tilt forward. The seats can be folded and tilted for more accessibility for passengers to enter and exit the third row.
  • Page 41 GETTING TO KNOW YOUR VEHICLE Exit For Third Row Passengers Manually Folding Third Row Seats — If 3. Pull release strap marked “2” and tumble the seat rearward into the storage bin. Equipped For passengers seated in the third row, there is a pull strap located on the outboard side of the 1.
  • Page 42 GETTING TO KNOW YOUR VEHICLE To Unfold Third Row Seats 2. Pulling strap “2” releases the seatback to Stow 'n Go Seating return to its full upright position. On vehicles equipped with Stow 'n Go seating, 1. Pull up on the assist strap to lift the seat the second and third row seats can be folded out of the storage bin and push the seat into the floor for convenient storage.
  • Page 43 GETTING TO KNOW YOUR VEHICLE A one-touch Auto Advance ‘n Return button is If the power sliding door is closing when the The Auto Advance ‘n Return system includes   located on the B-Pillar trim panel, just in front of button is pushed, the front seat will not move obstacle detection.
  • Page 44 GETTING TO KNOW YOUR VEHICLE Second Row Stow 'n Go NOTE: 3. Pull the floor panel and position it toward the front seats while folding the top half For Manual Seats: To stow the seat in the floor, Push the lock rod inward for the locked ...
  • Page 45 GETTING TO KNOW YOUR VEHICLE 5. Fold the armrest upward and stow the seat 7. Close the floor by pulling the floor panel 9. Readjust the front seat as needed, and by grabbing the strap on the lower part of backwards by the bottom corner edge of the replace the floor mat (if equipped).
  • Page 46 GETTING TO KNOW YOUR VEHICLE To Unstow Second Row Seats NOTE: 3. Pull the floor panel and position it toward the front seats while folding the top half For Manual Seats: To unstow the seat from the Push the lock rod inward for the locked ...
  • Page 47 GETTING TO KNOW YOUR VEHICLE 4. Pull the strap located on the seat and pull 6. To position the floor panel back into its orig- 8. Readjust the front seat as needed, and the seat out of the storage area. Push the inal state, grab the bottom corner and replace the floor mat (if equipped).
  • Page 48 GETTING TO KNOW YOUR VEHICLE Power Adjustment (Front Seats) — If Adjusting The Seat Forward Or Rearward WARNING! Equipped The seat can be adjusted both forward and rear- Adjusting a seat while driving may be  ward. Push the seat switch forward or rearward, Some models may be equipped with eight-way dangerous.
  • Page 49 GETTING TO KNOW YOUR VEHICLE Reclining The Seatback CAUTION! WARNING! (Continued) The angle of the seatback can be adjusted Do not place any article under a power seat Seats should be adjusted before fastening forward or rearward. Push the seatback switch ...
  • Page 50 GETTING TO KNOW YOUR VEHICLE Third Row Power Recline — If Equipped Third Row Power Stow ‘n Go Seat — If The switch is only functional when the liftgate is Equipped open and the vehicle is in PARK. The power recline feature, located on the trim The rear switch bank allows multiple power panel next to the seat, adjusts the seatback A one-touch power folding seat switch is located...
  • Page 51 GETTING TO KNOW YOUR VEHICLE To move the selected seat(s) to the normal Driver Memory Seat — If Equipped (seated) position, push and release the The Memory Buttons (1) and (2) on the driver's “Normal” button. The seat will automatically door panel can be programmed to recall the stop when the Normal position is reached.
  • Page 52 GETTING TO KNOW YOUR VEHICLE Programming The Memory Feature Linking And Unlinking The Remote Keyless 4. Push and release button (1) or (2) accord- ingly. “Memory Profile Set” (1 or 2) will Entry Key Fob To Memory To create a new memory profile, perform the display in the instrument cluster.
  • Page 53 GETTING TO KNOW YOUR VEHICLE A recall can be cancelled by pushing any of the When the ignition is placed in the OFF posi- Heated Seats  memory buttons on the driver's door during a tion, the driver seat will move to a position Front Heated Seats —...
  • Page 54 GETTING TO KNOW YOUR VEHICLE Vehicles Equipped With Remote Start Rear Heated Seats — If Equipped Push the switch once to select HI-level heating. Push the switch a second time to select LO-level On models that are equipped with remote start, On some models, the second row seats are heating.
  • Page 55 GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS The front ventilated seats control buttons are Adjustable Armrest (Front Seats) — If located within the climate or controls screen of Equipped Head restraints are designed to reduce the risk the touchscreen. Your vehicle may be equipped with adjustable of injury by restricting head movement in the Press the ventilated seat button once to...
  • Page 56 GETTING TO KNOW YOUR VEHICLE Head Restraints — Front Seats restraint, put the head restraint posts into the holes and push downward. Then, adjust the The front driver and passenger seats are head restraint to the appropriate height. equipped with four-way head restraints. To raise the head restraint, pull upward on the head restraint.
  • Page 57 GETTING TO KNOW YOUR VEHICLE Head Restraints — Second Row Quad Seats WARNING! The second row outboard head restraints, as A loose head restraint thrown forward in a  well as the removable 8th passenger seat (if collision or hard stop could cause serious equipped) have adjustable head restraints.
  • Page 58 GETTING TO KNOW YOUR VEHICLE Head Restraints — Third Row NOTE: Power Folding Third Row Head Restraints — If To remove the center head restraint, raise it as Equipped The outboard head restraints can be manually far as it can go. Then, push the release button For improved visibility, the third row outboard folded forward for improved rearward visibility.
  • Page 59 GETTING TO KNOW YOUR VEHICLE STEERING WHEEL Press the heated steering wheel button  WARNING! second time to turn the heating element off. Tilt/Telescoping Steering Column Do not adjust the steering column while NOTE: driving. Adjusting the steering column while This feature allows you to tilt the steering The engine must be running for the heated driving or driving with the steering column...
  • Page 60 GETTING TO KNOW YOUR VEHICLE MIRRORS base of the mirror. A light to the left of the Outside Mirrors button will illuminate to indicate when the To receive maximum benefit, adjust the outside Inside Day/Night Mirror — If Equipped dimming feature is activated. The sensor to the mirror(s) to center on the adjacent lane of traffic right of the button does not illuminate.
  • Page 61 GETTING TO KNOW YOUR VEHICLE Conversation Mirror Power Mirrors — If Equipped Using the mirror control switch, push on any of the four arrows for the direction that you want Located in the overhead console there is a The power mirror controls are located on the the mirror to move.
  • Page 62 GETTING TO KNOW YOUR VEHICLE Tilt Side Mirrors In Reverse (Available With Power Folding Mirrors — If Equipped Resetting The Power Folding Outside Mirrors Memory Seat Only) — If Equipped You may need to reset the power folding mirrors The switch for the power folding mirrors is if the following occurs: located between the power mirror switches Tilt Side Mirrors In Reverse provides automatic...
  • Page 63 GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Illuminated Vanity Mirrors — If Equipped Headlight Switch An illuminated vanity mirror is located on the The headlight switch is located on the left side Multifunction Lever sun visor. To use the mirror, rotate the sun visor of the instrument panel.
  • Page 64 GETTING TO KNOW YOUR VEHICLE Daytime Running Lights (DRLs) — If NOTE: To Deactivate Broken, muddy, or obstructed headlights and Equipped Perform either of the following steps to deacti- taillights of vehicles in the field of view will vate the Automatic High Beam system. The headlights or LED light bars on your vehicle cause headlights to remain on longer (closer to will illuminate when the engine is started.
  • Page 65 GETTING TO KNOW YOUR VEHICLE Automatic Headlights — If Equipped Refer to “Uconnect Settings” in “Multimedia” Lights-On Reminder for further information. This system automatically turns your headlights If the headlights or the parking lights are left on on or off based on ambient light levels. To turn after the ignition switch is placed in the OFF Headlight Delay —...
  • Page 66 GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS Turn Signals Battery Protection Move the multifunction lever up or down and This feature provides battery protection to avoid Courtesy/Interior Lighting the arrows on each side of the instrument wearing down the battery if the headlights or The courtesy light switches are used to turn the cluster flash to show proper operation of the parking lights are left on for extended periods of...
  • Page 67 GETTING TO KNOW YOUR VEHICLE Rear Courtesy/Reading Lights — If Equipped Ambient Light Control — If Equipped With the parking lights or headlights on, rotate the instrument panel dimmer control upward or Located above the rear passengers are cour- Rotate the ambient dimmer control upward or downward to increase or decrease the bright- tesy/reading lights.
  • Page 68 GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPER AND WASHERS returning to the off position. If the windshield Windshield Washers wiper switch is turned off and the blades cannot To use the washer, pull the lever rearward Windshield Wiper Operation return to the off position, damage to the wiper toward you and hold while spray is desired.
  • Page 69 GETTING TO KNOW YOUR VEHICLE Rain Sensing Wipers — If Equipped NOTE: Low Temperature Wipe Inhibit — The Rain  Sensing feature will not operate when the This feature senses rain or snowfall on the wind- The Rain Sensing feature will not operate ...
  • Page 70 GETTING TO KNOW YOUR VEHICLE Remote Start Mode Inhibit — On vehicles Rear Wiper And Washer Rear Window Washer Operation  equipped with Remote Starting system, Rain Pushing the windshield wiper lever forward acti- Rear Window Wiper Operation Sensing wipers are not operational when the vates the rear window washer.
  • Page 71 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Manual Climate Controls Overview Uconnect 4 With 7–inch Display Manual Climate Controls...
  • Page 72 GETTING TO KNOW YOUR VEHICLE Uconnect 4/4C NAV With 8.4–inch Display Manual Climate Controls...
  • Page 73 GETTING TO KNOW YOUR VEHICLE Manual Climate Control Descriptions Icon Description MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is on. Performing this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off. NOTE: The MAX A/C setting is only available on the touchscreen.
  • Page 74 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors (if equipped). An indicator will illuminate when the rear window defroster is on. The rear window defroster automatically turns off after 10 minutes.
  • Page 75 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Blower Knob Blower Control Blower Control is used to regulate the amount of air forced through the climate system. There are seven blower speeds available. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.
  • Page 76 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
  • Page 77 GETTING TO KNOW YOUR VEHICLE Controlling The Rear Climate Controls From To change the rear system settings: The Front MTC Display/Touchscreen Press the "Rear Climate" button on the touch-  screen to change control to rear control The Three-Zone Manual Temperature Control mode;...
  • Page 78 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Lock Button Press and release to lock out the rear manual temperature controls from adjusting the rear temperature and blower settings. Front Climate Button Press and release this button to change the display on the Uconnect system back to the Front Climate Controls. Rear Passenger Temperature Up and Down Buttons Provides the rear passengers with independent temperature control.
  • Page 79 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Passenger Climate Control OFF Button Press and release this button to turn the Rear Climate Controls off. Panel Mode Panel Mode Press this button on the touchscreen to change the air distribution mode to Panel Mode. In Panel Mode, air comes from the outlets in the instrument panel.
  • Page 80 GETTING TO KNOW YOUR VEHICLE Rear Manual Temperature Control (MTC) The rear system temperature control buttons are located on the headliner on the passenger The rear Manual Temperature Control (MTC) side of the vehicle. system has floor air outlets at the rear right side of the Third Row seats and overhead outlets at each outboard rear seating position.
  • Page 81 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from both the headliner outlets and the floor outlets. NOTE: In many temperature positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer air from the floor outlets.
  • Page 82 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Blower Controls The rear blower control can be manually set to off, or any fixed blower speed by pushing the blower control buttons. This allows the rear seat occupants to control the volume of air circulated in the rear of the vehicle. The larger of the two icons increases blower speed, whereas the smaller of the two icons decreases the blower speed.
  • Page 83 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Overview Uconnect 4 With 7–inch Display Automatic Temperature Controls...
  • Page 84 GETTING TO KNOW YOUR VEHICLE Uconnect 4C/4C With 8.4–inch Display NAV Automatic Climate Controls...
  • Page 85 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Descriptions Icon Description MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is on. Performing this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off. NOTE: The MAX A/C setting is only available on the touchscreen.
  • Page 86 GETTING TO KNOW YOUR VEHICLE Icon Description Front Defrost Button Press and release to change the current airflow setting to Defrost mode. The indicator illuminates when this feature is on. Air comes from the windshield and side window demist outlets. When the defrost button is selected, the blower level may increase.
  • Page 87 GETTING TO KNOW YOUR VEHICLE Icon Description SYNC Button Press the Sync button on the touchscreen to toggle the Sync feature On/Off. The Sync indicator is illuminated when this feature is enabled. SYNC is used to synchronize the front and rear passenger temperature settings. Changing the front or rear passenger temperature setting while in SYNC will automatically exit this feature.
  • Page 88 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
  • Page 89 GETTING TO KNOW YOUR VEHICLE Controlling The Rear Climate Controls From The Front ATC Panel—If Equipped The Three-Zone Automatic Temperature Control (ATC) system allows for adjustment of the rear climate controls from the front ATC panel. To change the rear system settings: Press the "Rear Climate"...
  • Page 90 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Passenger Temperature Up And Down Buttons Provides the front occupants with the ability to control the rear temperature. Push the up arrow button on the touchscreen to increase the temperature. Push the down arrow button on the touchscreen to decrease the temperature. When the SYNC feature is active, the passenger’s temperature will move up and down with the driver’s temperature.
  • Page 91 GETTING TO KNOW YOUR VEHICLE Icon Description Panel Mode Panel Mode Press this button on the touchscreen to change the air distribution mode to Panel Mode. In Panel Mode, air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to one side will shut off the airflow.
  • Page 92 GETTING TO KNOW YOUR VEHICLE Rear Automatic Temperature Control (ATC) — 2. ATC is selected by pushing the AUTO button. If Equipped Once the desired temperature is displayed, the The rear Automatic Temperature Control (ATC) ATC System will automatically achieve and system has floor air outlets underneath the maintain that comfort level.
  • Page 93 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from both the headliner outlets and the floor outlets. NOTE: In many temperature positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer air from the floor outlets.
