Amana GUI* User's Information Manual

Gas fired warm air furnace

Advertisement

GUI*, GCI*
Gas Fired Warm Air
Furnace
WARNING
If the information in these instructions is not
followed exactly, a fire or explosion may re-
sult causing property damage, personal in-
jury or loss of life.
—Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity
of this or any other appliance.
—What to do if you smell gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
—Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING
Should overheating occur or the gas supply
fail to shut off, turn off the manual gas con-
trol valve to the furnace before shutting off
the electrical supply.
The installation and servicing of this equipment must be performed by qualified, experienced technicians only.
Due to policy of continual product improvement, the right is reserved to change specifications and design without notice.
Effective: April 1996
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION
User's Information
Manual
Affix this manual, Installation Instructions and Specifica-
tion Sheet adjacent to the furnace.
WARNING
To avoid death, personal injury or property
damage, do not use this furnace if any part
of the furnace has been under water. Imme-
diately call a qualified service technician to
inspect the furnace and to replace any part
of the control system and any gas control
having been under water.

To The Owner

Keep this literature in a safe place for future reference.
Important Note To The Owner
It is important that you fill out the owner's registration card
and mail it today. This will assist Amana in contacting you
should any service or warranty information change in the
future. When filling in the registration card, be sure to in-
clude the Model, Manufacturing and Serial Numbers, plus
the installation date. If the registration card cannot be lo-
cated, please call 1-800-843-0304 to register the furnace.
Your warranty certificate is also supplied with the unit. Read
the warranty carefully and note what is covered. Keep the
warranty certificate in a safe place, so you can find it, if
necessary.
10759611

Advertisement

Table of Contents
loading

Summary of Contents for Amana GUI*

  • Page 1: To The Owner

    It is important that you fill out the owner’s registration card not use any phone in your building. and mail it today. This will assist Amana in contacting you • Immediately call your gas supplier from should any service or warranty information change in the future.
  • Page 2: Table Of Contents

    Induced Draft Motor Lubrication ......................10 Air Circulating Blower Motor Lubrication .................... 10 IV. For More Information ..................10 V. Safety Labels ....................11 Amana Refrigeration, Inc. Fayetteville, TN 37334 ATTENTION INSTALLING PERSONNEL As a professional installer you have an obligation to Remember, it is your responsibility to install the know the product better than the customer.
  • Page 3: General Information

    I. General Information WARNING This furnace is built to provide many years of safe and de- PERSONAL INJURY HAZARD pendable service, providing it is properly installed and main- tained. However, abuse and/or improper use can shorten To avoid personal injury or fire, minimum the life of the furnace and create hazards for you, the home- clearances to combustible surfaces must be owner.
  • Page 4: Air Requirements

    • When the furnace is installed in a confined space within Air Requirements a home and the air for combustion and ventilation en- ters the space through ducts from the outside...be sure WARNING to check the entering and outlet (grilled) openings so that they are always clear and clean.
  • Page 5: Propane Furnaces Only

    II. Operation Propane Furnaces Only Thermostat WARNING There are many types and styles of thermostats but the op- PERSONAL INJURY HAZARD eration is usually similar. BE SURE TO BECOME FAMIL- IAR WITH YOUR THERMOSTAT. The simplest type of ther- To avoid death, personal injury or property mostat only starts and stops the furnace to maintain the damage due to explosion or fire, install a gas proper room temperature.
  • Page 6: Operating Instructions

    Operating Instructions 1. Close the manual gas valve external to the furnace. 2. Turn off the electrical power supply to the furnace. 3. Set room thermostat to lowest possible setting. 4. Remove the louvered door on the front of the furnace by lifting up and pulling it forward.
  • Page 7: Reset After Control Lock-Out

    Reset After Control Lock-Out If ignition has not been achieved for any reason after sev- eral ignition cycles, the electronic control module will lock- out the furnace. Ignition is no longer attempted. On fur- naces with a self diagnostic control module, the control di- agnostic light will then repeat a single flash followed by a pause.
  • Page 8: Roll-Out Protection Device

    Roll-Out Protection Device III. Maintenance When flames from the burners are not properly drawn into AT LEAST ONCE A YEAR, BEFORE THE HEATING SEA- the heat exchanger, a flame roll-out limit switch will open SON BEGINS, have the furnace checked by a qualified ser- causing combustion to cease.
  • Page 9: Upflow Filters (Not Included With Furnace)

    Filters must be inspected, cleaned or changed every two Wash, rinse, and dry a permanent filter. Both sides of a metal months or as required. It is the owner's responsibility to keep filter should be sprayed with a dust adhesive as recom- air filters clean.
  • Page 10: Horizontal Filters (Not Included With Furnace)

    Repeat with the left filter. (Figure 11) 7. Replace the blower door, then reconnect the electrical power. Ask a participating Amana dealer about Amana's extended service plan. It adds to the strong warranty with additional parts and labor coverage.
  • Page 11: Safety Labels

    V. Safety Labels NOTE: If safety labels are missing or illegible, contact the installing dealer or Amana Customer Service Department for ordering information.
  • Page 12 THIS COMPARTMENT MUST BE CE COMPARTIMENT DOIT RESTER W ARNING: AVERTISSEMENT: CLOSED EXCEPT WHEN SERVICING FERME, SAUF POUR L'ENTRETIEN B13580-1 To obtain the proper labels, the Model, Manufacturing Number and Serial Number of the unit must be supplied. These numbers are recorded on the nameplate of the furnace. For convenience, record this information here: MODEL NUMBER: _ _ _ _ _ _ _ _ _ _ _ MANUFACTURING NUMBER: P _ _ _ _ _ _ _F SERIAL NUMBER: 9 _ _ _ _ _ _ _ _...
