Summary of Contents for PURE Evoke D4
-
Page 2: Pure Warranty Statement For Australia
If you have any questions about your warranty you can call us toll free 1800 988 268. What’s covered by this warranty? • Pure agrees to refund, repair or replace, at your election, without charge to you, any part found to be defective during the warranty period. - Page 3 Thank you for choosing Evoke D4. This manual will get you up and running in no time and explains how to make the most of Evoke D4’s great features. If you need additional help with topics not covered in this manual, please visit the Pure support pages at www.pure.com.
-
Page 4: Safety Instructions
10. Fit the mains adapter to an easily accessible socket, located near the radio and ONLY use the mains power adapter supplied by Pure (model number ZDD090150, ZDD090150BS or ZDD090150AU). 11. Always switch the radio off and disconnect it from mains power before inserting or removing a ChargePAK. -
Page 5: Table Of Contents
Contents Introduction Front panel controls Rear connectors Remote control Getting started Changing digital radio stations Changing FM radio stations Pausing and controlling scrolling text 10 Storing and selecting presets To quick-store a station to a preset button (1–4) To store a station to the preset list (1–15) To recall a preset when listening to digital radio or FM radio 11 Setting the alarm &... -
Page 6: Introduction
Introduction Front panel controls SnoozeHandle Tap to snooze the alarm Volume dial Adjust and mute Select dial volume (see Turn and press to browse page 6) and select radio stations (see page 8), select and adjust menu options or Volume Select pause and control scrolling text (see page 9) -
Page 7: Rear Connectors
Rear connectors Stereo Speaker 9V DC Aux in Stereo Speaker Stereo Speaker Stereo Speaker Stereo Speaker V DC 9V DC 9V DC 9V DC Aux in Aux in Aux in Aux in Connect to supplied 3.5 mm stereo Analogue stereo Mini-B type USB mains adapter only headphone socket... -
Page 8: Changing The Information Shown On Screen
Adjusting and muting the volume Turn the Volume dial or press the Volume buttons on the remote to increase or decrease the volume. Press the Volume dial to mute. Volume Volume Volume BBC Radio 2 Muted Changing source Use the Source button to choose between digital radio, FM radio or Auxiliary device (a separate device such as an MP3 player connected to the Aux In socket). -
Page 9: Getting Started
Getting started Quick set up Note: If you have a ChargePAK F1 rechargeable battery (sold separately) fit it now before plugging in Evoke. See page 17 for more information. • Unclip the aerial and fully extend it (steps A and B). •... -
Page 10: Changing Digital Radio Stations
Changing digital radio stations Using the front panel controls Turn the Select dial left or right to browse through the list of available digital stations. Push the Select dial to change the station. Select Select Station list BBC Radio 6Music BBC Radio 6Music Now playing: Race For T Using the remote control... -
Page 11: Pausing And Controlling Scrolling Text
Pausing and controlling scrolling text Using the front panel controls When ‘Scrolling text’ information is displayed in either digital or FM radio, push the Select dial to pause the scrolling text. Select BBC Radio 6Music BBC Radio 6Music Playing: Race For Th Now playing: Race For T Turn the Select dial right and left to scroll forwards and backwards through the text. -
Page 12: Storing And Selecting Presets
Storing and selecting presets Store up to 15 digital and 15 FM radio stations for quick access. To quick-store a station to a preset BBC Radio 6Music Now playing: No Cars G button (1–4) Tune to the digital or FM radio station you want to store. Press and Preset 1 stored hold one of the numbered Preset buttons (1–4) for two seconds until you see a message to confirms the preset has been stored on the... -
Page 13: Setting The Alarm & Timers
Setting the alarm & timers Setting an alarm Alarm 1 Setup Evoke has two alarms which can switch the radio on and tune to a digital or FM radio station or sound an alarm tone. Press the button. Turn and press the Select dial to select ‘On’. The alarm is now Alarm time active. -
Page 14: Changing The Alarm Snooze Time
Changing the alarm snooze time Set snooze time 5 minutes Press Menu. Turn and press the Select dial to choose ‘Clock’. Turn and press the Select dial to choose ‘Set snooze time’. Turn and press the Select dial to change the snooze time between 1 and 59 minutes. -
Page 15: Options And Settings
Options and settings Digital radio settings Autotune You can use the autotune function to automatically scan for new digital radio stations and remove inactive ones. Note: Autotune is only available when you have selected ‘Digital radio’ as the radio source. To carry out an autotune: Press Menu. -
Page 16: General Settings
Software updates for your Evoke may be made available in the future. If you register your product and include a valid e-mail address you will receive notification of software updates (register at www.pure.com/ register). Alternatively, visit http://support.pure.com at any time to check for available software updates. -
Page 17: Clock Settings
Clock settings Setting the time and date The time and date on Evoke are automatically set by the FM or digital radio signal. If the time/date does not update automatically, you can manually set it using this option. Note: Any time or date updates received by an FM or a digital broadcast will override manual settings, if clock synchronisation is enabled (see below for more information). -
Page 18: Display Settings
Display settings Adjusting the display You can adjust the brightness and time-out duration of the display for when the unit is switched on and in standby. To change display options: Press Menu, scroll to ‘Display settings’ and push the Select dial. Now choose either ‘Active’... -
Page 19: Using A Chargepak F1
Important: Evoke can only be powered with a Pure ChargePAK F1 and is not compatible with any other batteries, either disposable or rechargeable, or any other ChargePAK model. -
Page 20: Help And Specifications
Help and specifications Secondary and inactive stations (<</>>) Secondary digital radio services Some stations have accompanying secondary services which provide extra information or alternative content and may only be broadcast at certain times. If a station has a secondary service available, the station shows ‘>>’... -
Page 21: Technical Specifications
Output DC 9.0V , 1500mA; Main unit: DC 9.0V , 1.5A ChargePAK Pure ChargePAK F1 rechargeable battery pack (available separately) Power consumption Standby with clock display: >0.8W, Standby with display off: >0.5W, Active: 3.5W Dimensions 180mm high x 217mm wide x 115mm deep... -
Page 22: Warranty Information
Please visit www.pure.com/register to register your product with us. Should you have a problem with your unit please contact your supplier or contact Pure Support at the address shown on the rear of this manual. - Page 23 Pure UK Headquarters Pure Australasia Pty Ltd Imagination Technologies Limited PO Box 5049 Home Park Estate Wonga Park Kings Langley Victoria 3115 Herts, WD4 8LZ Australia United Kingdom sales.au@pure.com www.pure.com http://support.pure.com/au http://support.pure.com...
- Page 24 104ZE...
