Robur B15 Generators Series Installation, User And Maintenance Manual
Generators series gas fired unit heaters for heating medium areas
Hide thumbs
Also See for B15 Generators Series:
- Installation, user and maintenance manual (34 pages)
Related Manuals for Robur B15 Generators Series
Summary of Contents for Robur B15 Generators Series
- Page 1 Installation, user and maintenance manual Series B15 Generators Gas fired unit heaters for heating medium areas Methane gas powered...
- Page 2 Revision: B Code: D-LBR595 This manual has been drawn up and printed by Robur S.p.A.; whole or partial reproduction of this manual is prohibited. The original is filed at Robur S.p.A. Any use of this manual other than for personal consultation must be previously authorised by Robur S.p.A.
-
Page 3: Table Of Contents
Installation, user and maintenance manual – Series B15 Generators INDEX OF CONTENTS PREFACE ......................5 OVERVIEW AND TECHNICAL FEATURES ............7 WARNINGS ....................................... 7 NOTES ON OPERATION OF THE APPLIANCE ........................8 TECHNICAL MANUFACTURING CHARACTERISTICS......................8 TECHNICAL DATA ..................................10 DIMENSIONS ....................................11 INSTALLATION ....................13 GENERAL INSTALLATION INSTRUCTIONS ...........................13 SIZING AND INSTALLING THE COMBUSTION AIR/FUMES EXHAUST TUBES ............15 BRACKET INSTALLATION ................................20... -
Page 5: Preface
PREFACE The present "Installation, user and maintenance manual" is intended for anyone who is to install or operate Robur series B15 hot air generators. In particular, the booklet is intended for the plumber who will install the generator, the electrician who will connect it to the mains power supply and the final user who will con- trol it during everyday operation. -
Page 7: Overview And Technical Features
Any repair may be carried out solely by a ROBUR Technical Assistance Centre, using only original replacement parts. -
Page 8: Notes On Operation Of The Appliance
the gas supply seals, both internal and external; the gas flow rate setting as required by the generator’s power rating; the gas supplied to the appliance is of the type for which it is designed; the gas supply pressure in relation to the admitted range specified on the nameplate;... - Page 9 Installation, user and maintenance manual – Series B15 Generators pre-mix burner in stainless steel. high head blower. cylindrical combustion chamber in stainless steel. heat exchangers in corrugated stainless steel with a very large exchange surface. external panelling in steel with epoxy powder enamel finish. high capacity axial fan.
-
Page 10: Technical Data
TECHNICAL DATA Table 2.1 – Technical data. TECHNICAL CHARACTERISTICS unit of measurement appliance category appliance type C13-C33-B23-C63-C53 natural (methane) thermal capacity nominal thermal power nominal 13,8 gas consumption natural (G20) m3/h 1,59 efficiency nominal gas supply pressure natural gas (G20) mbar gas fitting dia. -
Page 11: Dimensions
Installation, user and maintenance manual – Series B15 Generators DIMENSIONS Figure 2.2 LEGEND fumes outlet fitting combustion air intake fitting power cable inlet gas fitting front view side view rear view Series B15 dimensions. -
Page 13: Installation
Professionally qualified personnel is defined as those possessing specific techni- cal competence in the residential heating equipment sector. Contact ROBUR S.p.A. Presales (tel. +39.035.888.111) for any further information. Incorrect installation may cause damage to persons, animals or things, for which the manufacturer is not liable. - Page 14 A cut-off valve and three-piece coupling must be fitted on the gas supply. Check that there is an adequate mains gas supply. In particular: make sure that the gas mains pressure, with the appliance operating, is set to 20 mbar (204 mm H with an admissible range of 17 mbar to 25 mbar (G20 natural gas supply).
-
Page 15: Sizing And Installing The Combustion Air/Fumes Exhaust Tubes
Installation, user and maintenance manual – Series B15 Generators Figure 3.2 Min 200 Min 400 Min 2,5 m 2,2 ÷ 3,0 [m] Max 3,5 m (min/max) Clearances: minimum clearance required for installation. Figure 3.3 Example of generator positioning. SIZING AND INSTALLING THE COMBUSTION AIR/FUMES EXHAUST TUBES Series B15 hot air generators can be installed in one of the following ways. - Page 16 The total admitted pressure drop is given in Table 3.1 → 17. The pressure drops of the fumes, air and coaxial tubes supplied by ROBUR, are given in Table 3.2 → 17 (for dia. 80 and 100). The pressure drops of external terminals need not be considered as they are negligible.
- Page 17 [Pa] tube [Pa/m] 90° bend [Pa] coaxial [Pa] wall roof fumes air fumes fumes air fumes roof O-SCR009 O-SCR007 O-SCR008 0.35 0,25 Dati per il calcolo del sistema aria/fumi con condotti Ø 80 o Ø 100 forniti da Robur Spa.
- Page 18 If the installation had turned out to be not permitted due to excessive pressure drop, we could have adopted one of the following measures: reduce the length of the air/fumes tubes; increase the diameter of the tubes to dia. 100. For special installations, phone ROBUR Presales at +39.035.888.111.
- Page 19 Installation, user and maintenance manual – Series B15 Generators Figure 3.6 LEGEND C13 type installations generator, seen from above example with separate wall-mounted ducts example with coaxial wall- mounted duct combustion air intake fumes exhaust C13 type installations. Figure 3.7 LEGEND generator, front view generator, side view...
-
Page 20: Bracket Installation
Observe the warnings given in the Robur O-STF019 bracket’s assembly instructions. USING SHELVES (not supplied by Robur) If he opts not to use Robur mounting accessories, the installer must not only observe the instructions given in Paragraph 3.1 GENERAL INSTALLATION INSTRUCTIONS → 13 and Figure 3.2 →... -
Page 21: Installing The Wall Panel
Installation, user and maintenance manual – Series B15 Generators Figure 3.9 LEGEND 176 mm supporting plate wall-mounted plate (and counterplate) generator base mounting hole spacing generator rear mounting hole spacing generator base/rear support plane line of intersection generator mounting bolts (*) detail of "b-c"... -
Page 22: Setting The Gas Valve
If further adjustment should be necessary, proceed as explained below (see Figure 3.10 → 23). The adjustment must be done by professionally qualified personnel. ROBUR S.p.A. has a network of Assistance Centres which can be contacted via your reseller, area agent, or by phoning ROBUR S.p.A. - Page 23 Installation, user and maintenance manual – Series B15 Generators Table 3.5 OFFSETS OFFSET [mbar] [Pa] nominal Offsets. Check that the CO percentage is as given in 3.1 → 17. If it is not, adjust the offset again until the CO percentage is as given in 3.1 →...
-
Page 24: Wiring Diagrams
WIRING DIAGRAMS Figure 3.11 Installation diagram. - Page 25 Installation, user and maintenance manual – Series B15 Generators Figure 3.12 LEGEND programmer room thermostat RL1-2-3 programmed control relay ground single-phase line (230 V - 50 Hz) wall-mounted generator generator internal terminals Installation of multiple appliances with a single programmer and multiple room thermostats.
- Page 26 Figure 3.13 LEGEND programmer room thermostat RL1-2-3 programmed control relay ground single-phase line (230 V - 50 Hz) wall-mounted generator generator internal terminals Installation of multiple appliances with a single programmer and a single room thermostat (solution with multiple relays).
- Page 27 Installation, user and maintenance manual – Series B15 Generators Figure 3.14 LEGEND programmer room thermostat programmed control relay ground single-phase line (230 V - 50 Hz) wall-mounted generator generator internal terminals Installation of multiple appliances with a single programmer and a single room thermostat (solution with a single relay).
-
Page 29: Use And Operation
Installation, user and maintenance manual – Series B15 Generators USE AND OPERATION SWITCHING ON AND SWITCHING OFF The first start up must be done by professionally qualified personnel. Before starting up the generator, have it checked by professionally qualified personnel: the electricity and gas mains specifications must correspond to the specifications on the nameplate;... - Page 30 (automatic reset). The limit thermostat ONLY trips during malfunctions. Before resetting it, troubleshoot the problem (in this case, overheating). If it trips frequently, contact ROBUR TAC. SUMMER MODE To activate FAN ONLY mode, proceed as follows: You will need: the appliance connected to the power/gas supply.
-
Page 31: Service And Assistance
Installation, user and maintenance manual – Series B15 Generators SERVICE AND ASSISTANCE MALFUNCTIONS Before taking any particular measures, always check that: the power supply is present: 230 V ± 10% 50 Hz with an effective ground plant; the gas supply is present; the gas pressure and flow rate must be in the range specified by the manufacturer. - Page 32 You will need: generator powered off, with master power switch set to "OFF" and gas valve set to "CLOSED". Open the generator’s hatch. Undo the hexagonal ring nut connecting the gas pipe to the nozzle mount fitting. Move the gas pipe aside and remove the nozzle. Undo the four bolts securing the blower screw.
- Page 33 Installation, user and maintenance manual – Series B15 Generators...
- Page 34 Robur is dedicated to dynamic progression in research, development and promotion of safe, environmentally-friendly, energy-efficiency products, through the commitment and caring of its employees and partners. Robur Mission Robur Spa tecnologie avanzate per la climatizzazione Via Parigi 4/6 24040 Verdellino/Zingonia (Bg) Italy...
