Troubleshooting

What appears to be a malfunction may not always be serious. Please go through the following list before requesting service.
Symptom
The unit is not operative.
The remote control unit does not function.
(XL-Z232BK only)
Playback is not possible.
The reproduced sound includes noise.
The sound is intermittent.

Specifications

General
System:
Signal detection system:
Sampling frequency:
Power requirements
Power consumption:
Dimensions (W x H x D):
Mass:
Power plug is disconnected from the AC
outlet.
The AC power cord plug is disconnected
from the AC power cord inlet of this unit.
Disc is not loaded.
Batteries are exhausted.
There is an obstacle between remote control
unit and the remote sensor of the main unit.
Direct sunlight shines on the remote sensor
of the main unit.
Disc is inserted upside down.
Disc is not loaded in the correct position.
Moisture is condensed inside the unit.
Disc is dirty.
Disc is warped.
Disc is scratched.
Compact disc player
Non-contact optical system
44.1 kHz
AC120V , 60Hz
10 watts (POWER ON)
4 watts (STANDBY)
435 x 101 x 281 mm
17-3/16 x 4 x 11-1/8 inches
3.3 kg (10.8 lbs)
Possible cause
Audio performance
Frequency response:
Dynamic range:
Signal to noise ratio:
Total harmonic distortion:
Channel separation:
Wow and flutter:
Output level
Accessories
Remote control unit (RM-SX230U)(XL-Z232BK only) ................ 1
Battery R03(UM-4)/AAA(24F) (XL-Z232BK only) ....................... 2
Audio cord ................................................................................. 1
COMPU LINK cord .................................................................... 1
AC POWER cord ....................................................................... 1
Design and specifications subject to change without notice.
GENERAL INFORMATIONS
Remedy
Connect the plug to an AC outlet.
Connect the plug to an AC power
cord inlet.
Load a disc in the disc tray.
Replace both batteries.
Remove the obstacle.
Shade the unit from the direct sunlight.
Load a disc with its label-side up in the
disc tray.
Load the disc according to the groove of
the disc tray.
Leave the unit turned on until the mois-
ture evaporates.
Wipe off the disc surface with a soft
cloth.
Replace the disc with a new one.
Replace the disc with a new one.
2 Hz to 20,000 Hz (±1 dB)
More than 98 dB (at 1 kHz)
More than 106 dB
Less than 0.0025% (at 1 kHz)
More than 94 dB (at 1 kHz)
Less than measurable limit
2.0Vrms (at 10 kohms)
Page 14
