Polycom SoundStation IP 6000 Quick Start Manual page 5

Configure the Polycom 6000 Conference IP Phone via web configurator
• Open a web browser window from a computer connected to the same local area network as
the OfficeSuite Polycom SoundStation IP 6000 Conference Phone.
• Type in the IP Address from the OfficeSuite Polycom SoundStation IP 6000 Conference
Phone (If static it is the one you assigned in step A.3.a. If DHCP it is the one you retrieved
from step B.3.c)
• Hit enter
• When prompted, enter user name ''Polycom''
• Enter Password ''456''
• Once the Polycom User Interface appears select ''Line''
o Identification
Display Name -- - User name as per OfficeSuite web site when created
Address -- - type in OfficeSuite ext.
Auth User ID -- - type in OfficeSuite ext.
Auth password -- - type in OfficeSuite password for that ext.
Label -- - enter the extension and/or the DID for the extension
o Server 1
Address (type in address to MBG -- - Sil dependent)
Port -- - type in 5060
Transport -- - UDP only
Scroll to bottom hit submit
Wait for phone to reboot
• Select SIP
o Server 1
Address (type in address to MBG -- - from pre-installation check list)
Port -- - type in 5060
Transport -- - UDP only
o Local Settings
Digitmap -- - type in x.T|x.#
Digit Timeout -- - type in 3
Scroll to bottom hit submit
Wait for phone to reboot
• Select General
o Select Audio Processing
Codec Preferences
• Select G.711Mu as 1
• Select G.729AB as 2
• Select the remaining Codecs as Not Used
Scroll to bottom hit submit
Wait for phone to reboot
• Select General -- - again
o Select Time
SNTP (64.90.182.55 OR 129.6.15.30)
Copyright © 2014 Broadview Networks
Quick Start Guide for the
Polycom SoundStation IP 6000
Conference Phone For OfficeSuite®
5
