Battery Pack Installation
4.
Place the battery pack in to the battery tray
as shown in the photograph.
Secure the battery pack using the two
Velcro strips on the side of the plastic
battery tray.
Final Connection
5.
Connect the cable from the powerpack in to
the underneath of the handset.
Place the top loop of the lift-up strap around
the opposite push handle to the handset.

Disassembly and Transportation

1. Switch the PowerStroll off at the ignition.
2. Disconnect / unclip the powerpack
connector from underneath the handset.
3. Remove the lift-up strap from the push
handle.
4. Lift the battery pack out of the battery tray.
PowerStroll Owner's Handbook
5. Remove the powerpack by pulling the
Velcro strap whilst pulling the powerpack
from the rear of the brackets (see the photo
below).
6. Place all items in the carry holdall supplied.
Notes:
• The battery supplied with the PowerStroll is
classified as safe for air travel by compliance
with IATA special provision A67.
• The battery pack and power pack have fabric
handles to make them easier to carry.

Battery Charging and Care

Follow the procedure below step by step:
1. Turn the power switch to (OFF)
2. Lift out the battery pack using the handle
on the pack.
3. Plug the charger's power cord into the
mains.
4. Plug the charger's round plug into the
charging socket of the battery pack
5. Switch on the plug socket.
6. The charger's LED will illuminate orange to
indicate the batteries are charging. The
charging duration is about 8 hours. To
ensure optimum performance a 12-hour
charge is recommended.
7. The orange LED will turn green when
charging is complete.
8. Turn off the charger, disconnect the power
cord and the round plug from the battery
pack.
Page 4 of 8 Part Code: Z24000
