Icom IC-7700 Service Manual page 74

[SW-A BOARD] (SWA)
REF ORDER
NO. NO.
J1* 6510020081 52808-2071
MP1 8930074270 3009 C-SPONGE
MP2 8930055010 RUBBER SHEET (AX)
[SW-B BOARD] (SWB)
REF ORDER
NO. NO.
J1* 6510020531 52808-1871
[TENKEY BOARD] (TEN)
REF ORDER
NO. NO.
J1* 6510022471 40FLT-SM2-TB (LF) (SN)
J4* 6510019971 52808-1071
J5* 6510019971 52808-1071
J7* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J8* 6510019971 52808-1071
[VR-A BOARD] (VRA)
REF ORDER
NO. NO.
R1 7210002970 RV-314 (RK0972210 10KB/10KB)
R2 7210002970 RV-314 (RK0972210 10KB/10KB)
J103* 6510019971 52808-1071
J104* 6510020711 52793-1070
J106* 6510019981 52808-1671
J107* 6510025270 S6B-PH-SM4-TB (LF) (SN)
[VR-B BOARD] (VRB)
REF ORDER
NO. NO.
R1 7210002970 RV-314 (RK0972210 10KB/10KB)
R2 7210002970 RV-314 (RK0972210 10KB/10KB)
R3 7210002970 RV-314 (RK0972210 10KB/10KB)
J1* 6510019971 52808-1071
[VR-C BOARD] (VRC)
REF ORDER
NO. NO.
R1 7210001130 RK097111T005A 10KB
R2 7210001130 RK097111T005A 10KB
R3 7210001130 RK097111T005A 10KB
R4 7210001130 RK097111T005A 10KB
R5 7210001130 RK097111T005A 10KB
R6 7210001130 RK097111T005A 10KB
R7 7210001130 RK097111T005A 10KB
J1* 6510019971 52808-1071
[USB BOARD] (USB)
REF ORDER
NO. NO.
J106* 6510019971 52808-1071
J107 6510026080 XM7A-0441
J108 6510026080 XM7A-0441
J109:* 6510022031 B10B-ZR-SM4-TF (LF) (SN)
*: Refer to "BOARD LAYOUTS" for the location.
†
: Refer to "GENERAL WIRING" for the connection.
