Icom IC-7700 Service Manual page 81

[ANT-SW BOARD] (ANT)
REF ORDER
NO. NO.
J1* 6510017930 1771P145-20
J3* 6510007020 TMP-J01X-V6
J4* 6510019971 52808-1071
J51* 6510000410 MR-DSE-02
J61* 6510000410 MR-DSE-02
J71* 6510000410 MR-DSE-02
J81* 6510000410 MR-DSE-02
[CTRL BOARD] (CTR)
REF ORDER
NO. NO.
CP1* 6910009670 HK3-S-T
CP101* 6910009670 HK3-S-T
J1* 6510023771 52793-2470
J2* 6510023761 S10B-PH-SM4-TB (LF) (SN)
J51* 6510023771 52793-2470
J52* 6510022031 B10B-ZR-SM4-TF (LF) (SN)
J53* 6510021431 S8B-ZR-SM4A-TF (LF) (SN)
J101* 6510017920 1811P342
J251* 6510017920 1811P342
J252* 6510017920 1811P342
J301* 6510017920 1811P342
J351* 6510007020 TMP-J01X-V6
W1 9029804001 72/99/040/X98/X98
EP1 9040902903 IRRAX D=0.7 L=22MM
MP1 8510015760 2590 A-CTRL CASE
MP2 8930014140 EARTH SPRING (D)
MP3 8930048681 INSULATION PIPE (K)-1
MP4 8930048681 INSULATION PIPE (K)-1
MP5 8930048681 INSULATION PIPE (K)-1
MP6 8930048681 INSULATION PIPE (K)-1
MP7 8930014140 EARTH SPRING (D)
[DC-DC UNIT] (DCD)
REF ORDER
NO. NO.
J1* 6510022801 B10B-PH-SM4-TB (LF) (SN)
J2* 6510020251 B9B-PH-SM4-TB (LF) (SN)
J3* 6510018941 B13B-PH-SM4-TB (LF) (SN)
J5* 6510018951 B7B-PH-SM4-TB (LF) (SN)
J6* 6510023261 B6B-PH-SM4-TB (LF) (SN)
J7* 6510018921 B8B-PH-SM4-TB (LF) (SN)
J8* 6510018971 B4B-PH-SM4-TB (LF) (SN)
†
W1 9030090150 OPC-1803
MP201 8510015720 2590 DC-DC A-CASE
MP203 8930074750 FERRITE SHEET (V)
MP401 8510015720 2590 DC-DC A-CASE
MP403 8930074750 FERRITE SHEET (V)
MP601 8510015720 2590 DC-DC A-CASE
MP603 8930074750 FERRITE SHEET (V)
MP801 8510015740 2590 DC-DC B-CASE
[DIGISEL UNIT] (DSL)
REF ORDER
NO. NO.
J1* 6510007020 TMP-J01X-V6
J2* 6510007020 TMP-J01X-V6
J11* 6510009870 PD054-02M
J12* 6510009870 PD054-02M
J2017* 6510019971 52808-1071
J2018* 6510003391 B03B-EH-S (LF) (SN)
†
W11 9030090110 61/99/070/D33D/D33D
†
W12 9011130220 WIRE 08 DD
MP1 8930062740 2590 M-SPRING
MP2 8930062740 2590 M-SPRING
MP3 8930062740 2590 M-SPRING
MP4 8930062740 2590 M-SPRING
MP5 8930062740 2590 M-SPRING
MP8 8510018460 3009 DIGISEL CASE
MP9 8510018470 3009 DIGISEL COVER
MP14 8810007231 SETSCREW (H) 3X8 ZC3
MP15 8810007231 SETSCREW (H) 3X8 ZC3
[FILTER UNIT] (FIL)
REF ORDER
NO. NO.
J901* 6510017930 1771P145-20
J902* 6510022031 B10B-ZR-SM4-TF (LF) (SN)
J903* 6510019971 52808-1071
J904* 6510017930 1771P145-20
J905* 6510019421 B8B-ZR-SM4-TF (LF) (SN)
*: Refer to "BOARD LAYOUTS" for the location.
†
: Refer to "GENERAL WIRING" for the connection.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[LOGIC UNIT] (LG)
REF ORDER
NO. NO.
1 J1* 6510022490 AXK5S30045P
1 J2* 6510019870 AXK5S40045P
1 J52* 6510023261 B6B-PH-SM4-TB (LF) (SN)
1 J102* 6510019981 52808-1671
1 J602* 6510019971 52808-1071
1 J604* 6510019971 52808-1071
1 J804* 6510022031 B10B-ZR-SM4-TF (LF) (SN)
J805* 6510020081 52808-2071
J806* 6510022471 40FLT-SM2-TB (LF) (SN)
J808* 6510020001 52808-3071
J809* 6510020001 52808-3071
J810* 6510020251 B9B-PH-SM4-TB (LF) (SN)
J811* 6510021561 52808-2470
J813* 6510019991 52808-2271
1
J814* 6510019981 52808-1671
1
J816* 6510019981 52808-1671
J820* 6510022801 B10B-PH-SM4-TB (LF) (SN)
1
J821* 6510020251 B9B-PH-SM4-TB (LF) (SN)
1
J824* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1
J826* 6510015541 B4B-ZR-SM4-TF (LF) (SN)
1
J2001* 6510023720 LGY6501-0600C
1
J2052* 6510023120 CD6109SA1J0
1
J2101* 6510024040 TM11R-5M2-88-LP
1
J2201* 6450001941 KEY-15S-2A3A (LF) (SN)
1
1
MP201 8930065740 2590 D-EARTH SPRING
1
MP2001 8930049470 RUBBER SHEET (AS)
MP2051 8850001860 FLAT WASHER M3 SUS 3X6X0.5
1
MP2052 8850000420 S-WASHER M3 NI
1
[MEMORY BOARD] (MEM)
1
REF ORDER
1
1 NO. NO.
1
J1* 6510024410 AXK6S30545
1
J2* 6510020120 AXK6S40545P
1
1
MP1 8930025070 SPONGE (CW)
MP2 8930025070 SPONGE (CW)
MP3 8930063720 AL SHEET (AN)
[NETWORK BOARD] (NET)
REF ORDER
1
NO. NO.
1
1
J1* 6510021561 52808-2470
1
J2* 6510017930 1771P145-20
1
J3* 6510017930 1771P145-20
1
J4* 6510003521 S04B-EH-S (LF) (SN)
1
MP1 8510011480 1900 AL COVER
1
1
[OSC UNIT] (OSC)
1
1
REF ORDER
1
NO. NO.
1
1
J1071* 6510007020 TMP-J01X-V6
1
J1072* 6510007020 TMP-J01X-V6
J2016* 6510020091 52808-0871
J2017* 6510003401 B04B-EH-S (LF) (SN)
[PA UNIT] (PA)
REF ORDER
1
NO. NO.
1
1
P2* 6510018990 PHR-4
1
P3* 5610000500 179228-3
1
P4* 5610000500 179228-3
1
MF1 2710000860 FBA08A12H
1
MF2 2710000860 FBA08A12H
1
†
W1 8900012790 OPC-1299
1
†
W2 9030090030 16/00/320/B11/V05
1
†
W3 9030090030 16/00/320/B11/V05
1
†
W4 9030090040 16WIRE /08/400/B11/V05
1
†
W5 9030090040 16WIRE /08/400/B11/V05
1
1
MP1 8820000551 CAP BOLTM4X8 ZK3
1
MP2 8930047252 1900 SPACER-2
7
MP6 8510015991 2590 PA COVER-1
6
MP7 8410002550 2590 PA HEATSINK
MP8 8930062121 2590 PA SHEET-1
MP9 8930073140 3009 PA ANGLE
MP10 8930061221 2590 R-PA ANGLE-1
MP12 8930062210 THERMALLY SHEET (AL)
MP13 8810009040 SETSCREW (H) 2.6X10 NI
MP14 8810007231 SETSCREW (H) 3X8 ZC3
MP15 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
1
MP16 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
1
MP20 8930063150 THERMALLY SHEET (AR)
1
MP21 8950003640 COATING CLIP CS-2
1
1
6 - 9
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8
7
1
1
1
1
1
1
6
8
5
2
2
