XX. Unified Wire Manager (UM)
Figure 7.6.3 (j) - GetConnections Utility
7.6.3.1. Hypervisor
Xen Bridge Configuration
The Xen Bridge Configuration module allows you to view and manage network bridges, virtual
nterfaces (vifs) and virtual machines to which those virtual interfaces are assigned. The left
pane displays a list of different bridges created. Clicking on a bridge name will display related
properties on the right.
If a virtual interface is attached to a particular bridge, a "+" link appears next to the bridge name.
Expanding the "+" link will display the virtual interface and expanding the "+" for that virtual
interface displays the virtual machines to which it is assigned. Click on the virtual machine
names to view their properties on the right.
To delete a bridge, click on the bridge name and then click "Delete Bridge". This will also delete
the virtual interface attached to that bridge and the VM(s) to which the interface was assigned.
