Maintenance and Service Manual
Wheelchair-Accessible
Lowered Floor Conversion
featuring 2008 and Newer
35497
August 2009
®
Entervan
XT
(Foldout Ramp)
Chrysler Minivans
Chrysler Minivans
W ARNING
®
Read manual
before servicing.
Failure to do so
may result in
serious bodily
injury and/or
property damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Entervan XT and is the answer not in the manual?

Questions and answers

Shawna Smith
July 4, 2025

I have a Braun Ramp. The error I keep getting on my ramp says "Ramp path blocked. Clear path to operate." Can you guys help me find what causes that error,

0

Related Manuals for BraunAbility Entervan XT

Summary of Contents for BraunAbility Entervan XT

  • Page 1 Maintenance and Service Manual ® Entervan Wheelchair-Accessible Lowered Floor Conversion (Foldout Ramp) featuring 2008 and Newer Chrysler Minivans Chrysler Minivans W ARNING ® Read manual before servicing. Failure to do so may result in serious bodily injury and/or property damage.
  • Page 2 INTRODUCTION Introduction Braun lowered floor conversions are designed ranty claims (parts, W ARNING to provide years of pleasure and mobility inde- repairs, etc.), all pendence. Familiarity with proper operation and requests must be Maintenance, lubrica- maintenance procedures will help ensure safe, processed through tion, troubleshoot- troublefree operation.

  • Page 3: Table Of Contents

    CONTENTS Safety Precautions ..........2 Wiring Diagram - Front Driver Seat Electrical System ..........17A, 18A Towing ..............2 Wiring Diagram - Front Passenger Seat Maintenance and Service Requirements ..3 Electrical System ......17B, 18B Maintenance and Lubrication Schedule ..4-6 Electrical Schematic - Power Door, Foldout Ramp and Kneel System ....

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS Safety Precautions Maintenance and service procedures must be performed W ARNING W ARNING only by authorized service personnel. Read this manual, Perform maintenance and lubrication procedures exactly W ARNING the conversion's as outlined in the Maintenance and Lubrication Schedule operator’s manual contained in this manual.

  • Page 5: Maintenance And Service Requirements

    MAINTENANCE and SERVICE Maintenance and Service Requirements Braun lowered floor minivan Electronic Control System: Braun Corporation Aftermarket conversions must be maintained The electronic control system Control Systems Policy: The and serviced by a Braun autho- provides simple one-touch acti- Braun Corporation manufactures rized service representative who vation of power functions.

  • Page 6: Maintenance And Lubrication Schedule

    MAINTENANCE and SERVICE Preventive Maintenance Maintenance is necessary to en- Keeping the passenger slide door The consumer should inspect and sure safe and trouble free conver- lower track pan free of debris, ice clean frequently and routinely sion operation. Encourage the and snow is one of the most ef- (minimum four weeks or 100 consumer to perform preventive...
  • Page 7 MAINTENANCE and SERVICE Maintenance and Lubrication Schedule Foldout Ramp: Foldout ramps vary in design. Disregard references to components not present. Outboard ramp extension hinge and fasteners Clean and lubricate with Light Oil. Resecure or replace fasteners as needed Inspect ramp inboard pivot points (bolts/screws Clean and lubricate with Light Oil.

  • Page 8: Maintenance And Lubrication Schedule

    MAINTENANCE and SERVICE Maintenance and Lubrication Schedule Perform all procedures listed in previous section also Power Fold Ramps: • Ramp flap (extension) chain Lubricate with Anti-Seize (14 oz. caulk tube available per Braun part no. 24710) Remove ramp housing cover/rear vertical panel and inspect: •...

  • Page 9: Troubleshooting Diagnosis Chart

    1.16 Circuit breaker tripped or Reset or replace damaged 1.00 1.21 Transmission not in Park Engage transmission in Park 1.22 Chrysler Slide Door Master Lock Press switch to ON position Out switch in OFF position OPERATION 1.20 1.23 Slide door handles have been...

  • Page 10: Troubleshooting

    3.14 Power door motor harness dis- Correct or contact Braun Product Not Run) connected or damaged Support 3.15 Power door motor damaged Contact Chrysler Service Center 3.20 3.21 Misaligned or otherwise damaged Correct or contact Braun Product drive cable or door track Support Motor Runs 3.00...
  • Page 11 TROUBLESHOOTING FUNCTION SYMPTOM POSSIBLE CAUSE REMEDY 4.11 See 1.00 and 3.41 4.12 No door full open signal Correct or contact Braun Product Support 4.10 4.13 Ramp motor harness discon- Connect, repair or replace No Unfold nected or damaged (Deploy) 4.14 Loose, damaged or missing fold Tighten, replace or otherwise correct Operation arm securement collar/coupling...
  • Page 12 TROUBLESHOOTING FUNCTION SYMPTOM POSSIBLE CAUSE REMEDY 6.10 6.11 See 3.10, 4.12 and 5.12 6.12 Power slide door module (PSDM) Correct or contact Braun Product Support Close did not see stowed signal Operation 6.20 6.21 See 3.20 Motor Runs - Door Does Not Move 6.30 6.00...

  • Page 13: Microswitches

    MICROSWITCHES Ramp Microswitch Adjustment The ramp motor assembly is equipped with two The stow position microswitch determines the full microswitches, the deploy microswitch and stow stow position (how far the ramp stows inside the position microswitch. vehicle). The deploy microswitch cuts the ramp motor Remove the ramp motor assembly interior cover when the platform reaches a position where the to access microswitches (located rear of the pas-...

  • Page 14: Below Floor Obstructions

    BELOW FLOOR OBSTRUCTIONS 2008 Chrysler XT Lowered Floor Minivan (Foldout Ramp) Conversion When installing an electrical tie-down, power seat or other Color Key auxiliary device, ob- structions below the OEM Wiring floor must be avoided. Obstructions include Braun Wiring wiring, fuel system, brake lines, etc.

  • Page 15: Auxiliary Power Supply

    AUXILIARY POWER SUPPLY Two fuse blocks are provided CAUTION W ARNING as an auxiliary power source for dealer-installed auxiliary electrical Do not connect device(s). Fuse block details and auxiliary devices to specifications are provided below. vehicle battery. Doing The fuse blocks are located in the so may result in dam- bottom of the center dash console.

  • Page 16: Electronic Control Modules

    ELECTRONIC CONTROL MODULES Diagram - Electronic Control Module Connections / Inputs / Indicators The control module assembly is Kneel Override - Buttons drive the trol switch is activated). A tone will mounted to the bottom of the pas- kneel system in the direction indi- also sound if the ramp motor pulls senger side third row seat.
  • Page 17 2008 Chrysler XT Conversion (Foldout Ramp) Switch and Component Location Diagram Master Lock Overhead Ramp Override B-Pillar Switch C-Pillar Switch Out Switch Console Switch Switch Ramp Press and hold this switch to stow (fold) the ramp. Release switch when the...

  • Page 18: System

    Wiring Diagram - 2008 Chrysler XT Conversion (Foldout Ramp) Power Door, Foldout Ramp & Kneel System NOTE To Battery Ground Rear Fuse Panel Front Fuse Panel Ignition Gateway Module Ramp Override Ramp Motor E51194A-09 E51461A Relay 100383 Switch 33469 & Gear Box...
  • Page 19 Wiring Diagram - 2008 Chrysler XT Conversion (Foldout Ramp) Front Driver Seat Electrical Systems Wiring Diagram - Front Driver Seat Electrical Systems (without Memory) DRAWING NOTES 37-COND WIRE CODE Junctions only occur at intersections with junction symbols ( COLOR FUNCTION...
  • Page 20 Wiring Diagram - 2008 Chrysler XT Conversion (Foldout Ramp) Front Passenger Seat Electrical Systems Wiring Diagram - Front Passenger Seat Electrical System (OEM Manufacture Date before 2-25-08) DRAWING NOTES 37-COND WIRE CODE COLOR CODE 12-COND WIRE CODE Junctions only occur at intersections with junction symbols (...
  • Page 21 Electrical Schematic - 2008 Chrysler XT Conversion (Foldout Ramp) Power Door, Foldout Ramp & Kneel System Ramp Switches E51461A E51091A and motor Vehicle 100278-001 100188-001 100281-002 52038A-96A8 E51059A-ADA Battery (12Vdc) Grey Ramp Connector1 Main Logic Board Connector1 Grey Kneel Connector1...
  • Page 22 Exploded View - 2008 Chrysler XT Conversion (Foldout Ramp) Platform Assembly Page 19B Page 20B...

  • Page 23: Assembly

    REPLACEMENT PARTS 2008 Chrysler XT Conversion (Foldout Ramp) Platform Assembly Item Qty. Description Part Number RAMP-EXTENSION/29.25" AUTO/2008 CHRYSLER E50262??-08 RAMP-BASE/29.25"AUTO/08RT E51095?? SCREW-#10-32X1/2 FHDHXS-AUTO BLK-W/PATCH 17192P NUT-#10-32 W/LOCKWASHER/AUTO-BK 18349 HINGE WMT.-S.S. 2" X 1/4" X 29" 18619W029 WASHER-1/4" FLAT/AUTO-BK 10062 BOLT-1/4-20X3/4"BHCS NYLK/BKZN...
  • Page 24 REPLACEMENT PARTS 2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly Gear, Motor and Base Assembly Item Qty. Description Part Number Item Qty. Description Part Number WMT-MAIN RAMP HOUSING E51096W?? MOTOR-RAMP ASSY/KLAUBER 12V. 1.2 RPM 51654AK2907 WMT-ARM-DRIVES RAMP-GEAR MTR E40268W-07BK SUPPORT-GEAR MOTOR/FOLDING RAMP/08RT...
  • Page 25 Exploded View - 2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly Gear, Motor and Base Assembly Page 23A Page 24A...
  • Page 26 Exploded View - 2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly Page 23B Page 24B...

  • Page 27: Foldout Ramp Assembly

    REPLACEMENT PARTS 2008 Chrysler XT Conversion (Foldout Ramp) Ramp Assembly Item Qty. Description Part Number RAMP ASSY-BASE & EXT/29.25" AUTO E51095??A2909 ASSY-MAIN RAMP HOUSING E51096A?? BEARING-FLANGE-5/8" X 1/4"-10FDU04 28435 SCREW-1/4-20 X 3/8" FLBHSCS- 28252 BOLT-3/8-16 X 3/4" FLBHSCS-GD8 25171 PIVOT PIN/BUSHING/EV RAMP/2905 52571-2905 HARNESS-RAMP EXT./CONTROLLER-OAKTEC...

  • Page 28: Kneel Assembly

    REPLACEMENT PARTS 2008 Chrysler XT Conversion (Foldout Ramp) Kneel Assembly Item Qty. Description Part Number Item Qty. Description Part Number ASSY-KNEEL BOX/ACTUATOR/RT E51016A KNEEL SWITCH BRACKET E50859BK KNEEL SWITCH BRACKET-TOP E50880BK SWITCH-DPDT VFD1 33469 BOLT-1/4-20 X 3/4 GR5-HEX/AUTO-BK 10970 ASSY-ACT/K2xG20-12V-08/2000#/8"STROKE...
  • Page 29 REPLACEMENT PARTS Exploded View - 2008 Chrysler XT Conversion (Foldout Ramp) Kneel Assembly Page 27...

  • Page 30: Dimensions

    DIMENSIONS Dimensions - 2008 Chrysler XT Conversion (Foldout Ramp) All dimensions are for reference only. Foldout Ramp Door Opening Usable Width (Slide Door) 31-1/2” Door Opening Usable Height (Slide Door) 56-1/2” Interior Height at Center of Van* 61” Interior Height at Driver and Passenger Position** 60”...
  • Page 31 "Providing Access to the World" ® Over 300 Braun Dealers Worldwide ® "Providing Access to the World" International Corporate Hdqrs: P .O. Box 310 Winamac, IN 46996 USA 1-800-THE LIFT ® (574) 946-6153 FAX: (574) 946-4670...
  • Page 32 ® 35497 35497 August 2009 August 2009 International Corporate Hdqrs: P .O. Box 310 Winamac, IN 46996 USA International Corporate Hdqrs: P .O. Box 310 Winamac, IN 46996 USA ® 1-800-THE LIFT ® (574) 946-6153 FAX: (574) 946-4670 1-800-THE LIFT (574) 946-6153 FAX: (574) 946-4670 ™...
