Mopar 2005-2009 Chrysler 300C Installation Instructions Manual

Audio system upgrade package

*Phillips Screwdriver *10mm Nut Driver *10mm Socket *Ratchet *Three Inch Putty Knife

1EA. SUBWOOFER ASSEMBLY

1EA. 100 WATT AMP ASSEMBLY

1EA. WIRE HARNESS

1EA. M6 BOLT

1EA. BODY CLIP

1EA. INSTRUCTIONS

6EA. WIRE TIES

4EA. #8 SHEET METAL SCREWS

77KICK02

Audio System Upgrade Package

2005-2009 Chrysler 300C

TOOLS REQUIRED:

*Panel Removal Tool *10mm Wrench

Do you have a question about the 2005-2009 Chrysler 300C and is the answer not in the manual?

Page 1 1EA. BODY CLIP P/N 06508613AA 1EA. INSTRUCTIONS P/N RBI05MAGSUB 6EA. WIRE TIES P/N RFZIP6 4EA. #8 SHEET METAL SCREWS P/N RFS2 77KICK02 9/22/2008 Page 1 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
Page 2 Remove the damping material and save for reinstallation later. Fig. 4 Fig. 3 Fig. 4 77KICK02 9/22/2008 Page 2 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
Page 3 11. Remove the six plastic retainers securing the large panel directly below the package tray and remove the panel from the trunk. Fig. 8 Fig. 7 Fig. 8 77KICK02 9/22/2008 Page 3 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
Page 4 Fig. 11 15. Secure the harness with the factory retaining bracket. Fig. 12 Fig. 11 Fig. 12 77KICK02 9/22/2008 Page 4 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
Page 5 Plug the white male connector back into the speaker. Fig. 16 Fig. 15 Fig. 16 77KICK02 9/22/2008 Page 5 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
Page 7 Pin 1 signal + Pin 2 empty Pin 3 signal - Pin 1 output + Pin 2 out put - Battery 77KICK02 9/22/2008 Page 7 of 7 © 2007, Chrysler, LLC. Mopar is a registered trademark of Chrysler, LLC. All rights reserved.
