Instruction sheet
1
PRemISe
1.1
QRCODE
1.2
AVAILABLE LANGUAGES
For versions of this Instruction sheet in other languages,
see Robur website.
1.3
USE
Gas unit heaters.
2
WaRNINGS
For correct installation, please refer to the manual
included in the appliance and to these installation
and operation instructions.
Please read the warnings and instructions for use
contained in these instructions carefully as they
provide important information regarding safe in-
stallation and use. Keep this sheet carefully for fur-
ther reference. The manufacturer cannot be held
responsible for any damage caused by improper,
erroneous or unreasonable use.
Installer's qualifications
Installation must exclusively be performed by a
qualified firm and by skilled personnel, with spe-
cific knowledge on heating and electrical systems,
in compliance with the laws in force in the Country
of installation.
3
DeSCRIPTION
The OTRG005 thermoregulator is a device that can direct-
ly manage Robur gas unit heaters: the simple and intuitive
display interface allows the user to change the control pa-
rameters, switch the unit on/off and change the operat-
ing mode; a serial interface also allows to create cascading
systems managed by a single chronothermostat (optional
OCDS008), with considerable advantages in terms of tem-
perature control, especially when installing gas unit heat-
ers in large spaces.
Cod.: D-FST422
Rev.: F
OTRG005 TheRmOReGulaTOR
OTRG005
1.4
KEY TO SYMBOLS
DANGER
WARNING
NOTE
PROCEDURE
REFERENCE (to other document)
The design, installation, operation and maintenance of
the systems shall be carried out in compliance with cur-
rent applicable regulations, depending on the Country
and location, and in accordance with the manufacturer's
instructions. In particular, regulations regarding the fol-
lowing shall be complied with:
Electrical systems and equipment.
Fire safety and prevention.
Any other applicable law, standard and regulation.
Any contractual or extra-contractual liability of the
manufacturer for any damage caused by incorrect
installation and/or improper use and/or failure to
comply with regulations and with the manufactur-
er's directions/instructions shall be disclaimed.
This operation must be curried in total safety.
Before starting intercept the gas and disconnect
the power supply.
When using the OTRG005 thermoregulator in com-
bination with Next-G series gas unit heaters, the gas
unit heater will be managed by the thermoregulator
on two power levels using the temperature probe
connected to the thermoregulator, instead of
using continuous heat output modulation.
OTRG005 thermoregulator
22 MCL SDC 008
29/04/2022
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OTRG005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Robur OTRG005

  • Page 1 DeSCRIPTION The OTRG005 thermoregulator is a device that can direct- When using the OTRG005 thermoregulator in com- ly manage Robur gas unit heaters: the simple and intuitive bination with Next-G series gas unit heaters, the gas...
  • Page 2: Technical Data

    OTRG005 thermoregulator FeaTuReS Figure 4.1   Thermoregulator The main features of this device are: 2-digit 7-segment display ▶ 2 led for diagnostic functions and operation signalisa- ▶ tion 4 buttons for setup functions ▶ 1 NTC probe for ambient temperature measurement ▶...
  • Page 3: Installation

    Pre-punched rectangular plates Openings for seating the pre-punched INSTallaTION The OTRG005 thermoregulator is equipped with an am- unscrewing the 2 fixing screws (B). 3. Remove the pre-punched plates from the bottom of bient probe capable of detecting the temperature of the zone where it is placed.
  • Page 4: Connection Diagram

    CONNeCTION DIaGRam Figure 7.1   Connection diagram MODBUS Electrical bridge (Jumper) External switch Chronothermostat OCDS008 Next OTRG005 thermoregulator Previous OTRG005 thermoregulator NTC temperature probe (already connected) Figure 7.2   Example of connection of several thermoregulators to OCDS008 chronothermostat OTRG005 thermoregulator OCDS008 digital chronothermostat Cod.: D-FST422 Rev.: F...
  • Page 5: Operation

    Figure 7.3   Example of connection of several thermoregulators to an external request OTRG005 thermoregulator External request Relay OPeRaTION The flexibility of the OTRG005 thermoregulator allows it Figure 8.1   Heating mode diagram (example values) to be combined with Robur gas unit heaters. The device can operate in the following modes: Local (single).
  • Page 6: Keyboard Lock

    OTRG005 thermoregulator sufficient to cover the demand) unit it reacher Keypad unlock again point 2 (18 °C) again, repeating the hystere- „ Press the and + keys simultaneously for 15 sec- sis cycle. onds. b. The heat supplied by the gas unit heater in mo- dulation is not sufficient to cover the demand, so „...
  • Page 7 Instruction sheet OTRG005 thermoregulator 8.5.1 J6 external request operation external request to the OTRG005 thermoregulator. J6 input can be used as: Check the required setpoint (Figure 8.5  p. 7 ): 1. External on/off request (in heating mode), with Lo pa- rameter disabled (Paragraph 10  p. 11 ).
  • Page 8: Remote Mode

    OCDS008 digital chronothermostat that uses an ▶ OpenTherm communication. With this system, it is possible to control up to 10 OTRG005 devices con- nected to as many gas unit heaters. For additional information regarding operation with the OCDS008 digital chronothermostat, please refer to the relative instructions.
  • Page 9 This mode is useful when the chronothermostat is far Identify the presence of gas unit heaters faults. from the comfort zone, or when more than one OTRG005 ▶ Unlock the gas unit heaters in case of faults. thermoregulator (and therefore more than one gas unit ▶...
  • Page 10: User Interface

    OCDS008 digital chronothermostat respectively. Please note that, in case of loss of OpenTherm or Modbus For modulation management, see Paragraph 8.2  p. 6 . communication between the OTRG005 devices and the remote system, due to any reason (failure of the OCDS008 NTC PROBE...
  • Page 11 Instruction sheet OTRG005 thermoregulator COM LED (GREEN) - BUS PRESENCE BUTTONS Table 9.2  p.  11 shows the functions of the device The COM led indicates the presence of a remote commu- buttons. nication (OpenThermо® or Modbus) as shown in Figure Table 9.2  ...
  • Page 12 OTRG005 thermoregulator Parameter Description Setting Default Economy (Lo) Allows, in local mode, the operation of the gas unit heater of economy mode disabled in economy mode through J6 contact (for further details 02 ÷ 25 °C economy mode setpoint see Paragraph 8.5.1.2  p. 7 ).
  • Page 13 Instruction sheet OTRG005 thermoregulator Figure 11.1   Connections between the thermoregulator and the gas unit heater OTRG005 thermoregulator NTC temperature probe (supplied) Next-R gas unit heater terminal block J6 electrical bridge Table 11.1   Connections between the thermoregulator and the gas unit heater OTRG005 thermoregulator...
  • Page 14 OTRG005 thermoregulator connector with an electrical bridge. board on the Next-G gas unit heater to value 0. For information on the procedure for setting the pa- rameter, refer to the Next-G gas unit heater instal- Setting parameter P45 lation, use and maintenance manual.
  • Page 15 Instruction sheet OTRG005 thermoregulator 11.3 M SERIE GAS UNIT HEATER 4. Make electrical connections as described in Figure 11.3  p. 15 and in Table 11.3  p. 15 . How to connect the thermoregulator to the M The cable may not be longer than 10 metres.
  • Page 16 OTRG005 thermoregulator OTRG005 thermoregulator Recommended colour Connector Terminal Type Description Terminal Input Selection jumper “impedance 120 Ω” Cod.: D-FST422 Rev.: F 22 MCL SDC 008 29/04/2022 OTRG005...
  • Page 20 OTRG005 thermoregulator INDEX OF CONTENTS 1 Premise Anti-condensation mode management ..p. 6 ..................p. 1 Keyboard lock ............p. 6 QRCode ..............p. 1 Local mode ............. p. 6 Available languages ..........p. 1 Remote mode ............p. 8 Use ................p. 1 NTC probe ............. p. 10 Key to symbols ............
